Rowe WALLPHONO WP100 Installation Instructions

Mars bill acceptor phonograph

Hide thumbs

Purpose:

These instructions cover the installation of a Mars AE2400 Bill Acceptor (700 bill capacity) with Mars

250079022 115V cable (supplied by the customer) in a Rowe WP100 Wallphono, with the use of the

22111809, 22111822 or 22111823 installation kit.

Tools Required:

1/4" and 11/32" Nut Drivers, Pliers

Parts Included in this Kit:

Part No.

40916801

40895201

21948602

25156910

40899803

21572601

40854003

40854004

40854005

21892613

86663610

80443008

80443006

88933000

87843000

70099201

70099101

34022302

22130503

Step-By-Step Instructions:

Step 1.

Unplug power cord from the 110V outlet.

Step 2.

Set the dip switches on the Mars Acceptor to 1 through 6 ON and 7 and 8 OFF.

Step 3.

Remove the 115V jumper plug from the power cord bracket. Using the pliers, attach the

blue self-stripping terminals to both the white and black wires making sure that they snap

all the way closed. Return the jumper to the power cord bracket.

Installation Instructions

INSTALLING THE MARS BILL ACCEPTOR

IN THE WP100 WALLPHONO PHONOGRAPH

Description

Mars Bracket Assembly

Bill Acceptor Mounting Bracket

Spacer

Shoulder Washer

700 Bill Detent Bracket

Fall Stop Cable

Bill Inlet (Blue) (for kit #22111809)

Bill Inlet (Green) (for kit #22111822)

Bill Inlet (Gold) (for kit #22111823)

Bill Insertion Label

#8 x 5/8 Black Wood Screw

#8-32 x 1/2 Self Tapping Screw

#8-32 x 3/8 Self Tapping Screw

#8 M.S. Washer

#8-32 Keps Hex M.S. Nut

Self-Stripping Terminal (Blue)

Self-Stripping Splice (3 way)

Harness

Installation Instructions

Qty.

22130503

Page 1 of 4

Rev. B

Table of Contents

Need help?

Do you have a question about the WALLPHONO WP100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Rowe WALLPHONO WP100

Page 1 Purpose: These instructions cover the installation of a Mars AE2400 Bill Acceptor (700 bill capacity) with Mars 250079022 115V cable (supplied by the customer) in a Rowe WP100 Wallphono, with the use of the 22111809, 22111822 or 22111823 installation kit.
Page 2 Step 4. Using the two #8-32 Hex Nuts, attach the Detent bracket to the two studs on the side of the mechanism partition with the catch facing the front of the box. See Figure 1. Step 5. Remove the Bill Blockout from the front door and install the Bill Inlet supplied with this kit. Step 6.
Page 3 40899803 (2) #8-32 Keps Hex Nuts Detent Bracket Figure 1 (4) #8-32 x 1/2 Self Tapping Screws 2 each side 40916801 Mars Bracket Assembly Figure 2 22130503 Page 3 of 4 Rev. B...
Page 4 25156910 Shoulder Washer and (1) Screw 21948602 Spacer and (2) #8-32 x 3/8 Self-Tapping Screws 40895201 Bill Acceptor Mounting Bracket (4) #8 x 5/8 Black Wood Screws Figure 3 22130503 Page 4 of 4 Rev. B...
