Summary of Contents for CYCLOPS NOVA OSD
- Page 1 NOVA V1.0 manual NOVA V1.0 manual NOVA NOVA OSD OSD V1.0 V1.0 manual manual Thanks for choosing the Cyclops products.
- Page 2 Name Name Quantity Quantity Param Param Name Name Quantity Quantity Param Param NOVA OSD mainboard GPS module 10Hz 100A Current sensor 50V 100A Infrared sensor Servo lead 20cm Infrared sensor cable 50cm Current sensor cable 20cm GPS cable...
- Page 3 Connection Connection diagram diagram Connection Connection diagram diagram Power jumper notice： there are 3 pins marked as above(pin 1,2,3), when the jumper connects the pin 1 and 2, the OSD and the AV in(camera) and AV out(video Tx)will be powered by the current sensor, also the power of your motor. WARNING, in this situation, you motor lipo should be 3s,or you will damage the OSD or your video devices.
- Page 4 Connect the equipments as above (the gps must be connected), power it on, the red LED will flash and the Nova OSD will show start-up screen as below: Before the start-up screen disappear, press the setting button, you will enter the...
- Page 5 configuration menu screen as below: Configuration Configuration guide guide guide： ： ： ： Configuration Configuration guide Press the setting button one time, the cursor will move to the next setting item, if press and hold for 2 seconds, the present configuration item will be executed. INIT INIT INIT IR IR IR...
- Page 6 Set the center position and directions of the servos for your plane。Press and hold the setting button for 2 seconds, the word”center”will appear, during the time, you should keep your Aileron and Elevator sticks of your radio on the center position;...
- Page 7 2 sensors on the board. Keep the IR sensor from the video Tx, which may affect the sensor. 4、 There are 3 modes for Nova OSD, you can connect one spare channel of your radio and use a 3-position stick to switch the modes. When the gps get signals,...
- Page 8 you can switch between manual mode, PA mode and RTH mode. 5、 Before your every flight, press the setting button one time to reset all the parameters of the OSD screens shows(including altitude, distance, flying time, current, mah consumed), don’t press and hold, or you will enter the unit switch process.
- Page 9 ChainLinkDare receiver for the future bi-direction communication application. 11 NOVA OSD can show analog RSSI voltage on the top left side, the voltage detect range is 0.1—3.3V, when the voltage is less the 0.1v, the RSSI voltage won’t be shown.
