Overview of this Publication Thank you for purchasing a STRATUS Air Conditioner. This manual shows you how to install, program and maintain all STRATUS Air Conditioners in the series. Who Should Read This Manual This manual contains important information for those who will install, maintain, and/or operate any of the STRATUS Air Conditioners. -
Page 6: Unpacking Stratus Air Conditioning Equipment
Motor-Compressor Thermally Protected UL Type 12, 04, 4X Interface to Electronic Enclosure per UL 50 & 508a STRATUS TA10 Series Industrial Air Conditioners User Manual 1 - 8 0 0 - 6 3 3 - 0 4 0 5 1 - 8 0 0 - 6 3 3 - 0 4 0 5... -
Page 7: Basic Operation
STRATUS air conditioners operate as a “closed loop” system the alarm condition is bypassed to prevent nuisance trips. where the enclosure air is taken into the STRATUS air Then, there is a 5-minute, anti-short cycle time delay before conditioner and cooled, and then returned to the enclosure with the compressor is turned on. -
Page 8: Features
* Voltage variation no greater than ± 10% from nameplate rating and Frequency variation no greater than ± 3Hz from nameplate rating. STRATUS TA10 Series Industrial Air Conditioners User Manual 1 - 8 0 0 - 6 3 3 - 0 4 0 5 1 - 8 0 0 - 6 3 3 - 0 4 0 5 2nd edition, Rev. - Page 9 * Voltage variation no greater than ± 10% from nameplate rating and Frequency variation no greater than ± 3Hz from nameplate rating. STRATUS TA10 Series Industrial Air Conditioners User Manual w w w . a u t o m a t i o n d i r e c t . c o m w w w .
-
Page 10: Preliminary Testing
Note: If the Digital Temperature Controller displays any alarms, refer to the Digital Temperature Controller section. • After completing the above check points, the electrical enclosure is ready to be prepared for the installation of the STRATUS AC unit. STRATUS TA10 Series Industrial Air Conditioners User Manual... -
Page 11: System Operation
As soon as electrical remote alarming. power is supplied to the STRATUS system and the power Three main conditions can shut down the AC compressor switch located on the back of the unit is turned on, the down: evaporator fan will start to operate. -
Page 12: Digital Temperature Controller
Programming phase (Customer wired) STRATUS TA10 Series Industrial Air Conditioners User Manual 1 - 8 0 0 - 6 3 3 - 0 4 0 5 1 - 8 0 0 - 6 3 3 - 0 4 0 5... -
Page 13: Functions And Parameters
1. Press and hold the UP and DOWN arrow keys simultaneously for more than 3 seconds until the Pon message is displayed. STRATUS TA10 Series Industrial Air Conditioners User Manual w w w . a u t o m a t i o n d i r e c t . c o m w w w . - Page 14 Temperature alarm LA2 automatically clears as soon as the condenser coil temperature returns to above 60°F Temperature alarm CA automatically clears as soon as the pressure returns to normal. STRATUS TA10 Series Industrial Air Conditioners User Manual 1 - 8 0 0 - 6 3 3 - 0 4 0 5 1 - 8 0 0 - 6 3 3 - 0 4 0 5 2nd edition, Rev.
-
Page 15: Preventative Maintenance
Moving the Enclosure and the Air Conditioner filters by frame size (TA10-FILTER-1, TA10-FILTER-2 or If the enclosure the STRATUS air conditioner is mounted to TA10-FILTER-3) from AutomationDirect. DO NOT operate must be moved, remove the air conditioner from the enclosure the air conditioner without the air filter. -
Page 16: Troubleshooting Guide
Low refrigerant Have qualified A/C tech check level. STRATUS TA10 Series Industrial Air Conditioners User Manual 1 - 8 0 0 - 6 3 3 - 0 4 0 5 1 - 8 0 0 - 6 3 3 - 0 4 0 5... -
Page 17: Dimensions
All dimensions inches [millimeters] Wiring STRATUS TA10 Series Industrial Air Conditioners User Manual w w w . a u t o m a t i o n d i r e c t . c o m w w w . a u t o m a t i o n d i r e c t . c o m... - Page 18 1000 and 1500 BTU/H Units All dimensions inches [millimeters] STRATUS TA10 Series Industrial Air Conditioners User Manual 1 - 8 0 0 - 6 3 3 - 0 4 0 5 1 - 8 0 0 - 6 3 3 - 0 4 0 5...
- Page 19 All dimensions inches [millimeters] Wiring STRATUS TA10 Series Industrial Air Conditioners User Manual w w w . a u t o m a t i o n d i r e c t . c o m w w w . a u t o m a t i o n d i r e c t . c o m...
- Page 20 120 and 240V 480V STRATUS TA10 Series Industrial Air Conditioners User Manual 1 - 8 0 0 - 6 3 3 - 0 4 0 5 1 - 8 0 0 - 6 3 3 - 0 4 0 5...
- Page 21 All dimensions inches [millimeters] Wiring STRATUS TA10 Series Industrial Air Conditioners User Manual w w w . a u t o m a t i o n d i r e c t . c o m w w w . a u t o m a t i o n d i r e c t . c o m...
- Page 22 120 and 240V 480V STRATUS TA10 Series Industrial Air Conditioners User Manual 1 - 8 0 0 - 6 3 3 - 0 4 0 5 1 - 8 0 0 - 6 3 3 - 0 4 0 5...
-
Page 23: Schematics
Prewired 22 AWG pigtail (7 ft) for Remote Alarming STRATUS TA10 Series Industrial Air Conditioners User Manual w w w . a u t o m a t i o n d i r e c t . c o m w w w . - Page 24 Schematic - 240V Prewired 22 AWG pigtail (7 ft) for Remote Alarming STRATUS TA10 Series Industrial Air Conditioners User Manual 1 - 8 0 0 - 6 3 3 - 0 4 0 5 1 - 8 0 0 - 6 3 3 - 0 4 0 5...
- Page 25 Prewired 22 AWG pigtail (7 ft) for Remote Alarming STRATUS TA10 Series Industrial Air Conditioners User Manual w w w . a u t o m a t i o n d i r e c t . c o m w w w .
-
Page 26: Notes And Model Information
828-334 1718504 1716522 STRATUS TA10 Series Industrial Air Conditioners User Manual 1 - 8 0 0 - 6 3 3 - 0 4 0 5 1 - 8 0 0 - 6 3 3 - 0 4 0 5 2nd edition, Rev. C. - Page 27 STRATUS TA10 Series Industrial Air Conditioners User Manual w w w . a u t o m a t i o n d i r e c t . c o m w w w . a u t o m a t i o n d i r e c t . c o m...
