AStar
The AStar is a remote audio networking hub that can be connected to a DiGiCo
4rea4 system fitted with a A128128 connectors. It provides four A3232 ports,
each carrying 32x32 channels of 96kHz audio, that can be used to connect to
4rea4 expanders.
Up to two A168/A164 expanders can be connected to each A3232 port allowing
up to 128 remote inputs and 64 remote outputs to be added to the 4rea4 system
per AStar connection. Two AStar connections can be used for a dual redundant
system.
Check the DiGiCo website for the latest documentation and software
updates
Connection
Normal Connection
Up to 8 A168/A164 expanders can be connected to an AStar
AStar User Guide
AP11443 Issue 1
Advertisement
Table of Contents
Summary of Contents for digico AStar
- Page 1 AStar The AStar is a remote audio networking hub that can be connected to a DiGiCo 4rea4 system fitted with a A128128 connectors. It provides four A3232 ports, each carrying 32x32 channels of 96kHz audio, that can be used to connect to 4rea4 expanders.
- Page 2 Up to 4 expanders can be connected redundantly to a pair of AStars. Routing Use the 4rea4 Routing screen to patch signals to and from the AStar I/O module connected to the AStar. Each A3232 on the AStar has 32x32 available...
- Page 3 Installation The AStar can be used free standing or up to two AStars can be installed in a 1u rack space using our optional rack ear kit which can be ordered from your...
- Page 4 A limited one year manufacturer’s warranty applies to this product, the conditions of which can be found at: http://www.digico.biz/docs/about/legal.shtml By using this DiGiCo product and the software within it you agree to be bound by the terms of the relevant End User Licence Agreement (EULA), a copy of which can be found at: http://www.digico.biz/docs/about/legal.shtml...
