SHYAM Networks GS800 Series Quick Start Manual

8 port gigabit ethernet switch
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

NETWORKS
8 Port Gigabit Ethernet Switch
For advanced settings and more detailed information, download the user
manual from www.shyamnetworks.com.
GS800
Quick Start Guide
Package Contents
8 Port Gigabit Ethernet Switch
(main unit)
Power Adapter (Optional)
DC Power Cord
Ethernet Cable
Console Cable (on request)
Quick Start Guide
www.shyamnetworks.com
1
1
1
1
1
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GS800 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for SHYAM Networks GS800 Series

  • Page 1 NETWORKS GS800 8 Port Gigabit Ethernet Switch Quick Start Guide Package Contents 8 Port Gigabit Ethernet Switch (main unit) Power Adapter (Optional) DC Power Cord Ethernet Cable Console Cable (on request) Quick Start Guide For advanced settings and more detailed information, download the user manual from www.shyamnetworks.com.

  • Page 3: Hardware Overview

    GS800 NETWORKS 1. Hardware Overview Status LEDs WAN Ports Factory Default Button Console Port LAN Ports GS-8GC-2GF2GC-IP Available Models MODEL DESCRIPTION GS-8GF-2GF2GC-l LAN - 8 fiber, WAN - 2 fiber, 2 copper GS-8GC-2GF2GC-l LAN - 8 copper, WAN - 2 fiber, 2 copper GS-8GC-2GF2GC-IP LAN - 8 copper (PoE), WAN - 2 fiber, 2 copper ( PoE) GS-4GF4GC-2GF2GC-IP...

  • Page 4: Caution And Warnings

    GS800 NETWORKS LED Behavior LED/BUTTON COLOR STATUS DESCRIPTION Indicates GS800 is receiving power Green and is functioning properly. GS800 is not powered-up. Green GS800 is up and working. There is some problem such as the fans are not working, hardware/ software errors, or others.
  • Page 5 GS800 NETWORKS 2. Installing GS800 GS800 DC Power Input Computer Computer Computer Computer STEP 1 Place GS800 on a flat and clean surface. STEP 2 Connect the power adaptor’s cord into the front of GS800 and then plug it into a power source.
  • Page 6 GS800 NETWORKS 3. Accessing the GS800 GUI STEP 1 Power-up GS800. STEP 2 Default IP of the system is 192.168.1.1. Give your system IP as 192.168.1.x where x is any integer from 1 to 254 except 1. iNote: If the IP address of GS800 is 192.168.1.1 then the IP address of the system should be other than 192.168.1.1.

  • Page 7: Quick Troubleshooting

    GS800 NETWORKS 4. Quick Troubleshooting PROBLEM PROBABLE REASON RESOLUTION The PWR LED is ‘Off’. GS800 has no power. • Ensure that power cord is properly connected to GS800. • Ensure that the power adaptor is properly connected to the functioning power outlet. •...

  • Page 8: Warranty

    Product ______________________________________________________________________ Model No. _______________________________ Serial No. ___________________________ Dealer’s Stamp & Signature Customer Care, Shyam Networks (A Division of Vihaan Networks Ltd.) 21-B, Sec-18, Udyog Vihar, Gurgaon-122015 Haryana, India Email: customer.care@vnl.in All India Helpline No. - +91 124 309 2000 Ext. 2009, +91 9873573710 Manufactured by Vihaan Networks Ltd.
