Attention:
CONFIRM COMPLIANCE WITH ALL APPLICABLE BUILDING CODES BEFORE
INSTALLATION.
CONFIRM WALL WILL SAFELY SUPPORT COMBINED LOAD OF THE PRODUCT AND
ALL PRODUCT OPTIONS.
IF WALL STUDS ARE WOOD . INSTALL WOOD SCREWS DIRECTLY INTO STUDS.
(standard screws in hardware kit)
IF WALL STUDS ARE METAL . TOGGLE ANCHORS AND MACHINE SCREWS ARE
RECOMMENDED. (not included in hardware kit)
DO NOT INSTALL WOOD SCREWS DIRECTLY INTO METAL STUDS!
6x 4,5x40
1
A
29x 5x60
B
35x 6x30
C
12x 3,9x12
6 mm
D
¼"
6x 4,2x13
E
1x
1x
5x71 mm.
3
6 mm.
¼"
PZ 2
eno Dynamic - 2620-01/2820-01 -Type Opal
C
B
F
F
F
F
quickstart installation guide (concrete)
2
C
B
G
G
J
4
6 mm.
¼"
G
C
A
01
Advertisement
Table of Contents
Related Manuals for Steelcase PolyVision eno Dynamic 2620-01
Summary of Contents for Steelcase PolyVision eno Dynamic 2620-01
- Page 1 PolyVision eno Dynamic - 2620-01/2820-01 -Type Opal ® quickstart installation guide (concrete) a steelcase company 6x 4,5x40 29x 5x60 35x 6x30 12x 3,9x12 6 mm ¼" 6x 4,2x13 5x71 mm. Optional for stud wall/dry wall 6 mm. 6 mm. ¼"...
- Page 2 PolyVision eno Dynamic - 2620-01/2820-01 - Type Opal ® quickstart installation guide (concrete) a steelcase company Contact/Support: PolyVision A/S - Denmark - +45 66 10 90 30 PolyVision SA - France - +33 327 45 60 60 PolyVision NV - Belgium - +32 89 32 31 30 PolyVision Corp - US - 678 542 3100 HP24.11.09...
