- Page 1 Cornermatic Plus ® Adjustable Dual Head Chute Retrofit Installation Guide 1-800-245-3188 www.ductmate.com ductmate@ductmate.com...
- Page 2 Cornermatic Plus Installation ® Guide Adjustable Dual Head Chute Retrofit NOTE: Make sure the machine is powered off when working on this retrofit. The only time it should be powered on during this procedure is to raise or lower the upper head. To Remove the Lower Chute To Install the New Lower Chute Remove the lower chute by removing...
- Page 3 To Install the New Lower Chute To Remove The Upper Chute (Cont.) Lower the upper head of the machine to a lowered position, ensuring that the Using the supplied screws, attach the chute shuttles back on the machine side tabs of the chute to the stabilizing such as in figure 8.
- Page 4 To Install the New Upper Chute Position the new upper chute as shown in figure 10. On figure 11, you will see a more detailed depiction of the base of the chute in proper position. Feed the supplied bolt through the hole in the base of the chute from underneath as seen in figure 12.
- Page 5 To Install the New Upper Chute (Cont.) Then use this screw and washer to attach the upright support to the machine as shown in figure 16. Next attach the other end of the upright support to the tab on the chute using the screw and washer removed a few steps ago.
- Page 6 To Load Sleeves of Corners Into the Upper Chute Begin with the upper chute lowered, so you can easily reach the chute. Locate the markings on the sleeve which state UPPER DUAL HEAD (figure 19). Tear off the perforated end of the sleeve, as seen in figure 20. The arrow head will point to the end which needs to be torn off, to ensure that the corners are loaded right side up.
- Page 7 Ready for Use! Figure 24 Figure 25 Figure 26 Figure 27 Figure 28 Charleroi, PA Lodi, CA 210 Fifth Street 810 S. Cluff Avenue Charleroi, PA 15022 Lodi, CA 95240-9141 800-245-3188 800-245-3188 724-258-0500 724-258-0500 FAX: 724-258-5494 FAX: 209-333-4678 www.ductmate.com 724 - 10/13...
