BELL SYSTEM PRACTICES
AT&TCo Standard
1.
GENERAL
This section contains connection and maintenance
1.01
information for 18- and 30-button general
purpose CALL DIRECTOR® telephone sets equipped
with headset jacks.
This section is reissued to:
1.02
Change title of section from 636- and 637-type
telephone sets
Show that all codes of these telephone sets
are now MD
Show 599H and 657H keys MD, replaced by
657L key
Add modification table, Fig. 6
Add information on T1A ringer, Fig. 1 and
change 241A amplifier to 241-type
Remove common maintenance information
which is now covered in Section 502-600-100.
These sets are not intended for use with
1.03
3-type speakerphone systems.
2.
CONNECTIONS
These sets are factory-wired for use with
2.01
lAl, 1A2, or 6A KTS line circuits.
may also be used with lA KTS line circuits by
modifying the set as shown in Table A.
circuits for lA, lAl, or 1A2 KTS may be connected
to the same set under the following conditions:
(a) lAl or 1A2 KTS lines must be connected
to the first key units with lA Jines connected
to supplementary key modules.
(b) lA, lAl, or 1A2 KTS lines should not be
connected to the same 6 line key module.
(c) lA, 1A1, or 1A2 KTS lines appearing behind
a m a n u a l s w i t c h b o a r d s h o u ld n o t be
502-610-410-i02_1972-04-Ql.jp g Scanned by Frank Harrell, (Cowboy Frank) Castle Rock, Colorado Feb 04,2012 13:17:13
BSP
636A, B, C AND 637 A, B, C, D TELEPHONE SETS
@ American Telephone and Telegraph Company,
SERVICE
intermixed at a CALL DIRECTOR telephone set
due to the different time out intervals provided
by the associated KTU's.
These 636- and 637-type (MD) rotary dial
2.02
telephone sets are equipped with 517A jacks
for the plugs of a G3L handset or a head telephone
set. The internal wiring is arranged to electrically
connect either the line switch or the headset jacks
to the line.
Replacement or substitution of the key in
2.03
the first module may require wiring changes
as shown in the notes for Fig. 3 and 4.
Some spade-tipped conductors or
mounting cord leads are insulated
with tubing which should be cut off
with electrician scissors or diagonal
pliers. Other conductors
with stiff plastic pockets. Pinch open
the pocket to release the spade tips.
When station busy lamp feature is required
2.04
with these sets having 1A1 or 1A2 KTS line
circuits, a P-90D033 Printed Wiring Board Assembly
must be ordered separately and installed in the
636- or 637-type telephone set.
the busy lamp will light whenever a line pickup
button is depressed and the handset is off-hook or
They
the headset is plugged into the jack.
for connections and Section 502-600-100 for installation
Line
procedures.
Sets equipped with a D120C mounting cord
2.05
manufactured prior to III-68 must use circuit
per Fig. 6 to provide station busy lamp feature.
tThe tip and ring leads of lines wired for
2.06
supplementary hold feature must be run
directly between the key telephone equipment and
key telephone set.
r o u t e d p e r SD-6 9 530-0 1 a n d D iv i s i o n 5 1 8
Printed in U.S.A.
SECTION 502-610-410
Issue 2, April 1972
are
With this option,
The A and lamp leads can be
1972
insulated
See Fig. 6
.•
Page 1
