Alpha One FALCON SPERBER mini DMX 2000W Instructions For Use Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Instructions for use
®
FALCON
B
®
SPER
ER
mini DMX 2000W

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FALCON SPERBER mini DMX 2000W and is the answer not in the manual?

Questions and answers

Summary of Contents for Alpha One FALCON SPERBER mini DMX 2000W

  • Page 1 Instructions for use ® FALCON ® SPER mini DMX 2000W...
  • Page 2 - 2 – Version 2.0 November 2008...

  • Page 3: Table Of Contents

    Contents INTRODUCTION ............................4 ..........................4 XPLANATORY NOTE ............................ 4 TEMS SUPPLIED IMPORTANT SAFETY INSTRUCTIONS ....................5 ............................5 SSENTIALS ......................5 ENERAL SAFETY INSTRUCTIONS ..................5 NSTRUCTIONS RELATING TO SAFETY AND USE ..........................6 ARNING NOTICES ....................8 TANDARDS DIRECTIVES REGULATIONS INSTALLATION ............................

  • Page 4: Introduction

    1 Introduction 1.1 Explanatory note ® ® The FALCON SPER mini DMX 2000W is a DMX controlled xenon searchlight. This xenon searchlight with integrated electronic power supply is exclusively for outdoor use*. *Its domestic use is not permitted. ® ® The FALCON SPER mini DMX 2000W can be used in a standing position for...

  • Page 5: Important Safety Instructions

    2 Important safety instructions 2.1 Essentials For your own safety, and to prevent unnecessary damage to your equipment, observe the following safety instructions: 2.2 General safety instructions ® ® The FALCON SPER mini DMX 2000W is suitable exclusively for outdoor use*. *Its domestic use is not permitted.

  • Page 6: Warning Notices

    Never operate the equipment if the mains cable is damaged. Do not remove the lid of the casing under any circumstances. Have your searchlight repaired and serviced only by specialists qualified and authorised by Alpha One GmbH. Improper interference with the equipment can negatively affect the equipment's electrical safety.
  • Page 7 Manufacturer's liability is excluded for accidents to the user from when the equipment is open Danger from UV radiation and explosion of the illuminant It is forbidden to operate the searchlight if the covers are removed or the protective glass is missing. The illuminant creates dangerous UV radiation which can cause severe injury to skin and eyes unless the corresponding protective equipment is used.

  • Page 8: Standards, Directives, Regulations

    2.5 Standards, directives, regulations Safety clearance Position the equipment on a suitable base which corresponds to the requirements in the specification for the searchlight in terms of size, weight and safety clearances to be maintained. Because of the danger of burns, it should be ensured that during operation nobody touches the equipment.

  • Page 9: Installation

    3 Installation Power cable Power cable Circuit Breaker The connection cable is a 3-Pin cable and must be connected to power net by an authorized person. Main switch (Circuit breaker) at front panel under cover shield. 3.1 Current supply Before the searchlight is operated for the first time, the plug provided should be fitted only by a qualified person and in accordance with the applicable regulations.

  • Page 10: Fixture Control

    perating at an incorrect supply voltage will immediately damage the internal electronical components and the illuminant. ® ® Connecting the FALCON SPERBER mini DMX 2000W to an electronic dimmer system will also damage the internal electronics and the illuminant. Replacement of the mains cable should be carried out only by trained and qualified specialist personnel.

  • Page 11: Operating Conditions

    3.4 Operating conditions ® ® The FALCON SPER mini DMX 2000W is a xenon searchlight which can be used only as a permanent installation. The searchlight may be operated only in a standing installation position. Its IP-54 classification allows the searchlight to be installed in a permanent outdoor position.

  • Page 12: Installation - Xenon Illuminant

    3.5 Installation - xenon illuminant The following instructions and safety measures should be observed when installing the xenon illuminant: • Handle the illuminant only in the safety packaging provided for this purpose. • When handling xenon illuminants, it is obligatory to wear appropriate protective clothing (face protection, leather jacket, and leather gloves).
  • Page 13 1. Step: Unlock all four screws from head cover. (Allen key needed) Head cover screw Head cover screw Head cover screw Head cover screw 2. Connect Anode adapter and Cathode adapter to the lamp. (Allen key needed) Anode Adapter 3. Check if the reflector is clean. Reflector 4.

  • Page 14: Instruction Of Beam Adjusting

    Nut for ignitor cable 5. After the anode cable has been reconnected to the ignition rod and fixed with the M8 nut, the glass holding plate must be refitted. 6. After the illuminant has been replaced, it is necessary to readjust the beam. 3.6 Instruction of beam adjusting 1.

  • Page 15: Unfocussed Beams

    3.7 Unfocussed beams Incorrect beam attitudes 3.8 Focussed beam On all axles optimized beam attitude - 15 – Version 2.0 November 2008...

  • Page 16: Cleaning

    3.9 Cleaning The cleaning and maintenance of the components in the head may be carried out only by qualified and trained specialist personnel. To maintain the optimum efficiency of the searchlight, the safety glass inside the light exit opening must be kept clean. This cleaning has a significant effect in creating top-quality and perfect light beams.

  • Page 17: System Description

    4 System description 4.1 Technical data ® ® FALCON SPER mini DMX 2000W Power System Internal electronic current supply, 98% PFC Supply 230VAC +-5%, 50/60Hz, max. tolerance: +-5% Working voltage 3-phase, neutral, ground Power 2.800W requirement -17°C up to +52°C, free of condensing Working temperature 1.4°F up to 126.6°F, free of condensing Housing...

  • Page 18: Dmx

    4.2 DMX The fixture will be controlled over an external DMX512 signal. The fixture must be connected to an external DMX512 control desk. Before using the DMX start address must be selected with the external wired program unit, the “Control 1”. DMX out DMX in Plug for program unit...
  • Page 19 When controller is connected to fixture the „alpha one“ logo appears in the display After pressing the “M” button the actual DMX start-address appears in the display After pressing the “M” button the main menu appears in the display After pressing the “down” button the displays show inverted “DMX SetUp” appears in the display - 19 –...
  • Page 20 After pressing the „E“ button the displays shows inverted „DMX Address“ in the display After pressing the „Enter“ button the display shows the actual DMX address in the display DMX start address can be changed by pressing the up or the down buttons After pressing the “E”...

  • Page 21: Photometric Data

    4.3 Photometric data - 21 – Version 2.0 November 2008...

  • Page 22: Company And Manufacturer Details

    All illustrations, drawings, and other incorporated media which have been used are subject to the law of copyright. Copyright: alpha one GmbH; 2008 We reserve the right to technical modifications. - 22 – Version 2.0 November 2008...
  • Page 23 - 23 – Version 2.0 November 2008...
  • Page 24 Attachment 3: Handling OSRAM XBO - 24 – Version 2.0 November 2008...
  • Page 25 - 25 – Version 2.0 November 2008...
  • Page 26 - 26 – Version 2.0 November 2008...
