Summary of Contents for geratech EGE-PSW-SCA-844MI
- Page 1 EGE-PSW-SCA-844MI 8×4 Multi-Interface Digital Presentation Scaler...
- Page 3 Geratech Technology assumes no responsibility for any inaccuracies that may be contained in this document. Geratech also makes no commitment to update or to keep current the information contained in this document.
- Page 4 SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
-
Page 5: Table Of Contents
CONTENTS 1. Introduction .................1 2. Applications ................1 3. Package Contents ..............1 4. System Requirements ............1 5. Features................2 6. Operation Controls and Functions ........3 6.1 Front Panel ..............3 6.2 Rear Panel...............4 6.3 Remote Control ..............5 6.4 IR Pin Assignment ............6 6.5 RS-232 Pin Assignment...........7 6.6 RS-232/Telnet Commands ..........8 6.7 OSD Menu ..............10 6.8 Telnet Control ..............13... -
Page 6: Introduction
1. INTRODUCTION This HDBaseT™ capable 8 by 4 Digital Presentation Scaler can switch and scale HDMI/ HDBaseT/PC/Composite Video signals from any one of its eight inputs and simultaneously display it on any of its HMDI or HDBaseT outputs. The unit has and HDMI bypass output, allowing local monitoring of any of the HDMI or HDBaseT inputs, and features full 5play™... -
Page 7: Features
5. FEATURES • HDMI, HDCP and DVI compliant • Full 5Play™ convergence: Video, Audio, LAN serving, Power over Cable (PoC) and Control (IR & RS-232 bypass) • Supports distances of up to 100 meters over industry standard CAT5e/6/7 cable • Supports scaling of any input signals to a wide range of HDTV and PC output resolutions up to 1080p and WUXGA (RB) •... -
Page 8: Operation Controls And Functions
6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel POWER: Press this button to turn ON the device and the LED will illuminated. IR Window: This IR receiver receives only the remote control signal from the packaged included remote control. INPUT HDMI 1~4 & LED: Press the IN buttons to select an input source signal from the 4 HDMI input sources to be display for output ports. -
Page 9: Rear Panel
6.2 Rear Panel IR OUT: Connect to the supplied IR Blaster cable for IR signal transmission. Place the IR Blaster in direct line-of-sight of the equipment to be controlled. IR IN: Connect to the supplied IR Extender cable for IR signal reception. Ensure that remote being used is within the direct line-of-sight of the IR Extender. -
Page 10: Remote Control
INPUT CV: Connect this port to source equipment such as video player or Set-Top-Box for input signal selecting. RS-232: Connect from PC/Laptop for RS-232 command sending to control the device. LAN: Connect from PC/Laptop with active internet service for Web GUI control with RJ- 45 terminated cable. -
Page 11: Ir Pin Assignment
ADJUST: Press this button when output image is not fitting the display's screen perfectly. The device will auto adjust the image to full screen. RESET: Press this button to set the deivice back into the fatory default setting. BYPASS: Press these buttons to select an input source for Bypass output port to display. 6.4 IR Pin Assignment IR Blaster Power... -
Page 12: Rs-232 Pin Assignment
6.5 RS-232 Pin Assignment Scaler Remote Control Assignment Assignment ► ◄ Baud Rate: 19200bps Data Bit: 8 bits Parity: None Flow Control: None Stop Bit: 1... -
Page 13: Rs-232/Telnet Commands
6.6 RS-232/Telnet Commands COMMAND DESCRIPTION S SOURCE 1~8 1=HDMI 1 5=HDBT 1 2=HDMI 2 6=HDBT 2 3=HDMI 3 7=PC 4=HDMI 4 8=VIDEO R SOURCE Reports the numerical equivalent for SOURCE setting (as above) S OUTPUT 0~21 0=640×480 11=1600×1200 1=800×600 12=1920×1080 2=1024×768 13=1920×1200 3=1280×768... - Page 14 COMMAND DESCRIPTION S SHARPNESS Setups the numerical equivalent for 0~30 SHARPNESS setting (as left) R SHARPNESS Reports the numerical equivalent for SHARPNESS setting S NR 0~3 0=OFF 2=MIDDLE 1=LOW 3=HIGH R NR Reports the numerical equivalent for the NOISE REDUCTION setting (as above) S VOLUME 0~100 Volume Value R VOLUME...
-
Page 15: Osd Menu
COMMAND DESCRIPTION PORT 0~8 1=HDMI 2=HDMI 2 3=HDMI 3 5=HDBT 1 6=HDBT 2 4=HDMI 4 8=VIDEO 0=Last Memory 7=PC VOL + Volume Value VOL - Volume Value FW Version & Source Note: 1. Only LPCM 2 channel digital audio is supported, please ensure that the source audio is set to LPCM 2 channel audio in order to avoid unnecessary audio noise. - Page 16 OVER SCAN DISPLAY SIZE FULL FOLLOW INPUT PAN SCAN LETTER BOX UNDER 2 UNDER 1 MODE INFO INFO INPUT HDCP (HDMI mode only) AUTO SETUP Yes/No(No) (PC mode only) H_POSITION 0~60 V_POSITION 0~60 PHASE 0~31 CLOCK WXGA/XGA XGA/WXGA(XGA) RESET Yes/No(No) 0~60(30) COLOR CONTRAST...
- Page 17 0~100(100) AUDIO VOLUME DELAY 40mS 110mS 150mS SOUND MUTE SOURCE AUTO (HDMI mode EXT. only) SETUP FACTORY RESET OSD Setting back to factory default KEY LOCK POWER SAVE DHCP IP MODE STATIC SET STATIC IP IP ADDRESS 0.0.0.0~ 255.255.255.255 (192.168.0.1) SUBNET MASK 0.0.0.0~ 255.255.255.255...
-
Page 18: Telnet Control
6.8 Telnet Control Before attempting to use the Telnet control, ensure that both the Scaler (via the LAN port) and the PC/Laptop or control system being used are connected to the same active network. To access the Telnet control in Windows 7, click on the 'Start' menu and type 'cmd' into the Search field then press Enter (see below for reference). - Page 19 Type '?' to list all the available commands (see below for reference). Note: All commands will not be executed unless followed by a carriage return. Commands are case-insensitive.
-
Page 20: Webgui Control
6.9 WebGUI Control On a PC/Laptop that is connected to same active network as the Scaler, open a web browser and type device's IP address on the web address entry bar. The browser will bring up the control page of the Scaler (see below for reference). Note: The IP address can be obtained from the OSD menu under Information. -
Page 21: Connection Diagram
7. CONNECTION DIAGRAM Set-top Box Router with Internet Blu-ray/DVD Connection Player Active Speakers RS-232 Equipped PC Smartphone Active Speakers or Tablet 100M RS-232 Cable CAT5e/6 HDMI Output Input 100M HDMI DVI to HDMI Output Blu-ray 3D TV/ Player Network Display Router Blu-ray or PS3 3D TV/... -
Page 22: Specifications
8. SPECIFICATIONS Frequency bandwidth Up to 10.2Gbps Input Ports 4 x HDMI 4 x L/R 2 x CAT5e/6/7 1 x PC + L/R 1 x CV+L/R 2 x USB (Service only) 1 x LAN 1 x RS-232 1 x IR Output ports 2 x HDMI 1 x HDMI Bypass... -
Page 23: Input Resolution Support
8.1 Input Resolution Support INPUT RESOLUTION HDMI NTSC/PAL 480i/576i 480p/576p 720p@50/60 Hz 1080i@50/60 Hz 1080p@50/60 Hz VGA@60/72/75 Hz SVGA@56/60/72/75 Hz XGA@60/70/75 Hz SXGA@60/75 Hz UXGA@60 Hz ... -
Page 24: Output Resolution Support
8.2 Output Resolution Support OUTPUT RESOLUTION HDMI 480p/576p 720p@50/60 Hz 1080i@50/60 Hz 1080p@50/60 Hz VGA@60 Hz SVGA@60 Hz XGA@60 Hz SXGA@60 Hz UXGA@60 Hz 1280×768@60 Hz 1280×800@60 Hz 1360×768@60 Hz ... -
Page 25: Acronyms
9. ACRONYMS ACRONYM COMPLETE TERM COMP Component Video Composite Video Digital Visual Interface EDID Extended Display Identification Data HDCP High-Bandwidth Digital Content Protection HDMI High-Definition Multimedia Interface Infrared On-screen Display (Menu) Universal Serial Bus UXGA Ultra Extended Graphics Array Video Graphics Array Extended Graphics Array WUXGA Wide Ultra Extended Graphics Array... - Page 26 www.egerate-store.com...
