Thermco ACC895WRFT Manual

ACC895WRFT
WIRELESS MIN-MAX ALARM THERMOMETER FEATURES
•
3 channels temperature measurement
Internal – Devices ambient temperature
External – Probe with bottle
Wireless – Bluetooth transmitter
• Triple display for current, minimum and maximum
temperature
•
Programmable Low and High alarm limit
•
Ambient/External temperature display
• Wireless temperature display
o o
• C / F exchange
• Low battery indicator
•
Foldaway stand or mounting keyhole
•
FCC, CE, IC and RoHS complaint
INSTALLATION WIRELESS TRANSMITTER
1. Install battery with correct polarity positioning. Diagram of polarity printed on end cap.
2. Press [ ] on the Wireless Transmitter to power on; Blue LED light above power button will flash 5 times.
3. Put the Wireless Transmitter into the area of temperature monitoring. Allow the unit to reach temperature equilibrium of the area to be
monitored before setting Low and High Alarm Limits (approx. 1 hour)
4. Continue to OPERATION for next step.
If you require to turn off your Wireless Transmitter press and hold [
times.
INSTALLATION PROBE
1. Remove protective plastic end from probe sensor connection end and plug into port on side of unit.
2. Turn Thermometer/Receiver over and remove battery cover. Install batteries with correct polarity positioning in Thermometer/Receiver.
Diagram of polarity printed inside battery compartment. Replace battery cover.
3. Put the Probe into the area of temperature monitoring. Allow the unit to reach temperature equilibrium of the area to be monitored
before setting Low and High Alarm Limits (approx. 1 hour)
4. Continue to OPERATION for next step.
OPERATION
Thermometer/Receiver
1. Turn on the
2. Select Celsius or Fahrenheit using
3. Ensure that the Probe/Wireless Transmitter is in the area of temperature monitoring and has equilibrated prior to setting Low and High
Alarm.
LOW AND HIGH ALARM LIMIT SETTING
1. Press [MODE] to enable alarm limit setting.
Press [LO ↑] to set low alarm limit. * Holding down the button will increase the value automatically. If you missed desired temperature,
continue holding button while temperatures cycle again. You can also press the button to increase by a single degree slowly.
Press [HI ↑] to set high alarm limit. * Holding down the button will increase the value automatically. If you missed desired temperature,
continue holding button while temperatures cycle again. You can also press the button to increase by a single degree slowly.
**If you select LO/HI parameter for a Probe/Wireless Transmitter that exceed your parameters the thermometer will alarm immediately.
2. Press [MODE] to return to NORMAL <Current/Min/Max> display mode.
3. When the current reading is lower or higher than the alarm limits the alarm will sound and a red LED light will flash at the bottom right of
the unit.
4. To stop the alarm sound, press any button once. The LO or HI icon will still be flashing until the current reading is within the alarm limit.
Press [LO ↑] and [HI ↑] simultaneously to turn off the LED.
5.
Press [ ] to enable alarm function
RESET MINIMUM (MIN) AND MAXIMUM (MAX) READING MEMORY
1. In MIN-MAX display mode, press [Min-Reset] to reset minimum reading memory to current temperature reading.
2. Press [Max-Reset] to reset maximum reading memory to current temperature reading.
3.
Reset the memory once after viewing/documenting new Minimum or Maximum readings to begin new data cycle
AMBIENT/EXTERNAL WIRELESS SENSOR TEMPERATURE DISPLAY
Press [AMB/EXT/WIRELESS] to select AMB, EXT, or Wireless []
*When powering up, displays Ambient.
using On/Off switch on the back of the unit.
o o
C / F button on the back of the unit.
.
] temperature display.
] for 3 seconds; Blue LED light above power button will flash 2
.
