Forest garden LOG STORE Manual

1762
Thank you for choosing this product manufactured by the UK's largest manufacturer of timber garden products. In order to gain the most benefit from it, please note the following:
- Exercise particular care and follow instructions.
- This product is pressure treatedto ensure longevity of all components and to protect against rot. This may leave a colour difference as on some parts as that will even out as the
moisturte content stabilises. For extra protection from the elements we recommend that you treat your structure using a wood preservative treatment. Apply in accordance with the
manufacturers instructions.
- In line with your statutory rights, please check all parts prior to assembly, as assembly of damaged parts may be deemed to be acceptance and this may affect the remedies you are
entitled to. If the product is not constructed in accordance with the instructions, or is altered in anyway (eg painted), the manufacturer cannot be held liable for any resulting damage
- Please keep all plastic bags and small parts away from children in order to reduce the risk of suffocation.
- Important Note : Do not lean or stand on roof during assembly this is not a load bearing.
- If there are any technical queries with the product, please contact our customer help line on 0333 7777 089 between the hours of 8.30 am and 5.00 pm Monday to Friday.
LSLHS
(Log Store Left Hand Side)
(Log Store Right Hand Side)
ELSRHS
(Economy Log Store
Right Hand Side)
1
IMPORTANT, RETAIN FOR FUTURE REFERENCE :READ CAREFULLY
1155
(Log Store Floor)
LSRHS
137161762PTR (Large Board) Qty 6
ELSLHS
(Economy Log Store
Left Hand Side)
L S
OG TORE
912mm
MUST PRE DRILL
LSFLR
(Large Log Store Floor)
For LGLOGSTORE
For LOGSTORE
137161155PTR (Board) Qty 6
137160912PTR (Board) Qty 5
Place the left hand side on
to the floor short side as
shown and secure using
2x50mm screws, screwing
into the batten
underneath.
Repeat this step with the
right hand side.
LOGSTOREFP
LGLSFLR
(Economy Log Store Floor)
LSROOF (Log Store Roof)
LGLSROOF (Large Log Store)
ELSROOF (Economy Log Store)
REQUIRED TOOLS : (NOT SUPPLIED)
DRILL
POZI DRIVE SCREWDRIVE
TAPE MEASURE
LOGSTOREFP
FIXING PACK
24
30mm
22
Issue 0116
JE
ELSFLR
R
8
50mm
