LOXONE Music Server Quick Start Manual

Advertisement

Loxone
Music Server
Quick Start Guide
www.loxone.com
[A] HARDWARE INSTALLATION
[1] Plug an Ethernet cable from your Router or
Network switch, into the Ethernet port at the
back of the Music Server.
[2] Plug one of the included audio cables from the
Music Server to the Amplifier (3.5mm Jack to
RCA cable).
[3] If required, connect the Trigger Outputs from
the Music server to the Line input of your
Amplifier (3.5mm to 3.5mm cable). The outputs
of the Music Servers are as follows:
[4] (Optional): Manual Setup Page: You can con-
figure the network settings directly on your
Music Server by connecting a USB mouse,
keyboard and monitor.
[5] Plug the power supply into the jack at the rear
of the Music Server.
[6] Start your Music Server by pressing the power
button.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Music Server and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for LOXONE Music Server

  • Page 1 Music Server to the Amplifier (3.5mm Jack to RCA cable). [3] If required, connect the Trigger Outputs from the Music server to the Line input of your Amplifier (3.5mm to 3.5mm cable). The outputs of the Music Servers are as follows:...
  • Page 2 2 – Click on the Loxone Music Server 3 – Click on the “Configure” button 4 – Set a static IP Address for the Music Server by selec- ting “Use the following address” and entering the new IP Address details for the Music Server.
