KAEL CON-3 Quick Start Manual

CON-3
(Rechargable)
USB – infrared
Data Loader

Astro PC Software installation

1. Insert Kael Astro installation disc into the CD-ROM and double-click 'setup.exe' to start the installation.
2. After starting the installation,
the welcome pane appears.
Please click the 'Next' button.
Mostly, it is difficult to program an astronomical time relay because of the
complicated menus.
Astronomical time relay that KAEL has developed, could be programmed
easily with using CON-3 device.
There is a rechargable battery (LIR2032) in CON-3.
For charging the battery, CON-3 must be plugged into the USB port and
the switch at the bottom must be turned on.
It is recommended to turn off the switch, if the battery level is sufficient.
NOTE: Even if the key is in OFF position, Real Time and Date of CON-3 will
continue to run.
The switch controls only charging the battery (Enable/Disable).
Preperation to Use:
- Turn on the switch.
- Plug CON-3 into the USB port on your computer.
- Run ASTRO Software. A battery charge indicator appears in the lower right
of screen. After complition of charging it disappears.
- Make the program for your needs.
- Load the program into CON-3.
- Unplug CON-3 from the computer.
Energize the astronomical time relay that you want to program and point
CON-3 towards the device. Press 'Load' button.
While transferring the data 'CON-3' appears and two circles spin on the
screen of the device. After finishing the data transfer, 'IR OK' appears
on the screen.
