- Page 1 BBQ MODULE (ALL SIZES) ASSEMBLY INSTRUCTIONS For further instruction, please visit: www.alfrescoplus.com.au...
-
Page 2: What's Needed
Essential TIP: Ensure you have a stable flat surface or workbench to work from. The most ideal height to assemble the module is waist height. The workbench should be at least 1.8m (W) x 1m(H) x 0.7m(D) in size. ALFRESCOPLUS™... -
Page 3: What To Do Next
WHAT TO DO NEXT? Remove all parts from the cartons. DO NOT unwrap the frames at this stage. Preparing the panels: • Remove all the white panels from the carton and place in an easily accessible location. (All red arrow labels to face upwards). - Page 4 ASSEMBLED VIEW OF FRAMES & PANELS FIG. 2 FIG. 3 FIG. 4 FIG. 5 ALFRESCOPLUS™...
- Page 5 At this stage your progress should look like FIG 6. FIG. 6 ASSEMBLY TOP BOTTOM & BACK FIG. 7 BBQ MODULE (ALL SIZES) ASSEMBLY INSTRUCTIONS...
- Page 6 FIG. 8 FIG. 9 At this stage your progress should look like FIG 10. FIG. 10 ALFRESCOPLUS™...
- Page 7 ASSEMBLING SIDE & CENTRE WALLS FIG. 11 FIG. 12 FIG. 13 BBQ MODULE (ALL SIZES) ASSEMBLY INSTRUCTIONS...
- Page 8 FIG. 14 FIG. 15 ALFRESCOPLUS™...
- Page 9 ASSEMBLING PLINTH FEET & KICKER PLATE No Allocating holes are used for plinth feet since the inside frame edge provides the guide. Place Plinth foot into corner of cabinet frame. Screw down with screws provided. If easier, remove plinth shaft from baseplate then screw down base plate first. If desired move the front two plinth feet further back to create a deeper kick-plate position.
- Page 10 Please take note that the Kick plate provided is reversible, thereby giving you the choice between a black “shadow line” finish or stylish silver finish. The Kick plate Biscuit is used to connect onto more than one cabinet, thereby aligning the kick plate. FIG. 18 FIG. 19 FIG. 20 10 | ALFRESCOPLUS™...
- Page 11 Choose the desired color face of kick plate. (Silver or Black). No pre drilled holes are possible due to this color choice. Self tapping screws are provided to attach the spring clip plate to the kick panel. The dimensions below can be used as a guide only since the position of the plinth foot and the desired...
- Page 12 • Attach all four-hinge plates when attaching two doors. Attach the two-left hinge plates when attaching a single door. Attach provided Hinge Plate x 4 and self tapping screws. FIG. 23 Illustration on attaching hinges to door panels by using the self-tapping screws provided. FIG. 24 12 | ALFRESCOPLUS™...
- Page 13 * Detailed INSTRUCTIONS on how to clip on the doors using clip-on-hinges. Clip On Hinge Instructions: Clamp hinge on to the mounting plate as shown by direction arrow Press down the hinge arm to lock the plate as shown The door can be quickly removed by pushing the button Unclipping the door from the mounting plate leaves all adjustments analtered...
- Page 14 Make sure the cabinets are leveled and aligned, ready to be connected by barrel bolts. Please note the biscuit inserted into the kick plate provided, ensure the kick plate is aligned ready to be connected. FIG. 28 FIG. 29 14 | ALFRESCOPLUS™...
- Page 15 Insert the “biscuit” connection part into the slot that is pre cut. If required, gently tap into place with soft sided hammer. FIG. 30 Diagram using the Allen key provided to fasten cabinets using the barrel bolts. FIG. 31 Joining the Cabinet with Barrel Bolts Cabinet Joined with Barrel Bolts | 15 BBQ MODULE (ALL SIZES) ASSEMBLY INSTRUCTIONS...
- Page 16 Figures 32, 33 and 34 illustrate the cabinets and kick plate aligned and joined. FIG. 32 FIG. 33 FIG. 34 Note: The door is not shown in some images to illustrate the cabinet connection method more clearly. 16 | ALFRESCOPLUS™...
- Page 17 ASSEMBLING THE AIRFRAME HEAT-SHIELD Insert the pre-assembled vertical side shields onto the horizontal bottom heat shields by pressing firmly into pre inserted prongs. The infill panel should still remain loose at this point. Note: The Prong in the horizontal heat shield will fit into the frame firmly, however can be removed again.
- Page 18 18 | ALFRESCOPLUS™...
- Page 19 Gently place the airframe heat shields on top of the BBQ Module. Please note there are no joining bolts or screws required to fit into place. The airframe will be firmly attached by making use of the barrel bolts provided, to join to the cabinets or end panels directly adjacent to the airframe.
- Page 20 FIG. 38 Attach the joining screw bolt through the pre-drilled holes provided. Make use of the allen keys provided. Do not over tighten. FIG. 39 FIG. 40 Step 1: Insert shoulder screws halfway. 20 | ALFRESCOPLUS™...
- Page 21 FIG. 41 FIG. 42 Step 2: Lower Infill Panel onto Shoulder Screws and tighten (Do not over tighten). Your progress should resemble the below diagram 43 at this point. FIG. 43 | 21 BBQ MODULE (ALL SIZES) ASSEMBLY INSTRUCTIONS...
- Page 22 The BBQ module and Airframe heat shield is now assembled and ready to be joined with other modules. Please refer to the more detailed instructions labeled “Attaching and leveling the modules”. FIG. 44 The BBQ module can be aligned and joined with the barrel bolts provided. FIG. 45 22 | ALFRESCOPLUS™...
- Page 23 ASSEMBLING & ATTACHING THE END PANELS Remove the panel and frame from the carton and choose which side of the panel needs to face towards the outside which should be the same color as the doors chosen (The panel is reversible depending on color chosen). End Panel Attachment Plate FIG.
- Page 24 Remove the four Small screws from the Take long screws and align the end panel Aluminum frame surrounding the stone frame and module, screw into stone top top. frame to anchor the end panel. FIG. 49 FIG. 50 24 | ALFRESCOPLUS™...
- Page 25 FIG. 51 Ensure screws are flush with the frame after screwed into place. | 25 BBQ MODULE (ALL SIZES) ASSEMBLY INSTRUCTIONS...
- Page 26 FIG. 52 FIG. 53 FIG. 54 FIG. 55 Align, Insert and Tighten the Barrel Bolts Please Note there are two Barrel Bolts with the Alen key Provided. that needs to be inserted and tightened, front and back. 26 | ALFRESCOPLUS™...
- Page 27 Remove red double sided tape from frame and align panel, ready to stick onto frame. FIG. 56 Your panel should resemble the diagram below. Please press onto all edges firmly to ensure that the double sided adhesive tape permanently attaches the panel to the frame. FIG.
- Page 28 ATTACHING DIRECTLY TO THE AIRFRAME SIDE PANEL FIG. 58(A) FIG. 58(B) 28 | ALFRESCOPLUS™...
- Page 29 HOW TO INSTALL A DOOR HANDLE Take note that the door handles can be placed vertically or horizontally as preferred by you. Remove the Double sided Tape from the inside of the handle. Ensure you align the edge of the handle to the edge of the door before touching the tape to the door panel.
- Page 30 For any queries or assistance call: Customer Service Austalia Only 1300 174 876 Hours of operation: Monday to Friday 8am - 5pm Do not return to place of purchase Keep your purchase receipt, this will be required to make any claims under the 12 month warranty...
