Summary of Contents for SHENZHEN NEWCT TECHNOlLOGY HUIYOU-19
-
Page 2: Table Of Contents
CONTENTS 1.Introduction..........1.1 About HUIYOU-19......2 1.2 System requirements......2 Package Contents......2 Pressure pen............3 2. Installation........... 2.1 power＆Signal connections....5 2.2 Tablet software Installation ....5 OSD KEY ＆Display Stand......3.1 OSD KEY.........13 3.2 LED........14 3.3 Display Stand......14 3.4 MENU Description......15 4.Specifications..........5.Trouble Shooting........ -
Page 3: Introduction
1.Introduction 1.1 About HUIYOU-19 This product is a high quality, high Thank you for choosing HUIYOU-19. resolution, low radiation, low power consumption LCD digital screen This product is integrated LED tablet designed for direct on screen interface with your computer。... -
Page 4: Pressure Pen
·1*DC 12V Adapter ·1*CD ·1*Pen Holder（contains pen Nibs and clipper） ·1*User English Manual ·1*VGA cable 1.4 Pressure pen This display includes a rechargeable pressure pen for pen input. The pen stylus must be charged before use. ① Checking Charge Status ·Tap the tip on a desk or other surface to turn the pen on. - Page 5 positioned in the notch on one side of the opening. Squeeze the pen tip removal tool to firmly grasp the pen tip. ·Open the Pen Holder ·Remove the Pen Tip ·Replacing the Pen Tip 第 4 页 共 18 页...
-
Page 6: Installation
2. Installation power＆Signal connections Attention：Be sure both of your computer and the tablet monitor are power off. ① Connect the power cord to the AC outlet， and connect the power with the tablet monitor through the AC/DC（12V）adapter. ② Plug one end of the VGA at the rear of the PC system and the other end of the VGA port of monitor.Secure the connects with the screws on the cable connector on both ends. - Page 7 operation. Reboot your computer after uninstalling the driver(s). ② Insert the included CD-ROM disc into the optical drive on your computer.open File Explorer, locate the “Setup.exe ” file on the CD, and double click the file to launch the setup program. 2.2.2 Tablet Driver setting on the Windows Click on the tablet icon the bottom right of the tool bar to enter...
- Page 8 ②Monitor Setting 第 7 页 共 18 页...
- Page 9 ③Pen Button Setting 第 8 页 共 18 页...
- Page 10 ④Pressure Setting 第 9 页 共 18 页...
- Page 11 ⑤Calibration 第 10 页 共 18 页...
- Page 12 2.2.3 Mac OS Insert the included CD-ROM disc into the optical drive on your computer. Open the CD -ROM and find a file named MPKG in the Mac driver directory. （Prior to installing the driver, uninstall any pen or tablet software and drivers that you may have previously used on this computer.
- Page 13 ②Pen button setting ③ Calibration 第 12 页 共 18 页...
-
Page 14: Osd Key ＆Display Stand
3.OSD KEY ＆ Display Stand 3.1 OSD KEY The monitor's controls are on right of the display bezel. The five buttons have the following functions: ①: Press switch to turn the power on of off. ②：When OSD M（MENU）is off, is the hot key to access OSD M （MENU）... -
Page 15: Led
3.2 LED Color Status Green Power on No Signal — Power off 3.3 Display Stand Adjusting the Display Stand level” ： To adjust the tablet monitor in an optimum tilt position for different applications。 第 14 页 共 18 页... -
Page 16: Menu Description
MENU Description Picture 【Brightness】：adjust the screen brightness 【Contrast】：adjust the screen contrast 【Clock】：adjust the horizontal size of the display 【Phase】：adjust the phase of the display 【H.position】：position the display along the horizontal axis of the screen 【V.position】：position the display along the vertical axis of the screen 【colour TemP 】：adjust the color Temperature OSD setting 【OSD Time Out】:set the OSD time out... -
Page 17: Specifications
4.Specifications Item Specifications Display Area 402*255mm Resolution 1440*900 317.56 × 429.19 × 51.60 mm Dimension Response Time 14ms Pixel pitch 0.17925*0.17925 Support color 16.7M Contrast radio 800:1 Brightness 250cd/㎡ Viewing angle -80°-80°（H）/-80°-80°（V） environment Operating temperature 0℃-50℃ Storage temperature -20℃-50℃ Humidity Operating temperature 20 ~80%RH, non-condensing Storage temperature 20~90%RH,non-condensing... - Page 18 NO Signal ·Check that the brightness or contrast control is at the appropriate position.Not at the minimum。 ·Check to make sure the signal cable is firmly is seated in the socket. The screen is not synchronized ·Make sure the signal timings of the computer system are with the specification of the monitor.
- Page 19 SHENZHEN NEWCT TECHNOlLOGY CO., LTD. TEL：（0755）27658847 FAX:（0755）27618070 ：http://www.shouxieping.cn website http://www.shouxieping.net address:TianHao Technology Park,JingBei village, Shiyan Lake,Shiyan Town,Baoan District , Shenzhen, China 第 18 页 共 18 页...
