1. Product Name
Nostalgia Music Centre
2. Product Code
20525
3. Colour
Natural wood finish
4. Brief Description
It may look like something from the past but its features are contemporary!
Features: 33/45/78 rpm turntable, draw loading CD player, MW‐FM Stereo Radio, Cassette
Player, Line Out Socket and Line In Socket.
5. Contents
• 1 x Nostalgic Music Centre
Advertisement
Table of Contents
Summary of Contents for Rompa Nostalgia Music Centre
- Page 1 1. Product Name Nostalgia Music Centre 2. Product Code 20525 3. Colour Natural wood finish 4. Brief Description ...
-
Page 2: Detailed Description
6. Snoezelen® Stimulations • Sound 7. Best Use Use indoors in a quiet environment. 8. Compatible ROMPA® Products See www.rompa.com for an extensive range of CDs. 9. Starting Up • Plug in. • Use the Function Knob (1) to play desired music. 10. Detailed Description It may look like something from the past but its features are contemporary! Features: 33/45/78 rpm turntable, draw loading CD player, MW‐FM Stereo Radio, Cassette Player, Line Out Socket and Line In Socket. Mains operated. Oak‐look finish. Model may vary slightly subject to availability. ... - Page 3 Front Controls 1. Function knob for CD / PHONO / RADIO / TAPE / LINE‐IN 2. Tuning Knob 3. Power ON / OFF VOLUME Knob 4. 3.5mm LINE‐IN Jack 5. CD Door OPEN / CLOSE Button 6. STOP Button 7. PLAY / PAUSE Button 8. FOLDER + REPEAT Button 9. CD Drawer Door 10. CD LCD Display 11. PROGRAM Button 12. F.SKIP Button 13. B.SKIP Button 14. Earphone ‘PHONES’ Jack 15. AM / FM Band Switch 16. Lid 17. Dial Scale ...
- Page 4 Turntable RCA (L / R) LINE‐OUT Jack AC Mains Cord Fm Wire Antenna 21. Turtable Platter 26. Auto / Manual Stop Selector 22. Turntable Spindle Switch 23. 45rpm Spindle Adaptor 27. Turnable Tone Arm 24. Cue Lever 28. Tone Arm Lock / Arm Rest 25. 33 , 45 and 78rpm Selector ...
- Page 5 Side Panel 31. Speaker 32. Cassette Slot 33. Cassette Eject / F. Forward Button CD FUNCTION CD Playback The CD Player can play normal audio CDs as well as MP3 CDs. 1. Turn the Function Knob (1) to CD, then press the Open / Close Button to open the CD Drawer. 2. Place a pre‐recorded CD into the CD tray. Press the Open / Close Button again to close the CD door. The CD LCD Display will show the total number of tracks on the CD. The CD will start automatically playing from the first track. 3. Press the Play / Pause Button (7) to pause the CD. The LCD Display will flash. 4. Press the Play / Pause Button (7) to resume playback. 5. Press B.Skip (13) or F.Skip (12) to select a particular track. 6. Press the Stop Button (6) to stop playback. Repeat Playing Function Press the Repeat Button (8) once to repeat a single track and press once more to repeat all tracks. Press it again to cancel the repeat function. Programming Function To program the tracks, press the Program Button (11), then press the B.Skip Button (13) or F.Skip Button (12), then press the Program button to save into the memory. Up to 20 tracks can be programmed into memory. ...
-
Page 6: Auto Stop Function
RADIO / TUNER FUNCTION 1. Turn the Function Knob (1) to Radio. 2. Select the Am / Fm channel by sliding the Am / Fm Slide Switch (15) to the desired band. 3. Use the Tuning Knob (2) to select a radio station. 4. Reposition the Music Centre or extend the FM wire antenna (20) as necessary to obtain a better reception. PHONO FUNCTION 1. Turn the Function Knob (1) to Phono. 2. Remove any packaging from the Turntable. 3. Remove the plastic protective cover (30) from the stylus (29) and unlock the Tone Arm (27) by releasing the Lock Clip (28). 4. Place your record onto the turntable platter (21). 5. Select the turntable speed by sliding the 33 / 45 / 78rpm switch (26) on the right side of the turntable. 6. Lift up the Tone Arm, move it towards the rotating turntable and gently place it over the record where you wish it to start playing. 7. Lower the Tone Arm with the Cue Lever (24). If you want to stop the record playing, lift up the Tone Arm with the Cue Lever and place it back on the Arm Rest (28). AUTO STOP FUNCTION 1. If you want the turntable mechanism to stop automatically at the end of the record, ensure the Auto Stop Switch (26) is in the ON position. 2. If a record stops playing before the end of the record, switch the Auto Stop Switch to the OFF position. The turntable mechanism will continue to spin and the record will ... -
Page 7: Technical Specification
CASSETTE FUNCTION Playing A Tape The Cassette Player can play back normal length Cassette tapes (80 minutes). 1. Turn the Function Knob (1) to Tape / Line In, then insert a cassette tape into the cassette slot on the side panel (32), ensuring it is inserted correctly. 2. Push the cassette tape in and it will automatically start playing. 3. Press the Eject Button (33) gently to skip forward and fully press this button to eject the tape. Note: Make sure the direction is correct when inserting the tape. Some searching noise will be heard – this is normal. Remove the tape after each use. 11. Safety • Always supervise the use of this product. • For use indoors, in dry environments only. • Do not put anything on top of the Music Centre and allow plenty of ventilation around it. ... -
Page 8: Care And Maintenance
14. Care and Maintenance Do not attempt to remove the cover or access the interior of this product. There are no user‐serviceable parts inside and the lamps are soldered into place. Only a suitably qualified person should service this product. Once this product is eventually exhausted, please dispose of it appropriately. Compact Disc Care To remove a disc from its storage case, press down on the centre of the case and lift the disc out, holding it carefully by the edges. Fingerprints and dust should be carefully wiped off the disc’s surface with a soft cloth. Wipe in a straight line from the inside to the outside of the disc. Clean the disc periodically with a soft, lint‐free, dry cloth. Never use detergents or abrasive cleaners to clean the disc. Do not fix labels to the surface of the discs or write on them except with specialist CD‐R pens. ... - Page 9 Care and Maintenance (continued) Cassette Care Two common causes of trouble experienced when using cassettes are: a. Tape jamming, leading to uneven speed during playback. b. Tape entangling, when the tape wraps itself around vital parts of the mechanism. To avoid these problems occurring, take the following precautions: • Check that there are no loose layers of tape visible through the cassette centre window (see below) • Take up any loose layers, using a pencil or hexagonally barrelled ballpoint pen, before inserting the cassette (see below) ...
- Page 10 Care and Maintenance (continued) Stylus Replacement/Refit To remove the Stylus from the Tone Arm, hold the Tone Arm head steady while grabbing the red plastic Stylus holder with two fingers then gently pull the complete stylus holder straight towards you and off the silver cartridge, as shown. ...
- Page 11 Care and Maintenance (continued) Re‐attaching the Turntable Drive Belt This is supplied fitted ‐ follow the steps below if this fails to revolve. STEP 3 To fix the turntable back onto the phonograph mechanism, make sure the column point is positioned over the correct place on the phonograph ...
-
Page 12: Troubleshooting
In the unlikely event of product failure, please check the following: Problem: No power going in • Check that the product is plugged in correctly • Check the product is switched ON Problem: No sound • Check volume level (3) • Check you haven’t left any Headphones plugged in (14) Problem: Turntable will not work • Make sure unit is set to PHONO mode (1) • Make sure the Turntable Drive Belt has not come off Problem: Turntable will not play some records to the end • Switch the Auto Stop Switch (26) to OFF, but remember to switch it back to ON if you wish the auto stop function to work for other records Problem: The Tone Arm does not go down onto the record • Lower the Tone Arm with the Cue Lever (24) Problem: The Record Player Tone Arm slides across the record • Make sure the white protective needle cover has been removed • Check the stylus is not damaged or missing Problem: My 45rpm ‘Singles’ do not fit on the turntable platter • If the centre clip is missing from the single, place the 45rpm spindle adapter on the turntable spindle first before placing the record on it Problem: The CD Drawer does not open • Check the product has been switched on • Check the Function Knob (1) has been set to CD Problem: The cassette is not playing • Check the Function Knob (1) has been set to Tape/Line‐In and that the cassette has been put in properly Problem: The Radio Reception is not good • Re‐position the product or for FM radio extend the FM wire antenna on the rear NOSTAGIA MUSIC CENTRE 20525, December 2012 Copyright ROMPA®Ltd ...
