- Page 1 Serial Flash Programmer SFWv3 S550- FA Mode Operation Manual Sunny Giken Inc. 2 0 / 1...
- Page 2 S550-SFWv3 FA Mode The contents of this manual may be revised without notice. We, Sunny Giken Inc. shall not be responsible for any damages and/or losses caused by using this product and/or the software attached to this product claimed by users and/or any intermediaries.
-
Page 3: Table Of Contents
Table of Contents Outline ..........................................3 1.1 Introduction ........................................3 1.2 Precautions ........................................3 S550-SFWv3 FA Mode Configurations ..............................4 2.1 General Specifications ....................................4 2.2 S550-SFWv3-XFA1 External Appearance ............................6 2.3 Terminal Block Specifications ................................. 7 2.4 Internal Interface Circuits ..................................9 2.5 Remote Control Timing ..................................... -
Page 4: Outline
Please read this operation manual carefully to understand the functions of this product for effective operations. Please beware that Sunny Giken Inc. shall have no liability for any damages and/or troubles caused by misuse or careless handling of this product. In addition, note that have been described in the "2.3 Terminal Block Specifications" when using terminal block. -
Page 5: S550-Sfwv3 Fa Mode Configurations
S550-SFWv3 FA Mode Configurations This chapter describes the entire system configurations of S550-SFWv3 FA Mode. S550-SFWv3 FA Mode is composed of S550-SFWv3 and S550-SFWv3-XFA1. 2.1 General Specifications Device Configuration Target Cable FA device Host PC Windows XP S550-SFWv3 XFA1 S550-SFWv3... - Page 6 ・Connector (S550-SFWv3 Main Unit FA Mode) A connector part appears when the cover on the right side of S550-SFWv3 is removed. Please remove the cover when the power supply doesn't enter the entire system (S550-SFWv3-XFA1, S550-SFWv3, target board and FA equipment).
-
Page 7: S550-Sfwv3-Xfa1 External Appearance
Status indicating LED Functions Lights up when the input signal from the FA device is “L”. IN1, IN2, IN3, IN4 Lights up when the output signal from S550-SFWv3-XFA1 is “L”. OUT1, OUT2, OUT3, OUT4 Terminal block/Connector Functions Use this when connecting to the FA device. -
Page 8: Terminal Block Specifications
*Note that signal names and directions are the ones seen from the S550-SFWv3-XFA1 side. *Pulling up all the output signals on the S550-SFWv3-XFA1 side on the FA device is recommended. * All the input-and-output H levels are the power supply of I/O side. - Page 9 ・Note 1) Connect/remove the electric wire after turning off the power supply of the entire system(S550-SFWv3-XFA1, S550-SFWv3, target board and FA equipment). There is danger of breaking down when the power supply of the entire system is not turned off.
-
Page 10: Internal Interface Circuits
2.4 Internal Interface Circuits Following illustrates the internal interface circuits of S550-SFWv3-XFA1. Internal Circuit Terminal Block 端子台 12V/24V 12V/24V 12V/24V 内部回路 12V/24V 100K 12V/24V 100K OUT1 OUT2 OUT3 OUT4 S550-SFWv3 FA Mode Operation Manual... -
Page 11: Remote Control Timing
REMOTE ① While Stand-alone (a) The REMOTE signal becomes “H” when S550-SFWv3 is not connected or is turned on. (b) After the start up, the REMOTE signal becomes “Ｌ”. (“H”, when data is not downloaded.) (c) The REMOTE signal becomes “H” when S550-SFWv3 is disconnected or settings are initialized. - Page 12 (d) The BUSY signal becomes “H”, 1ms after the result output. (e) For the FA device, switch back the START signal to “H” after the BUSY signal completion. (f) Please start the next sequence, at least 100ms after the START signal becomes “H”. S550-SFWv3 FA Mode Operation Manual...
- Page 13 (b) The result is output (FAIL signal “L”) when programming is canceled. * Cancellation corresponds to programming error. (c) The BUSY signal becomes “H”, 1ms after the result output. (d) Please start the next sequence, at least 100ms after the START signal becomes “H”. S550-SFWv3 FA Mode Operation Manual...
- Page 14 ・ Do not select the data that is not set in the S550-SFWv3 main unit. The data is not switched when selecting it. ・ The CONFIRM/SEL0/SEL1 signal is invalid in the single data mode. (See the timing when single data mode is selected.)
- Page 15 (j) The BUSY signal becomes “H”, 1ms after the result output. (k) For the FA device, switch back the START signal to “H” after the BUSY signal completion. (l) Please start the next sequence, at least 100ms after the START signal becomes “H”. S550-SFWv3 FA Mode Operation Manual...
- Page 16 (b) The BUSY signal becomes “H”, 1ms after the result output. (c) For the FA device, switch back the START signal to “H” after the BUSY signal completion. (d) Please start the next sequence, at least 100ms after the START signal becomes “H”. S550-SFWv3 FA Mode Operation Manual...
- Page 17 (b) The result is output (FAIL signal “L”) when programming is canceled. *Cancellation corresponds to programming error. (c) The BUSY signal becomes “H”, 1ms after the result output. (d) Please start the next sequence, at least 100ms after the START signal becomes “H”. S550-SFWv3 FA Mode Operation Manual...
-
Page 18: Remote Programming
③ Connect PC and S550-SFWv3 with a USB cable. *Check if the START signal is set to “H”. ④ Connect S550-SFWv3 and the target board with the target connecting cable. * When the consumption current of the target board exceeds 200mA, supply from an external power supply. -
Page 19: Data Settings
① Start up the control software Start up the control software. The main screen appears. When the control software is started, the switches on the S550-SFWv3 main unit become invalid. Also, the REMOTE signal becomes ”H”. S550-SFWv3 FA Mode Operation Manual... - Page 20 When multi data mode is selected, you can switch among the data 1 through 4. Note that remote programming is disabled in multi data mode. *For the S550-SFWv3 main unit, FA mode setting becomes valid after downloading. S550-SFWv3 FA Mode Operation Manual...
- Page 21 ③ Device settings Click the “Target Project” button. Following screen appears. On this screen, you can specify settings of the programming data. For details of settings, see “S550-SFWv3 Operation Manual”. S550-SFWv3 FA Mode Operation Manual...
-
Page 22: Downloading
① Download device settings After device settings, click the “Program” button. The settings are downloaded to the S550-SFWv3 main unit and the screen moves to the programming execution screen. *When the FA mode is selected in the maintenance screen, [FAmode] indication appears on the main screen. -
Page 23: Remote Programming
The REMOTE signal becomes “L” when the screen moves to the execution screen. The remote control by the FA device becomes enabled. *When the FA mode is selected in the maintenance screen, [FAmode] indication appears on the main screen. S550-SFWv3 FA Mode Operation Manual... - Page 24 ② Start programming Switch the START signal to “L” from the FA device and the programming is started. *While programming, switch the START signal to “H” to cancel programming. S550-SFWv3 FA Mode Operation Manual...
- Page 25 ③ Programming complete You can proceed to the next programming. S550-SFWv3 FA Mode Operation Manual...
-
Page 26: Stand-Alone Programming
Stand-alone Programming The following procedures show how to connect and operate for stand-alone programming. 4.1 Connecting Steps (Downloading) ① Connect PC and S550-SFWv3 with a USB cable. Host PC Windows XP USB2.0 High-Speed 4.2 Data Settings See “3.2 Data Settings”. -
Page 27: Downloading
4.3 Downloading ① Download device settings After device settings, click the “DownLoad” button. The settings are downloaded to S550-SFWv3. ② Downloading complete Exit from the control software. Disconnect PC from S550-SFWv3. S550-SFWv3 FA Mode Operation Manual... -
Page 28: Connecting Steps (Stand-Alone Programming)
4.5 Stand-alone Programming ① Complete programming preparation When the FA mode is set, “F.A” is indicated on the 14SEG LED of the S550-SFWv3 main unit immediately after the start-up. The REMOTE signal becomes “L” and the remote control by the FA device becomes enabled. -
Page 29: External Dimensions
External Dimensions 5.1 S550-SFWv3-XFA1 Main Unit Unit: [mm] S550-SFWv3 FA Mode Operation Manual... -
Page 30: When Placed On The Fixed Base
5.2 When Placed on the Fixed Base φ3.5穴 Unit:[mm] S550-SFWv3 FA Mode Operation Manual... -
Page 31: Troubleshooting
If lighted, check the BUSY signal connection. ・Is the OUT1(REMOTE) status LED lighted? If not lighted, the settings of S550-SFWv3 may not be done properly. Download the programming data with the control software again. If the control software is started, and the screen other than the programming execution screen is displayed, the START signal will not be accepted. - Page 32 ・ The figure of “Start-up timing “ is corrected. “2.5 Remote Control Timing” Rev.E 2014/07/11 ・ The table of “Data setting information “ is corrected. “2.5 Remote Control Timing” Rev.F 2020/01/10 ・ The figure and explanation about starting the next sequence is corrected. S550-SFWv3 FA Mode Operation Manual...
- Page 33 Serial Flash Programmer [S550-SFWv3 FA Mode] Operation Manual Date of Issue : August, 2010 First edition January, 2020 (Rev.F) Publisher : SUNNY GIKEN INC. Publishing office : 3-1-9 Nishidai, Itami, Hyogo Japan 664-0858 E-mail ： info@sunnygiken.co.jp ©2010-2020 Sunny Giken, Inc. All rights reserved.
