--CHARGING--
Charge DVR with USB wall charger
for approximately 2 hours. If your
DVR has the extended battery
installed, charging time can take
up to 3 hours.
Charge Shockbox with unique 4
pin connector style charger by
plugging into the back of the
Shockbox shell connector. The
LED on the charger will start out
RED and turn GREEN after
approximately 2 hours when the
Shockbox is fully charged. The
car charger with wall adapter takes
approximately 4 hours to fully
charge
Advertisement
Summary of Contents for MOTOCAM 360 Shockbox
- Page 1 2 hours. If your DVR has the extended battery installed, charging time can take up to 3 hours. Charge Shockbox with unique 4 pin connector style charger by plugging into the back of the Shockbox shell connector. The...
-
Page 2: Dvr Controls
The MotoCam DVR SD card limitation is 4GB, and the DVR does not recognize the newer “HC” format. Remove DVR from Shockbox Shell. This step should be followed every time the DVR is powered up. If this step is skipped, the DVR may power up and turn off the LCD screen in preparation for TV playback. - Page 3 Power up DVR by holding “POWER/REC” for 2 seconds. 2) Configure DVR by entering the “Setup” mode and adjusting each of the values listed below: Disable Auto Off Feature: Format SD Card in the DVR: Formatting should always be done in the DVR, not the PC! Formatting should be done as often as possible to re-calibrate the entire system, but...
- Page 4 NOTE: If the DVR loses power for more than 30 seconds, these settings will need to be re-entered. --SET UP DVR FOR VIDEO RECORDING-- Remember that you must remove the DVR from the Shockbox, otherwise the DVR will enter TV playback mode and turn off the LCD screen.
- Page 5 Hit “Enter/Play” button on DVR to activate this application. NOW you may insert the DVR into the Shockbox shell. If you miss a step, the LCD screen will turn off and the DVR will enter TV playback mode. --INSIDE THE VIDEO RECORDING APPLICATION-- You will see a black screen until you plug in your bullet camera and activate the power button on the remote control.
- Page 6 Check Volume Level: Start with volume at 5 and adjust as necessary based on location, vehicle type, horse power, aerodynamics and other noise factors Recording TIme: Check available amount of recording time on SD card...
- Page 7 Setting Video Quality / Activating Remote Control Trigger: Press the “Option” button while in the video recording application (AV REC) to set the video quality and activate the remote control: We recommend using the “BEST” setting always, which provides 1 hour of video recording per Gigabyte. Activate the remote control feature: By activating this feature, the DVR will begin recording each time the remote control switch is pushed.
- Page 8 Helmet Camera version Once all the settings are complete, press the “Option” button to return to the AV REC screen: Before closing the lid to Shockbox and starting your video recording, remember to activate the “HOLD” switch on the very top of the DVR. Doing...
- Page 9 --OPTIONS-- Adjustable Gain Mic ($49.99): Shockbox Hard Mount Accessories ($59.99): DVR 4 Hour Battery ($59.99): Helmet Camera ($179-$229): Sony Hi-Res 550 HQ1 color bullet ($229):...
-
Page 10: Troubleshooting
--TROUBLESHOOTING-- PC Operating Systems: VLC – http://uberdownloads.com/software/video-player/vlc.html Windows XP works perfectly with MPEG4 (asf) video files, using Windows Media Player to view MY VIDEO IMAGE IS WASHED OUT, WHAT the video. CAN I DO? The Show Biz editing software is compatible with Certain times of day and reflective conditions of Windows XP, but the software only needs to be the environment you are shooting video in can...
