Model 5050H Pipe Hanger Cart
Assembly, Safety and Parts Manual
This manual is free of charge. All personnel who operate this Pipe
Hanger Cart should have a copy of this manual and read and understand
its contents. To request a copy, call or write to the address below.
JACKSON TOOL • P. O. BOX 5701 • GREENVILLE, SC 29606
877-522-8995 or 864-721-4235 • FAX 864-721-4236 • www.jacksontoolinc.com
Read and understand this material before operating
or servicing the Pipe Hanger Cart. Failure to understand
how to safely assemble, operate and service this unit
may result in property damage, serious injury or death.
HEAD
ADJUSTIN
QUICK
LOCK
BRAKE
06/2019
HAND
Advertisement
Table of Contents
Summary of Contents for Jackson 5050H
- Page 1 Hanger Cart should have a copy of this manual and read and understand its contents. To request a copy, call or write to the address below. JACKSON TOOL • P. O. BOX 5701 • GREENVILLE, SC 29606 877-522-8995 or 864-721-4235 • FAX 864-721-4236 • www.jacksontoolinc.com...
- Page 2 CAUTION ALWAYS assemble the Pipe Hanger Cart according to the instructions section, using only parts provided by Current Tools. SPECIFICATIONS – 5050H PIPE HANGER CART Weight Capacity 1000 lbs. evenly distributed 40 — 6" to 8" hangers Pipe Hanger Size 120 —...
- Page 3 ASSEMBLY INSTRUCTIONS — CONTINUED 2. Spread both upright tubes apart and insert one end of the lower pipe hanger tube into one of the lower slots with the hanger rods angled upward (see Figure 3A). Then, insert the opposite end of the lower pipe hanger tube into the other upright tube’s lower slot. Ensure the lower pipe hanger tube is fully inserted on both ends (see Figure 3B).
- Page 4 STORAGE POSITION NOTE: The lower pipe hanger tube is inserted with the hanger rods angling downward. EXPLODED VIEW / PARTS LIST PARTS LIST – 5050H ITEM# PART# DESCRIPTION SCREW – HEX HEAD CAP 5050-3 GR5 ZINC 1/2-13 × 3) 458-1...
