Summary of Contents for IV Produkt EcoHeater Series
- Page 1 Operation and Maintenance NEW EcoHeater 060-300 Order number: Project: Translation of the original instructions...
- Page 2 Unit specifications Unit parts and accessories Damper (code EMT-01) Sound attenuator (code EMT-02) Combustion gas bypass (code EHP-B) Size Filter Coarse-65% (G4) ePM10-60% (M5) ePM2.5-50% (M6) ePM1-50% (F7) ePM1-70% (F8) ePM1-85% (F9) ePM1-70% (C7) Aluminium...
-
Page 3: Table Of Contents
Table of Contents Safety precautions 1.1 Lockable safety switch ................1.2 Inspection doors ................... 1.3 Electrical connection .................. 1.4 Compressor section ................... General 2.1 Intended use ....................2.2 Manufacturer ....................2.3 Designations ....................2.4 CE marking and EU Declaration of Conformity ...... -
Page 4: Safety Precautions
Rotating fan impeller, risk of personal injury. The unit must not be energised until all ducts have been connected. Wiring of connections and other electrical work may only be carried out by a qualified electrician or by service personnel recommended by IV Produkt. 1.4 Compressor section WARNING! Hot surfaces, risk of personal injury. -
Page 5: General
<3.5 g/kg in the fan room in winter. The unit can also be equipped for installation in cold attics or outdoors. Any other use and installation in other environments are prohibited unless spe- cifically permitted by IV Produkt AB. 2.2 Manufacturer The EcoHeater extract air heat pump is manufactured by: IV Produkt AB Sjöuddevägen 7... -
Page 6: Ce Marking And Eu Declaration Of Conformity
Operation and maintenance NEW EcoHeater DSEH200301.01.EN Page 6 2.4 CE marking and EU Declaration of Conformity EcoHeater extract air heat pumps are CE marked, which means that upon delivery, they conform to applicable provisions in EU Machinery Directive 2006/42/EC as well as to the EU Directives applicable to other types of air handling units, e.g. -
Page 7: Extended Warranty
In cases in which the equipment delivered falls under a 5-year warranty, in ac- cordance with ABM 07 with supplement ABM-V 07 or in accordance with NL 09 with supplement VU13, the IV Produkt Service and Warranty Manual is supplied with the product. -
Page 8: Technical Description
Operation and maintenance NEW EcoHeater DSEH200301.01.EN Page 8 3 Technical description 3.1 Design The EcoHeater extract air heat pump comprises two sections, a fan section and compressor section. Fan section Compressor section Fan section The fan section has a direct driven chamber fan with an EC motor and deep- ridged filter. -
Page 9: Function
Operation and maintenance NEW EcoHeater DSEH200301.01.EN Page 9 3.2 Function General The incoming water to the EcoHeater must be at least 20 °C to ensure the operational safety of the EcoHeater. Recovered energy is returned to the property's heating system. EcoHeater GT2 GP4 Min 10 °C... - Page 10 Operation and maintenance NEW EcoHeater DSEH200301.01.EN Page 10 Control The EcoHeater has a factory-set time programme for continuous operation at one speed. The time programme can be changed on the Climatix display for control at up to three fan speeds. •...
- Page 11 (Technical Data), or the prod- uct selection program IV Produkt Designer. 9. Press the enter button. 10. Press the back arrow button twice to return to the start menu. Continuous product development may give rise to specification changes without notice.
-
Page 12: Wiring Instructions And Fuse Protection
Operation and maintenance NEW EcoHeater DSEH200301.01.EN Page 12 4 Wiring instructions and fuse protection 4.1 Wiring diagrams For wiring diagrams, see order-unique electrical diagrams enclosed with the delivery of a unit or on docs.ivprodukt.com (Control diagram). 4.2 Recommended fuse protection and power supply Power supply is connected to the switch in the compressor section. -
Page 13: Wiring Instructions
Operation and maintenance NEW EcoHeater DSEH200301.01.EN Page 13 4.3 Wiring instructions Option 1 - Temperature control Option 3 - Temperature control external 0-10 VDC (code STA-08) of accumulation tanks (code STA-10) SETPOINT HEATING 0-10V TEMPERATUR SENSOR SIGNAL GND (ACTUAL ZERO) ACCUMULATOR TANK (GT7) INTERLOCK FROM INTERLOCK FROM... -
Page 14: Operation
The validity of the product warranty is conditional on the system having been commissioned correctly. Working on the unit during the warranty period without the approval of IV Produkt shall render the warranty void. The unit was designed and manufactured based on given operation cases that must comply with the unit’s use for optimal function and a good operating... -
Page 15: Commissioning Combustion Gas Bypass
Operation and maintenance NEW EcoHeater DSEH200301.01.EN Page 15 5.2 Commissioning combustion gas bypass If the EcoHeater is equipped with a combustion gas bypass, check that the combustion gas bypass: 1. Is connected to the unit’s fan section and connected according to the wiring instructions, see order-unique wiring diagrams enclosed with the delivery of the unit or on docs.ivprodukt.com... -
Page 16: Maintenance Instructions
Operation and maintenance NEW EcoHeater DSEH200301.01.EN Page 16 6 Maintenance instructions 6.1 Service schedule The service schedule comprises actions and service intervals for functional sections that may be part of the EcoHeater extract air heat pump. The unit consists of one or more of these functional sections. For the parts that come into question, refer to order unique documentation at docs.ivprodukt.com (Technical Data). -
Page 17: Filters (Code Elef)
Operation and maintenance NEW EcoHeater DSEH200301.01.EN Page 17 6.2 Filters (code ELEF) The air filter protects sensitive components inside the unit, such as the heat re- covery coil, from exposure to impurities. The dust separation efficiency varies considerably between various filter types. The dust collecting efficiency also varies substantially. - Page 18 Operation and maintenance NEW EcoHeater DSEH200301.01.EN Page 18 Inspection Check the pressure drop across the filter. The pressure drop is measured with a pressure gauge connected to the measurement outlets. The measurement out- lets are connected to each side of the filter. –...
- Page 19 Operation and maintenance NEW EcoHeater DSEH200301.01.EN Page 19 Filter replacement 1. Shut down the unit via the service switch in the control equipment, then turn the safety switch to the 0 position and lock it. The safety switch is not designed for starting/stopping the unit. Always use the service switch in the control equipment to start and shut down the unit.
-
Page 20: Fan Unit (Code Enf)
Operation and maintenance NEW EcoHeater DSEH200301.01.EN Page 20 6.3 Fan unit (code ENF) 1. EC motor with control unit 2. Fan impeller 3. Anti-vibration mounting The fan transports air through the system. The fan shall overcome the flow re- sistance found in air diffusers, ducts and units. The fan speed is regulated to provide correct air flow. - Page 21 Operation and maintenance NEW EcoHeater DSEH200301.01.EN Page 21 Inspection 1. Screws 2. Pins/screws 3. Earth braid WARNING! High voltage and rotating fan impeller, risk of personal injury. Working on/servicing the unit – Shut down the unit via the ser- vice switch in the control equipment, then turn the safety switch to the 0 position and lock it.
- Page 22 Operation and maintenance NEW EcoHeater DSEH200301.01.EN Page 22 Cleaning 1. Follow the safety instructions and paragraph 1 under Check. 2. Wipe the fan impeller blades to remove any coatings. Use an environmentally friendly degreasing agent. 3. The external surfaces of the motor must be kept clean from dust, dirt and oil. Clean with a dry cloth.
-
Page 23: Damper (Code Emt-01)
Operation and maintenance NEW EcoHeater DSEH200301.01.EN Page 23 6.4 Damper (code EMT-01) The purpose of the dampers is to regulate the air flow. Faulty function gives rise to disturbances that may result in serious problems. If the damper does not: open completely, the air flow is reduced (leaks) leading to increased energy use. -
Page 24: Combustion Gas Bypass (Code Ehp-B)
Operation and maintenance NEW EcoHeater DSEH200301.01.EN Page 24 6.5 Combustion gas bypass (code EHP-B) The purpose of the combustion gas bypass is to reroute the air flow in the event of a fire. Faulty function gives rise to disturbances that may result in serious problems. -
Page 25: Sound Attenuator (Code Emt-02)
Operation and maintenance NEW EcoHeater DSEH200301.01.EN Page 25 6.6 Sound attenuator (code EMT-02) The purpose of the sound attenuator is to reduce the sound power level in the system. Inspection Check that the baffle elements are intact and have clean surfaces. Take action if necessary. -
Page 26: Compressor Section (Code Ehp-C)
Operation and maintenance NEW EcoHeater DSEH200301.01.EN Page 26 6.7 Compressor section (code EHP-C) Periodic inspection The operation parameters for the extract air heat pump must not be changed unless a check is first made to ascertain that the changes will be within the unit’s operating range. - Page 27 Operation and maintenance NEW EcoHeater DSEH200301.01.EN Page 27 Access to the cooling circuit and compressor 1. Service hatch 2. Inspection door 3. Control cabinet WARNING! Hot surfaces, risk of personal injury. Shut down the unit and wait at least 30 minutes before opening the inspection doors to access the compressor.
-
Page 28: Troubleshooting
Operation and maintenance NEW EcoHeater DSEH200301.01.EN Page 28 7 Troubleshooting 7.1 Troubleshooting in the event of an alarm Alarm information is read out on the Carel display. Press the alarm symbol to view alarms. Inspection Possible cause Corrective action Is the alarm The frequency inverter does not Check the supply voltage to the frequency have supply voltage 3×400 V... -
Page 29: Troubleshooting Via Symptoms And Status Message
Operation and maintenance NEW EcoHeater DSEH200301.01.EN Page 29 7.2 Troubleshooting via symptoms and status message Status information is read on the Climatix display. (Main menu > Unit > Heat pump > Status heat pump). Symptom Status Possible cause Corrective action message The compres- HiPress... -
Page 30: Alarm Reset
Operation and maintenance NEW EcoHeater DSEH200301.01.EN Page 30 7.3 Alarm reset In the event of an alarm initiated by the frequency inverter or the safety circuit, the compressor stops. The alarm is displayed on both Climatix and the Carel display. In the event of an alarm, take corrective action to correct the fault, and then press the “Alarm reset”... - Page 31 You are welcome to contact us Switchboard: +46 (0)47 075 88 00 Control support: +46 (0)47 075 89 00 styr@ivprodukt.se Service: +46 (0)47 075 89 99 service@ivprodukt.se Spare parts: +46 (0)47 075 88 00 spareparts@ivprodukt.com Visit us at: www.ivprodukt.com Documentation for your unit: docs.ivprodukt.com Technical documentation: docs@ivprodukt.se...
