Summary of Contents for Essilor SL550L
- Page 1 SLIT LAMP - SL550L Installation manual www.essilor-instruments.com...
-
Page 3: Table Of Contents
INSTALLATION MANUAL > CONTENTS CONTENTS I. INSTALLATION 1. Equipment installation a. Fix the slit lamp to the pedestal b. Set the objective c. Position the eyepiece 2. Electrical connection... - Page 4 INSTALLATION MANUAL > CONTENTS...
-
Page 5: Installation
I. INSTALLATION... - Page 6 INSTALLATION MANUAL > INSTALLATION Slit lamp - SL550L > v1.0 -03.16...
-
Page 7: Equipment Installation
A size 5 Allen wrench A flat screwdriver The 6 provided screws: 4 to fix the plate on the stand (if Essilor table) 2 to fix the chinrest 4 wood screws (not provided) Slit lamp - SL550L > v1.0 -03.16... -
Page 8: Fix The Slit Lamp To The Pedestal
Using the size 5 Allen wrench and the 4 provided screws, fix the plate to the stand. If the plate used is other than the Retina412 then use the installation pattern provided with the SL550L, which is also downloadable on M’eyeDocs. - Page 9 Remove the rubber cap located under the lifting beam of the slit lamp. Put the base unit of the slit lamp on the rails then clip the 2 rail covers onto each rail. Use the screw which is under the main part of the lamp. Slit lamp - SL550L > v1.0 -03.16...
- Page 10 Place this screw in its proper place on the base unit of the slit lamp to assemble the bottom and upper parts. Tighten with the Allen wrench. > The upper part is now fixed to the pedestal. Slit lamp - SL550L > v1.0 -03.16...
-
Page 11: Set The Objective
Fit the objective onto the support. Slide the objective on until it reaches the end. > The objective is positioned. Screw on the side knob then, using the flat screwdriver, screw on the flathead screw. Slit lamp - SL550L > v1.0 -03.16... - Page 12 INSTALLATION MANUAL > INSTALLATION > The system is blocked. Slit lamp - SL550L > v1.0 -03.16...
-
Page 13: Position The Eyepiece
Position the eyepiece Using the screw located above the slit lamp microscope, fit on and then screw tight the eyepiece. 1 1 1 > The system is assembled. > You can now connect the system. Slit lamp - SL550L > v1.0 -03.16... -
Page 14: Electrical Connection
The slit lamp is delivered with: A power supply unit, A power supply cable Drawing of the complete connection of the slit lamp Chinrest Upper part of the slit lamp Pedestal of the slit lamp Slit lamp - SL550L > v1.0 -03.16... - Page 15 Connect the power supply cable located on the bottom of the chinrest to the power supply unit. Then connect the LED power supply cable to the “ ” port on the pedestal of the SL550L. Slit lamp - SL550L > v1.0 -03.16...
- Page 16 Then, plug the other end of the power supply cable into the power supply unit. Turn on the product by pressing on button 0/1 on the power supply unit. > The light turns green. > The attachment point turns on. Slit lamp - SL550L > v1.0 -03.16...
