The original operating instructions
KM 13050 M-ABR 50 / KM 13050 H-ABR 50
KM 14750 M-ABR 50 / KM 14750 H-ABR 50
KM 16550 M-ABR 50 / KM 16550 H-ABR 50
KM 19050 M-ABR 50 / KM 19050 H-ABR 50
KM 22550 M-ABR 50 / KM 22550 H-ABR 50
Order number: B00061
Manufactures by
Kersten Arealmaschinen GmbH
Empeler Straße 95
D - 46459 Rees
www.kersten-maschinen.de
Front Sweeper
KM 50
Roll diameter 50 cm
for municipal tractors u. Carrier vehicles from 18 kW
from machine number: Rev.: R00
Distributed in UK by
Kersten (UK) Ltd Tel. 0118 986 9253
Progrees House 39 Boulton Road
Reading, RG2 0NH
www.kerstenuk.com - info@kerstenuk.com
Date: 27.10.2014
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Kersten KM 50 Series
- Page 1 Order number: B00061 from machine number: Rev.: R00 Date: 27.10.2014 Distributed in UK by Manufactures by Kersten Arealmaschinen GmbH Kersten (UK) Ltd Tel. 0118 986 9253 Empeler Straße 95 Progrees House 39 Boulton Road D - 46459 Rees Reading, RG2 0NH www.kersten-maschinen.de...
-
Page 2: Table Of Contents
Table of Contents Letter ........................3 About this manual ....................4 BEFORE COMMISSIONING ..........................NOTES ABOUT THIS MANUAL ............................Safety instructions for implements ..............5 INTENDED USE ................................. GENERAL SAFETY AND ACCIDENT PREVENTION RULES ............... Disposal .............. errors! Bookmark not defined. Guarantee ............ -
Page 3: Letter
Introduction Dear Customer, Thank you for choosing a quality product from Kersten. This product has been manufactured according to the most up-to-date production methods and extensive quality assurance measures, because only when you are satisfied with your device, our goal is reached. -
Page 4: About This Manual
Kersten implement for the first time. The best way to familiarize yourself with its basic functions and its handling is to choose a free and level terrain for your first trip. -
Page 5: Safety Instructions For Implements
Safety 3 Safety instructions for implements The most important safety instructions in this manual can not cover all possibilities. It goes without saying that common sense and caution are factors that are not built into a machine, but must be brought by the person who uses and maintains the machine. - Page 6 Safety 3.2.2 Work and danger area • The user is responsible to third parties in the work area! • Staying in the danger area of the machine is prohibited! • Before switching on the implement and starting, check the near area. •...
- Page 7 Safety 3.2.7 Coupling and uncoupling of implements • Only connect and disconnect implements with the engine switched off and the PTO switched off. • When changing attachments and their parts, use suitable tools and wear gloves. • When mounting and dismounting, bring the required support equipment into the respective position and ensure sufficient stability.
- Page 8 Safety 3.2.9 Pictograms used Explanation of the pictograms used: Before commissioning, read and observe the operating instructions and safety instructions. Never open or remove protective devices while the engine is running! Follow the instructions in the technical manual. Smudge! Touch machine parts only when they have come to a complete stop.
-
Page 9: Disposal
Complaints must be confirmed by the company Kersten Arealmaschinen GmbH. Wear parts are excluded from the warranty. In addition, the warranty expires in the case of improper operation, in the event of no or incorrect maintenance work, when using inadmissible equipment and when using non- original spare parts. -
Page 10: Installing Km 13050-22550 M-Abr 50 And Km 13050- 22550H-Abr 50
Assembly 7 Installation 7.1 Extension of KM 13050-22550 M-ABR 50 and KM 13050- 22550H-ABR 50 Danger! Severe injuries to the operator or third parties may occur. Switch off the tractor and remove the ignition key before mounting or dismounting the mounted sweeper. Depending on the design of the front hydraulics, hook the FKM into the tractor implement triangle or the two-point receptacle, whereby it may be necessary to adjust the connecting parts on the sweeping machine side to the desired lifting height for the first time. - Page 11 Assembly Image 3 Image 4 6. Saw off the profile tube. Attention: the profile tube must be 10 mm longer than the protection. (image 3) 7. Repeat steps 4. - 6. on the second PTO shaft half. 8. Deburr all cut edges. (image 4) Image5 10.
-
Page 12: Mounting
Service 7.3 Cultivation of a KM 13050-22550 H-ABR 50 Insert the two hydraulic lines (supply and return) for the sweeper drive into the hydraulic sockets on the tractor. Depending on the version, the machines are equipped with a hydraulic swiveling device. Insert the hydraulic hoses into the hydraulic sockets provided on the tractor. - Page 13 Service For mounting the hydraulic tank first the tank on the sweeper housing (in the direction of travel on the right) Screw in top of existing holes. Screw the suction hose 15L between the tank filter side and the bottom of the pump.
-
Page 14: Mounting The Water Pressing Device
Service 7.6 Installation of the water blasting device Install the pre-assembled water jets with the mounting brackets - as shown in the sketch. a) Sweeper without collecting container: b) Sweeper with collecting container: Headers Headers Clippings The distance between the two nozzles varies with the different working widths of sweepers. See sketch. -
Page 15: Operation
Maintenance Operation 8.1 Operating instructions - Sweeper Adjust the two support wheels with the help of the turning handles in such a way that the roller brushes a about 4 cm wide strip on the ground depressed. It is important to pay attention to the same setting of the two support wheels according to the marking on the scale graduation! Note: A sweeping roller set too tight will not produce better sweeping results. -
Page 16: Maintenance
Maintenance 9 Maintenance 9.1 General Danger! Personal injury or damage to the machine may occur. Before using the machine, check all safety-related parts and the hydraulic connections. 9.2 Maintenance ● The sweeper must be subjected to regular maintenance. ● After carrying out the work, all dismantled safety devices must be removed be properly installed again. -
Page 17: Technical Data
Technical specifications 10 Technical specifications 10.1 Sweeper KM 13050 KM 14750 KM 16550 KM 19050 KM 22550 Type M-ABR 50 M-ABR 50 M-ABR 50 M-ABR 50 M-ABR 50 working width 150 cm 147 cm 165 cm 190 cm 225 cm Sweeping roller diameter... -
Page 18: Ec Declaration Of Conformity
Declaration of conformity 11 EG – Konformitätserklärung CE Déclaration de conformité EC Declaration Conformity EG conformiteitsverklaring,0 Nous Kersten Arealmaschinen GmbH Empeler Straße 95 D- 46459 Rees erklären, dass das déclarons que le herewith declare verklaren dat het Produkt produit that the product... - Page 19 NOTE:...
- Page 20 Distributed in UK by Kersten (UK) Ltd Tel. 0118 986 9253 Progress House 39 Boulton Road Reading, RG2 0NH www.kerstenuk.com - info@kerstenuk.com...
