APF Manual Burner System
ATTENTION: Please carefully read this instructions prior to installing your APF Manual
Burner System. Failure to adhere to these instructions may result in a possible fire
hazard, explosion, property damage, serious injury or loss of life. Do not discard this
installation guide, it must remain with fire feature.
ATTENTION: Installation and service must be performed by a qualified gas installer,
service agency or gas supplier. Your installer must follow these instructions
carefully. Architectural Pottery and their affiliates are not responsible for the actions
of the installer or misuse of products.
California Residents Prop 65 Warning: Operating, servicing and maintaining this appliance can expose you to chemicals including carbon
monoxide and brass which are known to the State of California to cause cancer, birth defects or other reproductive harm.
Installation and Operation Guide
Table Of
Contents
2
3
4
6
7
8
For more information go to www.Prop65Warnings.ca.gov
Advertisement
Table of Contents
Summary of Contents for ARCHPOT APF
- Page 1 APF Manual Burner System Installation and Operation Guide ATTENTION: Please carefully read this instructions prior to installing your APF Manual Burner System. Failure to adhere to these instructions may result in a possible fire hazard, explosion, property damage, serious injury or loss of life. Do not discard this installation guide, it must remain with fire feature.
- Page 2 Requirements Description BTU Rating Gas Inlet Size 12” Round Duel Burner, 304 Stainless Steel Up to 90,000 1/2” Female NPT 18” Round Duel Burner, 304 Stainless Steel Up to 125,000 1/2” Female NPT 24” Round Duel Burner, 304 Stainless Steel Up to 150,000 1/2”...
- Page 3 • 304 Stainless Steel Burner • Heavy Guage 304 Stainless Steel Support Plate • Key Valve Assembly • Flex Line x2 • Mounting Bracket (for select models) 2 Piece APF Mounting Bracket Whistle-Free Flex Line x2 (for select models) ARCHPOT FIRE BURNER SYSTEMS FOR ROUND, SQUARE AND LINEAR FIRE VESSELS...
- Page 4 Place the GFRC vessel over the bottom bracket so the all thread is accessible from top of vessel. Attach the APF top ring bracket using the supplied bolts. Do not seal open space between mounting bracket and vessel. Warranty is voided if the mounting bracket is not installed on required models.
- Page 5 Figure 2 SUPPORT PLATE BURNER RING KEY VALVE SUPPORT ASSEMBLY PLATE LEDGE FLEX LINES MOUNTING BRACKET NATURAL GAS SOURCE LINE DRAIN 3. The natural gas source line must be installed underground between each vessel, as shown in Figure 2. 4. The natural gas source line must be reduced to 1/2” NPT for fire tables 42”+ and 3/8” NPT for fire vessels 24” - 36”. 5.
- Page 6 Product Maintenance CAUTION! Use only approved decorative media to cover the burner assembly. Architectural Pottery Tumbled Lava Rock and Fire Glass are accepted media. Use caution when in the immediate area, as pieces may pop or explode when exposed to heat or moisture.
- Page 7 • If you experience problems with this unit, call Architectural Pottery or a licensed heating professional. • All work on this unit must be performed by a licensed heating professional. CAUTION! Before you turn on the APF Manual System, make sure that features are clear of people, animals, or any objects that are combustible.
- Page 8 Product Warranty APF Manual Burner System One Year Warranty: Architectural Pottery warrants its products, when purchased new, to be free from defects in materials and workmanship under normal use and service for one year, from the original date of purchase. Replacement or repair at the option of Architectural Pottery.
