Summary of Contents for Brickhouse Security MDC-11
- Page 1 HD Hidden Camera Watch User’s Guide...
- Page 3 HD Hidden Camera Watch The HD Hidden Camera Watch records 1080p HD video, crisp audio, or captures 1600x1200 resolution photographs. Record video continuously or based on motion. This hidden camera watch can also record in low light using its three IRs, located on the face of the watch. The HD Hidden Camera Watch supports up to 64GB of memory (not included).
- Page 4 Watch appearance may vary...
- Page 5 Audio Microphone Sensor USB Slot HD Camera Green Indicator Light Power Button, Camera, Audio, Photo Multi Function Button Time Dial Indicator Light Format & Motion Detection Function Button Infrareds...
-
Page 6: Getting Started
Getting Started The first step in using your device is charging it. Unscrew the cover knob over the USB adapter port to connect the device to your PC, or plug it into AC power with the included adapter. Be sure that the adapter jack is plugged all the way into the watch’s port. - Page 7 Formatting a MicroSD Card Press and hold the format button, then using USB line, connect camera to your computer. When the blue lights flash once,it means the format is completed. Note: The device will need to be fully charged for settings to hold. For more information on manually formating a microSD card, visit l.bhs.net/ sd-format.
- Page 8 Setting Time, Date, and Resolution After saving the file, close the window and use safely remove the hardware from your PC. Power the unit on and off. Everything created after this stage will have the new time and date set. To power the device On/Off, press and hold the Power/Video button for 2 seconds.
- Page 10 Using the HD Hidden Camera Watch With the device in Standby mode, press Continuous Video Recording: the Power/Video button to set the device to record continuously. The LED indicator will blink Blue 3 times, and then go out to indicate that it is recording video.
- Page 11 button again, and the indicator light will flash Green and Blue once. The indicator lights will remain solid Red and Blue after the photo is taken. Repeat these steps to take additional photos. Reviewing Files on a Computer To view your files on a computer, connect the device via the supplied USB cable, making sure the device is powered Off.
- Page 12 Troubleshooting The device seems to have frozen and isn’t reacting when any Problem: buttons are pressed. Solution: Your device is on low battery; charge it with the included cable. Problem: When playing back my video, I can hear audio, but have no video. Solution: This most often occurs if your computer’s media player is having trouble with your files.
- Page 13 Problem: The video is upside down. Solution: The camera is designed assuming that video is being recording while wearing this watch on your wrist aimed away from your body. If you aren’t recording that way then flip the watch over. You can also flip the video over afterwards using VLC Media Player.
