TECHLIGHTING 700FJBRK Series Installation Instructions

Installation Instructions for
Burk Head
H EADS
G ENERAL RODUCT NFORMATION P I
This product is ETL listed and suitable only for indoor dry
locations and approved for use at any height above the
finished floor.
C AUTION: To reduce the risk of a burn or electric
shock during accessory installation, disconnect the
power to the fixture.
Adjust the Fixture
1A
1
Tilt the fixture head to the desired position.
-L OW V OLTAGE
:
Lenses and Optics (Optional)
2A
ALLEN WRENCH
ALLEN SCREW
1
If installing or replacing lens accessory or replacing the
optic, remove the cover by unscrewing the Allen screw
from the top of the fixture using the provided Allen
wrench.
1
920FJBURK
700FJBRK_
1.0
