- Page 1 MULTI-JAW DEMOLITION TOOL SAFETY, OPERATION & MAINTENANCE 519014 User Manual 3/2020 Ver. 1 LaBounty | 1538 Hwy 2 | Two Harbors, MN 55616 | 1-800-522-5059 | www.stanleyinfrastructure.com/brands/labounty...
- Page 2 LaBounty dealer. You may also download a PDF copy at www.stanleyinfrastructure.com. REGISTRATION FORM The Warranty Registration Form must be filled out by the dealer or customer and returned to LaBounty indicating the date the machine went into service. POSSIBLE VARIATIONS LaBounty cannot anticipate every possible circumstance that might involve a potential hazard, as the owner’s...
-
Page 3: Table Of Contents
CONTENTS DECALS ......................6 ATTACHMENT DESCRIPTION ..............7 TERMS .......................7 INSTALLATION ..................8 Attach to Excavator ................................8 Hydraulic Installation ................................9 Adjust Rotation Flow ................................10 Jaw Installation ..................................10 Storing the Attachment ..............................14 OPERATION ....................16 Before You Start ..................................16 Safety Devices ..................................16 Technical Specifications ..............................17 Controls ....................................17 Bleed the Attachment Hydraulic Circuit ........................17 MAINTENANCE ..................19... - Page 4 If a procedure, method, tool or part is not specifically recommended by machine. Keep clear at a minimum of 15 feet (5 LaBounty, determine whether it is safe for you and others, meters). •...
- Page 5 BASE MACHINE • Ensure that the cab is equipped with the proper safety guards for LaBounty applications. The cab MUST be equipped with an approved Falling Object Protection Structure (FOPS) and cab guarding. The FOPS must meet the requirements of SAE standard J1356. A transparent, shatter-resistant shield covering the front of the cab, is also required.
-
Page 6: Decals
DECALS Servicing while pressurized can cause sever injury LOCK OUT source and RELIEVE PRESSURE before servicing Top and front cab guarding required during any material processing application 6 | MRX Multi-kit Demolition Tool Operation & Maintenance Manual... -
Page 7: Attachment Description
ATTACHMENT DESCRIPTION The MRX is the answer to most primary and secondary demolition applications. The interchangeable jaws’ designs facilitate improved penetration and rapid material downsizing. TERMS CYLINDER CONNECTION STICK CONNECTION IDENTIFICATION PLATE ATTACHMENT BRACKET HYDRAULIC CONNECTIONS ROTATING HEAD HYDRAULIC LOCK JAW MOUNTING PIN JAW MOUNTING PIN CYLINDER... -
Page 8: Installation
INSTALLATION ATTACH TO EXCAVATOR Use only approved rigging hardware rated for loads greater than the weight of the attachment. Lifting points are for moving the attachment only. Do not lift other objects or use the attachment in a cable- hung application. 1. -
Page 9: Hydraulic Installation
HYDRAULIC INSTALLATION Model Jaw Cycle Circuit (Max) Rotation Circuit (Max) Connection Attachment Rotation 74 GPM (280 LPM) 3.9 GPM (14.8 LPM) MRX200 5075 PSI (350 Bar) 2030 PSI (140 Bar) 79 GPM (299 LPM) 4.8 GPM (18 LPM) MRX250 1 In Code 62 1/2 In BSPP 5075 PSI (350 Bar) 2030 PSI (140 Bar) -
Page 10: Adjust Rotation Flow
Do not check for hydraulic leaks with your hands. Hydraulic oil could inject into the skin. Seek immediate medical attention if an injection injury occurs. 6. Visually check for hydraulic oil leaks or hydraulic hose interference. Note: The hydraulic circuit must be bled before putting the attachment into service (see “Bleed the Attachment Hydraulic Circuit”... - Page 11 Wear personal protection equipment at all times. This Clear all persons and equipment from the area of includes eye protection, hard hat, steel toe shoes, operation and machine movement. NEVER move loads leather gloves and hearing protection. over people or equipment. When viewing the operation of the attachment, maintain a safe distance of at least 30 feet (10 meters).
- Page 12 Retracted Jaw Locking Wedge Jaw Mounting Pins Jaw Mounting Hooks 8. Turn the hydraulic lock to the open position. 9. Use the auxiliary circuit control to retract the MRX cylinder. This will extend the jaw locking wedge. 10. Release the auxiliary circuit control, then have a helper quickly turn the hydraulic lock to the closed position. If performed correctly, the jaw locking pin will be fully extended.
- Page 13 Locking Screw (5 mm) 12. Clear the area of bystanders, then slowly raise the jaw off of the ground. Note: The cylinder and the hinged jaw will not be attached. The hinged jaw will be free hanging. Use caution when moving.
-
Page 14: Storing The Attachment
14. Using a 36 mm socket, remove the screw, washer and pin from the cylinder coupling. Set aside for use later. 15. Lift the cylinder hook and place a breaker bar in the cylinder hook hole. This will keep the hook open during coupling. - Page 15 Trapped hydraulic pressure may be present after Do not connect or disconnect hydraulic lines while the base machine is shut off. Extreme caution must they are pressurized. Escaping fluid under pressure be taken when removing hydraulic hoses or lines. can penetrate the skin, causing serious injury. Injury or death could result.
-
Page 16: Operation
• Ensure all decals are installed and legible. Contact • Maintain at least 50 feet (15 meters) between the LaBounty for replacements as required. attachment and any nearby power lines. • Have a DAILY safety dialog with all workers. Inform •... -
Page 17: Technical Specifications
• Use attachment rotation for positioning only. Do not • Before shearing thin material, ensure the blades are use if for bending, breaking or prying. sharp and properly adjusted. Thin material may jam • DO NOT use attachment as a jack hammer or the blades. - Page 18 7. Slowly cycle back and forth, at least five times, to full stroke. Be careful not to apply full operating pressure to the cylinder at this time. 8. Check the base machine hydraulic fluid level and fill if necessary. 9. Slowly extend and retract the excavator cylinder to it’s limits. Check for interference between the attachment and the excavator boom or stick.
-
Page 19: Maintenance
Visual Inspection _______Ensure the identification plate is present and legible. Replace if necessary. _______Inspect all tool decals and ensure they are legible. Replace if missing or illegible. Contact LaBounty customer service for replacements. _______Visually inspect the structure of the attachment for damage. If damage is found, do not use the attachment and repair immediately. -
Page 20: 40 Hour Inspection Checklist
40 HOUR INSPECTION CHECKLIST Inspect Hardware _______Check the play between the pins and bushings on the rotating head. If the play is greater than 0.6 mm, replace the bushings and pins. Lubrication _______Grease the pinion and teeth of the rotation bearing (See “MRX Body Grease Fittings” on page 21). Blade / Teeth Maintenance _______Measure the play between the blades. -
Page 21: Lubrication
LUBRICATION Recommended Grease Types Only use grease that is acid-free, contains resins, is not hygroscopic, resists aging and has a temperature range suitable for the application. After underwater use carefully clean the pins and bushings. Eliminate all trace of oxidation before lubricating again. - Page 22 Cracker Jaw Grease Fittings Pulverizer Jaw Grease Fittings Shear Jaw Grease Fittings 22 | MRX Multi-kit Demolition Tool Operation & Maintenance Manual...
-
Page 23: Inspect / Torque Bolts
INSPECT / TORQUE BOLTS General Fastener Torque Table Size 8.8 - (8G) Class 10.9 Class 12.9 4 Ft. Lbs. (5.10 Nm) 4 Ft. Lbs. (5.98 Nm) 6 Ft. Lbs. (8.5 Nm) 8 Ft. Lbs. (10.2 Nm) 6 Ft. Lbs. (8.73 Nm) 8 Ft. -
Page 24: Pulverizer Jaw
180° Blade Pitch Rotation 180° Blade Roll Rotation PULVERIZER JAW Measuring Blade Gap and Shimming Note: Removing and handling blades can be hazardous if done incorrectly. Stay at least 75 ft. (23 m) when moving. 1. Cycle the tool until the upper jaw blade begins to overlap the lower jaw blade. 2. -
Page 25: Shear Jaw
SHEAR JAW Measuring Primary / Secondary Blade Gap and Shimming Note: Removing and handling blades can be hazardous if done incorrectly. Stay at least 75 ft. (23 m) when moving. 1. Cycle the tool until the upper jaw blade begins to overlap the lower jaw blade. 2. -
Page 26: Tooth Maintenance
Guide Blade Rotation Each guide blade has two edges. Rotate the blade when the cutting edge is worn to a .25” radius. Replace when both edges are worn. 1. Remove the blade bolts and remove the blade from the blade seat. 2. -
Page 27: Build Up & Hardsurfacing
Hardsurfacing must be inspected and maintained. For hardsurfacing, LaBounty recommends; • FabTuf 960 or equivalent If you have questions about what hardsurface material to use, contact LaBounty Customer Service at 1-(800) 522- 5059. Guidelines • Connect the ground pole of the welder to the part to be welded, as close as possible to the welding area. The ground pole must be connected so that the current does not cross the hinges or the hydraulic cylinder. - Page 28 Wear Plates 28 | MRX Multi-kit Demolition Tool Operation & Maintenance Manual...
-
Page 29: Cracker Jaw
CRACKER JAW Hard weld areas Wear plates SHEAR JAW Hard wear areas MRX Multi-kit Demolition Tool Operation & Maintenance Manual | 29... - Page 30 30 | MRX Multi-kit Demolition Tool Operation & Maintenance Manual...
-
Page 31: Hydraulic Schematic
ATTACHMENTS HYDRAULIC SCHEMATIC PAR. DESCRIPTION Hydraulic diagrams ROTATION HYDRAULIC DIAGRAM 1 - Machine system 2 - Flow-regulator valve 3 - Anti-shock valve 4 - Orbital hydraulic motor HYDRAULIC POWER DIAGRAM 1 - Machine system 2 - Rotating joint 3 – BOOSTER valve 4 - Hydraulic actuator 5 - Switch 6 - Manifold... -
Page 32: Hydraulic Test Ports
HYDRAULIC TEST PORTS The MRX is equipped with hydraulic test ports that will allow you to measure cylinder pressure for troubleshooting purposes. Accessing the Hydraulic Test Ports Trapped hydraulic pressure may be present after Do not connect or disconnect hydraulic lines while the base machine is shut off. - Page 36 Additional copies of this manual are available by contacting your dealer or the LaBounty parts department, and requesting a CE Operation & Maintenance manual. You must include the attachment model number and serial number. LaBounty | 1538 Hwy 2 | Two Harbors, MN 55616 | 1-800-522-5059 | www.stanleyinfrastructure.com/brands/labounty...
