Summary of Contents for Comanche MC CAMP
- Page 1 COMANCHE MC CAMP STEP BY STEP ERECTION INSTRUCTION...
- Page 2 STEP 1. UN-HOOK UNIT FROM CAR...
- Page 3 STEP 2. LEVEL UNIT WITH JOCKEY WHEEL...
- Page 4 STEP 3. WIND DOWN BACK CORNER STEADY WITH HANDLE PROVIDED...
- Page 5 STEP 4. UNLOCK LID WITH THE KEYS PROVIDED...
- Page 6 STEP 5. RAISE BOTH SUPPORT LEGS OFF THE LID...
- Page 7 STEP 6. ATTACH BOTH SUPPORT BARS ONTO THE LEGS...
- Page 8 STEP 7. LIFT THE LID UP THROUGH 180 DEGREES TILL LEVEL ON THE GROUND...
- Page 9 STEP 8. WHEN OPENING THE LID, THE POLES AND CANVAS AUTOMATICALLY OPEN OUT...
- Page 10 STEP 9. AT THIS STAGE IT IS EASIER TO REMOVE BOTH THE MATTRESS AND THE BED LATS...
- Page 11 STEP 10. THEN REMOVE ALL 3 TABLES OUT OF THE BODY OF THE TRAILER...
- Page 12 STEP 11. REMOVING THE TABLES SHOWS YOU HOW MUCH STORAGE YOU HAVE PACK WISELY!!
- Page 13 STEP 12. PULL THE WHOLE POLE FRAME WORK OUT FROM THE LID – LEAVING THE CENTRE POLE IN THE UPRIGHT POSITION...
- Page 14 STEP 13. EXTEND ALL 3 POLE OUT TO THE FIRST CLICK BY PULLING UPWARDS. DO THIS BOTH SIDES...
- Page 15 STEP 14. NOW PULL THE CANVAS OFF THE ROOF SO IT HANGS FREELY...
- Page 16 STEP 15. NOW RAISE THE MIDDLE TENSIONING POLE AND THE OUTER POLE SO THE CANVAS HANGS LEVEL...
- Page 17 STEP 16. INSIDE SECURE THE CANVAS TO THE BODY OF THE TRAILER WITH THE VELCRO – DO THIS FRONT AND BACK...
- Page 18 STEP 17. OUTSIDE PULL THE CANVAS OVER THE BODY OF THE TRAILER AND GUIDE OUT IF REQUIRED...
- Page 19 STEP 18. NOW PEG OUT THE FRONT CANVAS AND HANG THE DRAFT SKIRT...
- Page 20 STEP 19. YOU CAN NOW ARRANGE THE TABLES HOW YOU NEED THEM...
- Page 21 STEP 20. NOW HAND THE CURTAINS AND ARRANGE SITTING/BEDROOM CUSHIONS AS REQUIRED...
