Sun's Hand Held Programmer (HHP) provides a convenient method to access configuration settings in the 790 Series Embedded
Digital Proportional Valve Amplifiers. Simply plug the appropriate Cable Adapter into the Programmer and connect the infrared-end into
the amplifier slot and it is ready to use. Only four buttons are required to view and change parameters. An additional button turns the
Programmer unit on and off. The Programmer is lightweight and compact for easy handling.
Easy to read, high-contrast screen
Intuitive, clearly marked buttons
Powered by one 9 Volt battery
Auto shutoff to extend battery life
Low battery power warning
Removable communication cable adapter
Screen contrast can be easily adjusted
Small size fits in a shirt pocket
On board memory for storage of one amplifier setup
(Version 2.0 or newer firmware only)
Operating Specifications:
Supply Voltage
Weight
Dimensions
Operating Temperature
2006-2010 Sun Hydraulics Corp.
Hand Held Programmer
9 VDC (requires standard 9 Volt battery/format EN22, 6LR61, 6AM6)
5.7 oz. (162 grams) with battery
3 in. W x 5 in. H x 1.0 in. D (76 mm W x 127 mm H x 25 mm D)
F to 158 F (
C
32
0
to 70 C)
30SEP10
# 999-991-229
www.sunhydraulics.com
991-700
Page 1 of 2
