- Page 1 Intelligent Standing Pole-mounted Measuring Instrument Quick Guide V1.01...
-
Page 2: Table Of Contents
Contents Packing List ....................1 Product Overview ..................1 2.1 Appearance and Dimensions ..............1 2.2 Structure and Cable ................3 Device Installation ..................3 3.1 Tools Preparation ................... 3 3.2 Installation ....................4 3.2.1 Ground Installation ................ 4 3.2.2 Base Plate Installation ..............8 Device Operation .................. -
Page 3: Packing List
Packing List Name Unit Intelligent measuring instrument Pole base Extension pole Expansion bolt Power adapter Power cable Note: The accessories may vary with device model and version. Product Overview OTC-513 is a non-contact thermometer that measures body temperature on the wrist. -
Page 5: Structure And Cable
Structure and Cable The figure below shows the structure and cable of the device. The actual device may vary. 1. Display screen 2. Temperature measurement module 3. Distance measurement module 4. Extension pole 5. Adapter 6. Pole base 7. Round base plate 8. -
Page 6: Installation
Installation You may choose ground installation or base plate installation. The steps are as follows. NOTE! For long-term use at a fixed location, ground installation should be adopted. Ground Installation 3.2.1 Mark the positions of holes on the ground by referring to the following figure. Fixing hole Cabling hole Use the electric drill to drill holes according to the marked positions. - Page 7 NOTE! You may choose to install 1, 2 or no extension pole based on your needs. After installation, the distance between the temperature measurement module and the ground will be 1m if one extension pole is used, 1.25m if two extension poles are used, and 0.75m if no extension pole is used.
- Page 8 WARNING! Do not hold the tail cable by hand for weight bearing. Otherwise, the cables may be loosened. Turn the measuring instrument clockwise to connect it to the standing pole. WARNING! When turning the measuring instrument, make sure the cable at the pole base is not pressed, and the cable inside the standing pole rotates with the instrument correspondingly.
- Page 9 Insert M8X80 expansion bolts into the three fixing holes on the ground, and make sure that the expansion bolts are a bit higher than the ground. M8x80 expansion bolts Ground Erect the standing pole, align the hole position at pole bottom with the expansion bolts fixed on the ground, adjust the standing pole so that it’s perpendicular to the ground, adjust device direction, and then fasten the standing pole with nuts.
-
Page 10: Base Plate Installation
Base Plate Installation 3.2.2 Connect the measuring instrument, extension pole, and pole base by referring to the Step 3 to Step 5 in Ground Installation. Fasten the base plate with screws by referring to Step 9 in Ground Installation. Device Operation Device Startup After installation is completed, connect the supplied power cable to power via a power adapter to start up the device. -
Page 11: Measuring Temperature
Clear data Latest temperature measurement Measuring Temperature 4.2.2 To take a temperature, place your wrist 1cm -2.5cm to the temperature measurement module. The screen displays as follows. Normal temperature Abnormal temperature... -
Page 12: Device Activation
Device Activation Long press the display screen. In the displayed password input interface, enter the password (the default is admin) to go to the Activation Config interface. NOTE! The default activation password is intended for initial use. Please enter the new activation password if it has been changed. -
Page 13: Network Setting
Click in Activation Config interface to enter Basic Info. Network Setting 4.3.2 Click in Activation Config interface. - Page 14 Set network parameters by referring to the table below. Parameter Description Enter the IP address of the device. IP Address The IP address of the device must be unique across the network. Subnet Mask Enter the subnet mask of the device. Default Gateway Enter the default gateway of the device.
-
Page 15: Activation Password
Activation Password 4.3.3 The default activation password is admin. Follow the steps below to change the activation password. Click in Activation Config interface. Enter the old password, new password, and confirm the new password as required. -
Page 16: Authentication Scene
NOTE! The password should be at least 8 characters including two elements of the following four: uppercase letters, lowercase letters, digits, and underscores and hyphens. The Confirm field must be consistent with the New Password field. Click Save. Authentication Scene 4.3.4 Configure temperature measurement range and temperature alarm threshold. - Page 17 The table below shows details. Parameter Description Valid range: 30-45. Default range:35.5-42. Temperature range Configure the range based on actual application scenes. When the temperature measurement module detects a temperature higher than the threshold, the abnormal Temperature alarm temperature alarm is displayed on the GUI and the threshold corresponding warning is sounded.
-
Page 18: Disclaimer And Safety Warnings
Disclaimer and Safety Warnings Copyright Statement ©2020 Zhejiang Uniview Technologies Co., Ltd. All rights reserved. No part of this manual may be copied, reproduced, translated or distributed in any form by any means without prior content in writing from Zhejiang Uniview Technologies Co., Ltd (referred to as Uniview or us hereafter). - Page 19 Uniview reserves the right to change any information in this manual without any prior notice or indication. Due to such reasons as product version upgrade or regulatory requirement of relevant regions, this manual will be periodically updated. Disclaimer of Liability ...
- Page 20 Enable IP address filtering: Allow access only from the specified IP addresses. Minimum port mapping: Configure your router or firewall to open a minimum set of ports to the WAN and keep only the necessary port mappings. Never set the device as the DMZ host or configure a full cone NAT.
- Page 21 Verify that the device is properly installed before connecting it to power. Do not remove the seal from the device body without consulting Uniview first. Do not attempt to service the product yourself. Contact a trained professional for maintenance. ...
- Page 22 http://en.uniview.com/Support/Download_Center/Product_Installation/Declaration/ Caution: The user is cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
