Advertising Displayer
CU-070I-A
7" Wide Screen
CR-070I-A
1
Specifications
Screen Size
Model name
Pixel Pitch
Resolution
Resolution (dots)
V/A( up / down )
V/A ( Right / left )
Display Size
Brightness
Card Supported
SD Card , USB Port , Inside Memory (128M)
File Supported
MP3/JEPG,M-JEPG/MEPG-I,MEPG-II, MEPG-IV
Video Decoding
Audio Decoding
Speaker
AV output
Memory Card
Auto Play
USD copy to inside
SD copy to Inside
Power Supply
Current Rating
Power Usage
Auto Power On/Off
Timer setup
Dimension L*W*H
Weight (pounds)
TFT LCD with LED Back light
7"
CU-070I-IS
0.064**0.191
480*234*3
112320*3
40°/60°
60°/60°
6.5"*4"
( 16:9 )
250cd/㎡
MPGI/II,MPG-IV,DAT,AVI
MP3
2W*2
Option
SD card: ~2G , Insider Memory : to 2G
MEPG or Auto slide show
Yes
Yes
100~240VAC 50/60Hz
1A from 12V DC adapter
8.4W
Yes
Yes
160*120*42
550g
Advertisement
Table of Contents
Summary of Contents for HUAI YANG CU-070I-A
- Page 1 TFT LCD with LED Back light Screen Size 7” CU-070I-IS Model name Advertising Displayer 0.064**0.191 Pixel Pitch Resolution 480*234*3 CU-070I-A Resolution (dots) 112320*3 V/A( up / down ) 40°/60° 7” Wide Screen V/A ( Right / left ) 60°/60° Display Size 6.5"*4"...
- Page 2 POWER POWER ON/OFF SETUP Changing settings Remote control Advertising Displayer DISPLAY No function CARD Selection Choose a different memory card Quick start guide MUSIC Go to and display music files PHOTO Go to and display photo files 1. Connect MOVIE Go to and display movie files 2.
- Page 3 1. Connect A. TURE ON THE POWER (Left Side) LED Light DC 12V INPUT B. INSERT THE MEMORY CARD OR USB MEMORY BAR (Right Side) MENU DOWN POWER On/Off USB Memory Bar USB PORT Memory card cover...
- Page 4 3. Enjoy Play in machine memory Machine have inside Memory Then Power On.. you can see… Machine is loading now (Don’t need insert SD card or USB bar to Machine ) B. Card select Auto Choose Inside memory first C. Function select Auto Play Inside memory MEPG file first If want play SD card or USB card must by Menu type...
- Page 5 Press SETUP Key Function : (1) LANGUAGE : ENGLISH /JAPANESE (2) SLIDESHOW TIME: 3s/5s/15s/1Mins/15Mins (3) Transition Effect: ▲ Random ▲Fading ▲Vexpand_Top ▲Vexpand_Bottom ▲ Vexpand_Middl ▲Off ▲Bottom_To_Top ▲Top_To_Bottoom ▲ Left_To_Right ▲ Right_To_Left ▲Door_close ▲ Door_open ▲ Hori_Cross ▲ Verti_Cross (4)MUSIC REPEAT MODE： Repeat all/Repeat off/Repeat One (5)MOVIE REPEAT MODE: Repeat all/Repeat off/Repeat One (6)DISPLAY MODE: Crop/Stretch/Cinema...
- Page 6 4.HOW TO Auto COPY USB Memory or SD Card memory to Inside Memory Card Machine Is Power On status: large SIZE (1) Insert USB Memory or SD card to Machine. SD card and USB bar must have one file is “ AUTOHOMEVIDEO.XXX “...
- Page 7 Menu Key : Play next MEPG or JEPG or Music Power Key : Machine Power On or Power On ******************************************** 淮 洋 有 限 公 司 HUAI YANG CO., LTD. TEL:886-2-8261-0858 FAX:886-2-8261-8855 http://www.hy1688.com.tw 236 台北縣土城市中央路二段 191 號 10 樓之 5 ********************************************* ☆...
