Matco Silver Eagle SE1350 Operating Instructions Manual

High speed air saw
Hide thumbs
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

Download this manual
Operating Instructions
SPECIFICATIONS
Strokes per Minute . . . . . . 10,000 SPM
Ave . Air Consumption . . . . . . . . 1 .0 CFM
Max . Rec . Air Pressure . . . . . . . 90 PSI
Air Inlet . . . . . . . . . . . . . . . . . . . 1/4" NPT
Net Weight . . . . . . . . . . . . . . . . . 1 .76 Lbs
Length . . . . . . . . . . . . . . . . . . . . . . . 9 .25"
Sound Pressure Level . . . . . . . . 82 dBA
Cutting Capacity . . . 1 .6mm steel sheet
Stroke Length . . . . . . . . . . . . . . . . . 10mm
Includes:
18TPI, 24TPI and 32TPI Bi-Metal Blades
ALwAys reAd
instruCtions
before using
power tooLs
ALwAys weAr
sAfety goggLes
weAr heAring
proteCtion
Avoid
proLonged
exposure to
vibrAtion
SE1350
Warning Information
Some dust created by power sanding, sawing, grinding, drilling, and other construction
activities contains chemicals known to cause cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:
• Lead from lead-based paints,
• Crystalline silica from bricks and cement and other masonry products, and
• Arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this type of
work. To reduce your exposure to these chemicals: work in a well ventilated area, and
work with approved safety equipment, such as those dust masks that are specially
designed to filter out microscopic particles.
High Speed Air Saw
Copyright © Professional Tool Products, 2009
1
SE1350
Parts Breakdown
All rights reserved.
07/16/09

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Silver Eagle SE1350 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Matco Silver Eagle SE1350

  • Page 1 SE1350 High Speed Air Saw Operating Instructions Warning Information Parts Breakdown SPECIFICATIONS Strokes per Minute . . . . . . 10,000 SPM Ave . Air Consumption . . . . . . . . 1 .0 CFM Max .
  • Page 2 • Use accessories recommended by Matco Tools. performing any maintenance on this tool. Failure to • Do not lubricate tools with flammable or volatile liquids do so could result in injury. Whip hoses can cause such as kerosene, diesel or jet fuel.

  • Page 3: Air Supply

    Silver Eagle™ Authorized Warranty Center, freight prepaid. Please include a copy of your proof of purchase and a brief description of the problem. The tool will be inspected and if any part or parts are found to be defective in material or workmanship, the tool will be repaired free of charge and returned to you freight prepaid. This warranty gives you specific rights. You may also have other rights which vary from state to state. The foregoing obligation is Matco’s sole liability under this or any implied warranty and under no circumstances shall Matco be liable for any incidental or consequential damages. SE1350 07/16/09...
  • Page 4 SE1350 High Speed Air Saw Ref. No. Part No. Description Qty. Ref. # Part # Description Qty. RS305A11 Valve Plug RS11031SE Comfort Grip RS305A10 O-Ring RS11032SE Housing RS305A09 O-Ring RS26115 Set Screw RS11004 Air Regulator RS11034 Screw RS305A07 Spring RS388418 Roll Pin RS305A06 Throttle Pin RS11036 Saw Blade Cover RS305A04 O-Ring...
  • Page 5 SE1350 SCIE PNEUMATIQUE À GRANDE VITESSE Instructions de fonctionnement Avertissement Pièces SPÉCIFICATIONS Courses par minute . . . . . . . 10,000 SPM Consommation d’air moyen . . . . . 1 CFM Pression d’air Rec .
  • Page 6 Si vous ne le faites • Utilisez les accessoires recommandés par les outils Matco. pas, vous risquez des blessures graves. Le fouettage • Ne lubrifiez pas les outils avec des produits inflammables des tuyaux peut causer de graves blessures. Vérifiez...

  • Page 7: Dépannage

    Cette garantie vous donne des droits particuliers. Vous pouvez aussi avoir d’autres droits qui varient d’un état à l’autre. Cette obligation est la seule responsabilité de Matco dans le cadre de cette garantie et Matco ne sera en aucun cas responsable de dommages connexes ou corrélatifs. SE1350 07/16/09...
  • Page 8 SE1350 SIERRA NEUMÁTICA DE ALTA VELOCIDAD Instrucciones de Operación Información de Advertencia Revisión de Refacciones ESPECIFICACIONES Golpes por minuto . . . . . . . . . . . . . . 10,000 SPM Consumo promedio de aire .

  • Page 9: Operación

    • Pueden calentarse los filos y las hojas de la sierra durante de aire antes de instalar, quitar o ajustar cualquier accesorio su uso. No los toque. de esta herramienta, o antes de realizar cualquier • Use los accesorios recomendados por Matco Tools. mantenimiento de esta herramienta. La falla en hacerlo • No lubrique las herramientas con soluciones inflamables ni podría resultar en alguna lesión. Las mangueras volátiles, tales como el queroseno, el gasóleo ni el combustible de látigo pueden ocasionar alguna herida seria.

  • Page 10: Diagnóstico De Averías

    1 se reparará la herramienta, libre de cargos, y ésta será devuelta a GARANTÍA usted con flete prepagado. Silver Eagle™ por Matco le brinda al consumidor una garantía de sus Esta garantía le proporciona ciertos derechos. Usted puede tener herramientas neumáticas por un período de un año. Repararemos también otros derechos los cuales varían de estado a estado. cualquier herramienta neumática de la Serie SE, cubierta bajo esta La obligación anterior es la única responsabilidad de Matco bajo esta o...
