- Page 2 2. Copper Nut 1. Copper Elbow 3. 4x Rubber Gasket 4. Fan 12. Body Spray Jet 10. Thermostatic Faucet Asembly 13. Control Valve 15. Drain Assembly 14. Air Control Valve 17. Color LED Light...
-
Page 3: Door Handles
25. Door handles 27. Door Roller Roof Fastening Brackets: 7pcs 29. Hand shower Pole 3.5x30mm Screw: 8pcs 6x30mm Bolt: 4pcs 28. Speaker 31. Cleaning Port 6mm Washer: 8pcs 33. Steam Outlet 6mm Lock Washers: 4pcs Rubber Grommet: 4pcs 3mm Allen Wrench: 1pc... - Page 4 Steamer Power 220V 30Amp GFCI Whirlpool power 110V 20Amp GFCI...
- Page 5 Level Bathtub 1. Carefully Unpack the bathtub from the Crate and bring into house and put into position on floor in bathroom. 2. Put a level on the bathtub to check the level in both directions as illustrated in drawing Adjust the adjustable legs if the bathtub is not level and to make sure there is no rocking of bathtub once final level is set then lock the adjustable legs in position by tightening the locking nut with a wrench And Recheck level of bathtub.
- Page 8 Install Moveable doors 1. Hang the doors on the upper track (Illustrated in Drawing A) Then press the lower spring loaded wheels down to hook into the lower aluminum track. (Illustrated in Drawing B) Note: there is an adjustment screw on the upper wheel assembly to adjust if there is a gap between the moveable doors or if the doors are overly stiff in movement then adjust the upper wheels to correct fit of doors.
- Page 9 Install Accessories 1. Install the Glass Shelf as illustrated in Drawing A. first install the brackets to the wall Using 4x16mm screws, 4mm washers, 6mm Plastic Washers and 4mm nuts. Then attach the arms to the brackets and the glass shelf to the arms as Illustrated in Drawing B. 2.
- Page 10 Connect Wires 1. Put the top cover onto the steam shower carefully (illustrated in Drawing A) 2. Use a phillips screwdriver to fix the top cover to the shower assembly with 4x10mm screws and stainless steel brackets. Illustrated in Drawing B. 3.
- Page 11 Connect Fittings and Water Lines 1. Connect the Overhead rain shower head hose to rain shower head joint. Connect the drain hose from the steamer to the shower base and connect the steam outlet hose to the steam outlet, Illustrated in Drawing A. 2.
