VXIpc 700 Series User Manual
December 1997 Edition
Part Number 321745A-01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VXIpc 700 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for National Instruments VXIpc 700 Series

Summary of Contents for National Instruments VXIpc 700 Series

  • Page 1 ™ VXIpc 700 Series User Manual VXIpc 700 Series User Manual December 1997 Edition Part Number 321745A-01...
  • Page 2 Singapore 2265886, Spain 91 640 0085, Sweden 08 730 49 70, Switzerland 056 200 51 51, Taiwan 02 377 1200, United Kingdom 01635 523545 National Instruments Corporate Headquarters 6504 Bridge Point Parkway Austin, Texas 78730-5039 USA Tel: 512 794 0100 © Copyright 1997 National Instruments Corporation. All rights reserved.
  • Page 3 90 days from date of shipment, as evidenced by receipts or other documentation. National Instruments will, at its option, repair or replace software media that do not execute programming instructions if National Instruments receives notice of such defects during the warranty period.
  • Page 4 This device complies with the FCC rules only if used with shielded interface cables of suitable quality and construction. National Instruments used such cables to test this device and provides them for sale to the user. The use of inferior or nonshielded interface cables could void the user’s authority to operate the equipment under the...

  • Page 5: Table Of Contents

    Peripheral Expansion..................1-6 Chapter 2 Functional Overview VXIpc 700 Functional Description..................2-1 Chapter 3 VXIpc 700 Series Configuration and Installation Default Settings........................3-1 Configuring the VXIpc 700 Series ..................3-3 How to Remove the Metal Enclosure..............3-3 VXIbus Slot 0/Non-Slot 0 .................3-4 Trigger Input Termination.................3-4 EEPROM......................3-5...
  • Page 6 Figure 1-2. VXIpc-745 Embedded Computer ............1-2 Figure 2-1. VXIpc 700 Series Block Diagram ............2-2 Figure 3-1. VXIpc 700 Series Parts Locator Diagram ..........3-2 Figure 3-2. VXIbus Slot Configuration ..............3-4 Figure 3-3. SMB Trigger Input Termination ............. 3-5 VXIpc 700 Series User Manual ©...
  • Page 7 VXIpc 700 Series Hardware Default Settings.........3-3 Table B-1. VXIpc 700 Series ISA Interrupt Resource Allocations......B-1 Table B-2. VXIpc 700 Series DMA Channel Resource Allocations ......B-2 Table B-3. VXIpc 700 Series I/O Address Map............B-3 Table C-1. LEDs and System Startup Status.............C-2 Table D-1.

  • Page 8: About This Manual

    • Chapter 2, Functional Overview, contains functional descriptions of each major logic block on the VXIpc 700 Series embedded computers. • Chapte 3, VXIpc 700 Series Configuration and Installation, contains the instructions to configure and install the VXIpc 700 Series embedded computer.

  • Page 9: Conventions Used In This Manual

    This font is also used for the proper names of disk drives, paths, directories, device names, functions, variables, filenames, and extensions. Bold text in this font denotes the messages and responses that the computer monospace bold automatically prints to the screen. VXIpc 700 Series User Manual © National Instruments Corporation...

  • Page 10: How To Use This Documentation Set

    About This Manual VXIpc 700 Series The terms VXIpc 700 Series and VXIpc-700 refer to a series of C-size, single-slot VXI controllers. Currently, this series consists of the VXIpc-740 and VXIpc-745. How to Use This Documentation Set Begin by reading the Getting Started with Your VXIpc 800/700 Series manual for basic instructions for setting up the hardware and software.

  • Page 11: Related Documentation

    Consortium Customer Communication National Instruments wants to receive your comments on our products and manuals. We are interested in the applications you develop with our products, and we want to help if you have problems with them. To make it easy for you to contact us, this manual contains comment and configuration forms for you to complete.

  • Page 12: Introduction

    Introduction This chapter describes the VXIpc 700 Series of embedded VXI computers, lists what you need to get started, describes the hardware, and lists optional equipment and software. Overview The VXIpc 700 Series consists of the VXIpc-740 and VXIpc-745 models.

  • Page 13: Optional Equipment

    PCMCIA-GPIB card in a PCMCIA slot to get IEEE 488.2 capability on the VXIpc-740. The VXIpc 700 Series is a custom computer that you install directly in one C-size slot of your VXIbus mainframe. An embedded computer can take full advantage of the VXI high-performance backplane capabilities and give you direct control of VXI registers, memory, interrupts, and triggers.

  • Page 14: National Instruments Software

    National Instruments Software National Instruments has developed several software kits that you can use with the VXIpc 700 Series. The NI-VXI bus interface software for the VXIpc 700 includes a Resource Manager, an interactive VXI resource editor program, a comprehensive library of software routines for VXI/VME programming, and an interactive control program for interacting with VXI/VME.

  • Page 15: Hardware Description

    Appendix A, Specifications. Slot 0 Functionality You can use the VXIpc 700 Series computers to achieve full VXI Slot 0 control of your VXI system. You can also install the VXIpc-700 in another slot and use it in Non-Slot 0 mode. You do not have to change any switches...

  • Page 16: Front Panel Features

    System reset push-button • Front-panel connectors as listed in the following table Connector VXIpc-740 VXIpc-745 RS-232 Serial VGA Controller IEEE 488.2 — 10BaseT Ethernet — Trigger Output Trigger Input PS/2-Style Keyboard © National Instruments Corporation VXIpc 700 Series User Manual...

  • Page 17: Peripheral Expansion

    Table 1-1 lists the various peripherals, indicates the VXIpc model(s) on which the peripheral is available, and describes the external connector, its bus interface, and its function. Table 1-1. VXIpc 700 Series Peripherals Overview External Peripheral Availability...
  • Page 18 Chapter 1 Introduction Table 1-1. VXIpc 700 Series Peripherals Overview (Continued) External Peripheral Availability Connector or PCI Function PCMCIA VXIpc-740 Two Type I/II or Supports two independent VXIpc-745 One Type III PCMCIA slots GPIB VXIpc-745 24-pin CHAMP IEEE 488.2 interface...

  • Page 19: Functional Overview

    Functional Overview This chapter contains functional descriptions of each major logic block on the VXIpc 700 Series embedded computers. VXIpc-700 Functional Description The VXIpc-700 is a modular PC in a VXIbus C-size form factor. It includes many high-performance peripherals that normally require add-in cards on desktop PCs.

  • Page 20: Figure 2-1. Vxipc 700 Series Block Diagram

    The VXIpc-700 consists of the following logic blocks: • IDE—This is dedicated PCI-IDE circuitry providing fast ATA-2 transfers to the internal hard drive. The IDE for the VXIpc 700 Series is built into the chip set. • VXI—This is the PCI-VXIbus interface circuitry. The MITE is a National Instruments ASIC developed to efficiently manage data transfers between the VXIbus and the processor (via the PCI bus).
  • Page 21 RJ-45 connector for access to an external Ethernet-based LAN. • GPIB—This logic block represents the IEEE 488.2 port on the VXIpc-745. It uses the National Instruments TNT4882 ASIC for maximum performance as an ISA-based GPIB controller. © National Instruments Corporation...

  • Page 22: Vxipc 700 Series Configuration And Installation

    Installation This chapter contains the instructions to configure and install the VXIpc 700 Series embedded computer. Unless otherwise noted, these instructions apply to all models in the VXIpc 700 Series, which currently consists of the VXIpc-740 and the VXIpc-745. Caution Electrostatic discharge can damage several components on your VXIpc-700 module.

  • Page 23: Figure 3-1. Vxipc 700 Series Parts Locator Diagram

    5 Slot 0 Identification (W1) 8 Trigger In Termination (W12) 3 Serial Number 6 MITE EEPROM Configuration (W7) 9 Ethernet EEPROM Configuration (W6) Figure 3-1. VXIpc 700 Series Parts Locator Diagram VXIpc 700 Series User Manual © National Instruments Corporation...

  • Page 24: Configuring The Vxipc 700 Series

    Chapter 3 VXIpc 700 Series Configuration and Installation Table 3-1 lists the factory-default settings and options for the onboard jumpers. Table 3-1. VXIpc 700 Series Hardware Default Settings Jumper Default Setting Optional Setting Enable automatic Slot 0 Force Slot 0;...

  • Page 25: Vxibus Slot 0/Non-Slot 0

    Chapter 3 VXIpc 700 Series Configuration and Installation VXIbus Slot 0/Non-Slot 0 The VXIpc-700 is configured at the factory to automatically detect if it is installed in Slot 0 of a VXIbus mainframe. With automatic Slot 0 detection, you can install the module into any VXIbus slot.

  • Page 26: Eeprom

    Chapter 3 VXIpc 700 Series Configuration and Installation a. Trigger Input b. Terminate Trigger Input Unterminated (Default) Figure 3-3. SMB Trigger Input Termination EEPROM The VXIpc-700 has an onboard EEPROM, which stores default register values for the VXI circuitry. These values are loaded when you power up the computer.

  • Page 27: How To Fix An Invalid Eeprom Configuration

    Chapter 3 VXIpc 700 Series Configuration and Installation Figure 3-5 shows the configuration settings for EEPROM operation. a. Boot from User b. Boot from Protected Configuration (Default) Configuration Figure 3-5. EEPROM Configuration How to Fix an Invalid EEPROM Configuration The NI-VXI software includes a configuration utility you can use to edit the configuration of the VXIpc-700.

  • Page 28: Installed System Ram

    Installed System RAM The 16 MB of installed RAM is factory configured per customer order. You can change the amount of installed RAM on the VXIpc 700 Series by installing DRAM SIMMs. Refer to Appendix A, Specifications, for more information on SIMMs.

  • Page 29: Ethernet Power-On Defaults

    Chapter 3 VXIpc 700 Series Configuration and Installation Ethernet Power-On Defaults The VXIpc-700 Ethernet circuitry loads its power-on settings from an EEPROM. Do not change W6 from its default setting as shown in Figure 3-7a. Figure 3-7b shows the alternate position only for informational purposes.
  • Page 30 Chapter 3 VXIpc 700 Series Configuration and Installation Insert the VXIpc-700 in the slot you have selected by aligning the top and bottom of the module with the card-edge guides inside the mainframe. Slowly push the VXIpc-700 straight into the slot until its plug connectors are resting on the backplane receptacle connectors.

  • Page 31: Entering Bios Setup

    Auto Configuration with Optimal Settings or Auto Configuration with Fail-Safe Settings. Select the Optimal settings if you want to get maximum performance from the VXIpc 700 Series. Fail Safe settings are more conservative settings. © National Instruments Corporation VXIpc 700 Series User Manual...

  • Page 32: Appendix A Specifications

    Specifications This appendix describes the environmental, electrical, and mechanical specifications of the VXIpc 700 Series embedded computer. Requirements Characteristic Specification VXIbus Configuration Space 64 B A24 or A32 Space 16 KB Minimum (Programmable) Electrical Current (A) Voltage (V) Typical Maximum (Fused) 3.85 A...
  • Page 33 Non-operational: 5 to 500 Hz, 2.5 g , 3 axes Functional MIL-T-28800E Class 3 (per Section 4.5.5.4.1) Shock Half-Sine Shock Pulse (11 ms duration, 30 g peak, 3 shocks per face) VXIpc 700 Series User Manual © National Instruments Corporation...
  • Page 34 ROR, FAIR Release on Request and FAIR bus requester IH(7-1) Interrupt handler for levels 7-1 I(7-1) Interrupt requester for levels 7-1 D32, D16, D08(O) VMEbus D32, D16, D08(O) interrupt (Interrupt Handler) handler © National Instruments Corporation VXIpc 700 Series User Manual...
  • Page 35 4 MB × 36 SIMMs — 70 ns 16 MB: 8 MB × 36 SIMMs — 70 ns 32 MB: The height of SIMMs used with VXIpc 700 Series controllers should be 1.2 in. Contact National Instruments for recommendations on specific manufacturers. VXIpc 700 Series User Manual...

  • Page 36: Vxipc 700 Series System Resources

    System Resources This appendix describes what system resources are available on the VXIpc 700 Series and where they are allocated. Because PCI is a relatively new addition to PCs, this appendix describes how PCI interrupts fit into a PC architecture before listing the devices that use them.

  • Page 37: Table B-2. Vxipc 700 Series Dma Channel Resource Allocations

    Appendix B VXIpc 700 Series System Resources Table B-1. VXIpc 700 Series ISA Interrupt Resource Allocations (Continued) ISA Interrupt PCI Interrupt Device INTD PCMCIA None Floppy Drive None PCMCIA Slot None None Ethernet INTC None GPIB None PCMCIA Slot None...

  • Page 38: Table B-3. Vxipc 700 Series I/O Address Map

    Appendix B VXIpc 700 Series System Resources Table B-3. VXIpc 700 Series I/O Address Map I/O Address Device 000-00F 8237 DMA #1 020-021 8259 PIC #1 040-043 8253 Timer 060-066 8742 Controller 070-077 CMOS RAM & NMI Mask Reg 078-07B...
  • Page 39 Appendix B VXIpc 700 Series System Resources Table B-3. VXIpc 700 Series I/O Address Map (Continued) I/O Address Device 3BC-3BF Free 3E8-3EF COM* 3F0-3F7 Floppy 3F8-3FF COM* * Relocatable VXIpc 700 Series User Manual © National Instruments Corporation...

  • Page 40: Led Indicators

    LED Indicators This appendix describes how to read the LEDs on the front panel to interpret the status of the VXIpc 700 Series. VXIbus Interface Status LEDs The VXIbus interface status LEDs are located at the top of the module and include four LEDs: FAILED, SYSFAIL, ONLINE, and TEST.

  • Page 41: Table C-1. Leds And System Startup Status

    Make sure that the VXIpc-700 is seated properly in the mainframe. Power on the mainframe and observe whether the SYSFAIL and FAILED LEDs become unlit some time before the operating system boots. VXIpc 700 Series User Manual © National Instruments Corporation...
  • Page 42 VXIbus master is accessing VXIbus shared registers or shared memory. DRIVE LED The DRIVE LED indicates that an access to the internal hard disk drive is occurring. © National Instruments Corporation VXIpc 700 Series User Manual...

  • Page 43: Front Panel And Connectors

    Dimensions are shown in inches and millimeters, with millimeter dimensions in square brackets. The front panel thickness for all models in the VXIpc 700 Series is 2.49 mm (0.098 in.). © National Instruments Corporation VXIpc 700 Series User Manual...
  • Page 44 2.091 [53.11] 2.080 [52.83] (2.937 [74.60]) 3.177 [80.70] (3.417 [86.79]) 3.701 [94.00] 4.137 [105.08] 4.209 [138.86] 5.467 [138.86] 9.159 [232.64] RESET VXIpc -740 Figure D-1. VXIpc-745 Front Panel Layout and Dimensions VXIpc 700 Series User Manual © National Instruments Corporation...
  • Page 45 Figure D-2 shows the front panel layout of the VXIpc-740. FAILED SYSF ONLINE TEST DRIVE 2.091 [53.11] 2.859 [72.62] 3.701 [94.01] 4.209 [106.91] 5.467 [138.86] 9.159 [232.64] RESET VXIpc -740 Figure D-2. VXIpc-740 Front Panel Layout and Dimensions © National Instruments Corporation VXIpc 700 Series User Manual...

  • Page 46: Keyboard Connector Location And Pinout

    Front Panel and Connectors Keyboard Figure D-3 shows the location and pinouts for the keyboard connector on the VXIpc 700 Series. Table D-2 gives the name and description for the keyboard connector signals. Amp manufactures a mating connector with part numbers 212437-4 (housing), 212435-7 (ferrule), and 66735-4 (pin contact).

  • Page 47: Table D-3. Vga Connector Signals

    Front Panel and Connectors Figure D-4 shows the location and pinouts for the VGA connector on the VXIpc 700 Series. Table D-3 gives the name and description for the VGA connector signals. Amp manufactures a mating connector with part numbers 748364-1 (housing) and 748333-2 (pin contact).
  • Page 48 Front Panel and Connectors Table D-3. VGA Connector Signals (Continued) Signal Name Signal Description Ground +5 VDC +5 VDC Ground Not Connected Serial Data HSync Horizontal Sync VSync Vertical Sync Serial Clock VXIpc 700 Series User Manual © National Instruments Corporation...

  • Page 49: Ethernet Connector Location And Pinout

    Amp manufactures a mating connector, part number 554739-1. Ethernet Figure D-5. Ethernet Connector Location and Pinout Table D-4. Ethernet Connector Signals Signal Description Differential Transmit Differential Transmit Differential Receive Differential Receive © National Instruments Corporation VXIpc 700 Series User Manual...

  • Page 50: Table D-5. Com1 Connector Signals

    COM1 Figure D-6 shows the location and pinouts for the COM1 connector on all models in the VXIpc 700 Series. You can plug a serial mouse into this connector. Table D-5 gives the name and description for the COM1 connector signals.
  • Page 51 Appendix D Front Panel and Connectors Table D-5. COM1 Connector Signals (Continued) Signal Name Signal Description CTS* Clear to Send Ring Indicator © National Instruments Corporation VXIpc 700 Series User Manual...

  • Page 52: Table D-6. Gpib Connector Signals

    Data Bit 1 DIO2* Data Bit 2 DIO3* Data Bit 3 DIO4* Data Bit 4 EOI* End or Identify DAV* Data Valid NRFD* Not Ready for Data NDAC* Not Data Accepted VXIpc 700 Series User Manual D-10 © National Instruments Corporation...
  • Page 53 SRQ* Service Request ATN* Attention SHIELD Chassis ground DIO5* Data Bit 5 DIO6* Data Bit 6 DIO7* Data Bit 7 DIO8* Data Bit 8 REN* Remote Enable 18-25 Logic Ground © National Instruments Corporation D-11 VXIpc 700 Series User Manual...

  • Page 54: Table D-7. Smb Connector Signals

    VXIpc -740 VXIpc -740 a. VXIpc-745 b. VXIpc-740 Figure D-8. SMB Connectors Location and Pinout Table D-7. SMB Connector Signals Signal Description Center TTL Trigger or Clock Signal Shield Ground VXIpc 700 Series User Manual D-12 © National Instruments Corporation...

  • Page 55: Table D-8. Signal Characteristics For Smb Connections

    SMB (TRIG out, CLK out) 0 to 3.4 V 200 mA DC-10 MHz † SMB (TRIG in) 0 to 5 V 100 mA DC-10 MHz † with 50 Ω termination © National Instruments Corporation D-13 VXIpc 700 Series User Manual...

  • Page 56: Table D-9. Vxibus P2 Connector Signals

    VXIbus P1 and P2 Figure D-9 shows the location and pinouts for the VXIbus connector on the VXIpc 700 Series. Table D-9 gives the name and description for the VXIbus P2 connector signals. Table D-10 gives the name and description for the VXIbus P1 connector signals.
  • Page 57 –5.2 V Not Connected MODID02 Not Connected MODID01 TTLTRG1* TTLTRG0* TTLTRG3* TTLTRG2* +5 V TTLTRG5* TTLTRG4* TTLTRG7* TTLTRG6* Not Connected Not Connected MODID00 Not Connected Not Connected +5 V Not Connected © National Instruments Corporation D-15 VXIpc 700 Series User Manual...

  • Page 58: Table D-10. Vxibus P1 Connector Signals

    BG1IN* BG1OUT* BG2IN* BG2OUT* SYSFAIL* BG3IN* SYSCLK BERR* BG3OUT* SYSRESET* BR0* DS1* LWORD* BR1* DS0* BR2* WRITE* BR3* DTACK* IACK* Not Connected IACKIN* Not Connected IACKOUT* IRQ7* IRQ6* IRQ5 IRQ4 VXIpc 700 Series User Manual D-16 © National Instruments Corporation...
  • Page 59 Front Panel and Connectors Table D-10. VXIbus P1 Connector Signals (Continued) Row C Row B Row A IRQ3 IRQ2 IRQ1 +12 V Not Connected –12 V +5 V +5 V +5 V © National Instruments Corporation D-17 VXIpc 700 Series User Manual...

  • Page 60: Appendix E Common Questions

    When the computer first boots, the video chips try to synchronize with the monitor. If the monitor is not there, the video chips cannot synchronize and establish color. You need to have the monitor attached at boot time to get color. © National Instruments Corporation VXIpc 700 Series User Manual...
  • Page 61 (adapter space) is free for use by ISA bus boards or expanded memory manager software programs? See Appendix B, VXIpc 700 Series System Resources, for information on the available port I/O register space, upper memory area, interrupts, and DMA channels. VXIpc 700 Series User Manual © National Instruments Corporation...
  • Page 62 (FSD) circuitry by changing the appropriate jumper setting on the VXIpc-700. Refer to Chapter 3, VXIpc 700 Series Configuration and Installation, for information on enabling and defeating the FSD circuitry. How do I check the configuration of the memory, floppy drive, hard drive, time/date, and so on? You can view these parameters in the BIOS setup.

  • Page 63: Appendix F Customer Communication

    Electronic Services Bulletin Board Support National Instruments has BBS and FTP sites dedicated for 24-hour support with a collection of files and documents to answer most common customer questions. From these sites, you can also download the latest instrument drivers, updates, and example programs. For recorded instructions on how to use the bulletin board and FTP services and for BBS automated information, call 512 795 6990.
  • Page 64 Telephone and Fax Support National Instruments has branch offices all over the world. Use the list below to find the technical support number for your country. If there is no National Instruments office in your country, contact the source from which you purchased your software to obtain support.
  • Page 65 National Instruments for technical support helps our applications engineers answer your questions more efficiently. If you are using any National Instruments hardware or software products related to this problem, include the configuration forms from their user manuals. Include additional pages if necessary.
  • Page 66 Complete a new copy of this form each time you revise your software or hardware configuration, and use this form as a reference for your current configuration. Completing this form accurately before contacting National Instruments for technical support helps our applications engineers answer your questions more efficiently.
  • Page 67 Other Peripherals (manufacturer, model) _______________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________...
  • Page 68 Documentation Comment Form National Instruments encourages you to comment on the documentation supplied with our products. This information helps us provide quality products to meet your needs. Title: VXIpc™ 700 Series User Manual Edition Date: December 1997 Part Number: 321745A-01 Please comment on the completeness, clarity, and organization of the manual.

  • Page 69: Glossary

    Valid numbers for n are 16, 24, and 32. In VME/VXI, because there are six address modifiers, there are 64 possible address spaces. ANSI American National Standards Institute ASIC application-specific integrated circuit bits bytes © National Instruments Corporation VXIpc 700 Series User Manual...
  • Page 70 Direct Memory Access; a method by which data is transferred between devices and internal memory without intervention of the central processing unit DRAM Dynamic RAM (Random Access Memory); storage that the computer must refresh at frequent intervals VXIpc 700 Series User Manual © National Instruments Corporation...
  • Page 71 16, using the digits 0 to 9 and letters A to F hertz; cycles per second Integrated Drive Electronics. Denotes the most common interface to the hard drive on PCs. IEEE Institute of Electrical and Electronics Engineers © National Instruments Corporation VXIpc 700 Series User Manual...
  • Page 72 The relative priority at which a device can interrupt IRQ* Interrupt signal Industry Standard Architecture; denotes a common expansion bus used in PCs kilobytes of memory Light-emitting diode VXIpc 700 Series User Manual © National Instruments Corporation...
  • Page 73 A transfer can be either a read or a write. megabytes of memory MITE A National Instruments custom ASIC, a sophisticated dual-channel DMA controller that incorporates the Synchronous MXI and VME64 protocols to achieve high-performance block transfer rates MODID Module ID Lines.
  • Page 74 VXIbus backplane, or both. Sub Miniature Type B connector that features a snap coupling for fast connection trigger Either TTL or ECL lines used for intermodule communication Transistor-Transistor Logic VXIpc 700 Series User Manual © National Instruments Corporation...
  • Page 75 Installing such a device into any other slot can damage the device, the VMEbus/VXIbus backplane, or both. VXIbus VMEbus Extensions for Instrumentation © National Instruments Corporation VXIpc 700 Series User Manual...

  • Page 76: Index

    PC configuration, 3-7 customer communication, xii, F-1 to F-2 setting back to default, E-3 COM1 connector and signals, D-8 to D-9 common questions about VXIpc 700 Series, E-1 to E-3 default settings, 3-1 to 3-3 configuration factory default settings (table), 3-3...
  • Page 77 1-6, 2-3 features, 1-6 to 1-7 peripherals overview (table), 1-6 to 1-7 layout and dimensions (figure) ISA interrupt resource allocations (table), VXIpc-740, D-3 B-1 to B-2 VXIpc-745, D-2 FTP support, F-1 VXIpc 700 Series User Manual © National Instruments Corporation...
  • Page 78 See also video interface. peripheral expansion (table), 1-7 booting for color, E-1 signals. See also connectors. type to use with VXIpc-740, E-2 COM1 connector (table), D-8 Ethernet connector (table), D-7 © National Instruments Corporation VXIpc 700 Series User Manual...
  • Page 79 1-5 to 1-6 B-1 to B-2 models available, 1-4 PCI interrupts, B-1 peripheral expansion, 1-6 to 1-7 resource tables, B-1 to B-4 system startup cycle and LEDs, C-2 VXIpc 700 Series User Manual © National Instruments Corporation...
  • Page 80 Slot 0 functionality, 1-4 logic blocks, 2-2 to 2-3 National Instruments software, 1-3 optional equipment, 1-2 overview, 1-1 to 1-2 VXIpc-740 embedded computer (figure), 1-1 VXIpc-745 embedded computer (figure), 1-2 VXIplug&play compliance, 1-2, D-1 © National Instruments Corporation VXIpc 700 Series User Manual...
