To connect a sensor:
•
Remove the waterproof dust cap from the connector.
•
Insert the sensor plug into the connector socket taking care that the plug and socket locating tabs are lined up.
•
Tighten the locking thread on the plug until it is secure.

Installing the Battery

The Aquaflex Cellular Hub has 3 AA rechargeable batteries which must be fitted after the system is installed.
•
Loosen the four corner screws on the front cover of the Aquaflex Cellular Hub.
•
Carefully pull the front cover forward and remove it.
•
Insert the batteries making sure that the polarity is correct.
•
Check the seal on the front cover is intact and free from debris and then replace the front cover onto the Aquaflex
Cellular Hub.
•
Tighten the four corner screws to secure the faceplate.
•
Now that your system is installed and operating you can advise your provider, from here your data will be setup
under an account and you will be given login instructions to view your data

Maintenance and Troubleshooting

The following points should be considered for maintenance.
•
Prevent foliage from covering the solar cell and wipe clean if dirty
•
Check rain gauges at each download and clear any blockages

Forcing a reset

Reset the Aquaflex Cellular Hub by removing all its power.
This is done by covering the solar cell and removing the batteries.
Watch the Green LED for a quick flash when the battery is inserted which indicates it has started up.
AF270-1
Connector (from left)
SDI-12 Sensor
External power
Digital input
SDI-12 Sensor
Pins Position in image
7 Bottom left
4 Top Centre
6 Bottom Centre
7 Bottom right
