- Page 1 Exostiv Probe User's Guide Rev. 1.0.3 - February 26, 2019 https://www.exostivlabs.com...
- Page 2 Table of Contents EXOSTIV Probe – User’s guide .................................3 Scope ........................................3 Overview......................................3 Instructions of use ....................................5 Interfaces voltages and specifications ..............................6 General precautions and safety recommendations..........................6 Regulatory compliance ..................................7 Revision History Revision Modifications • 1.0.1 Initial revision • 1.0.2 Minor corrections •...
- Page 3 EXOSTIV Probe with 1 to 4 channels – speed per channel up to 12.5 Gbps EP3000, EP6000 and EP12000 can be jointly referred to as ‘EXOSTIV Probe’. The model type can be found on the label at the back of the device – see ‘Overview below’.
- Page 4 12) Screws 11) Side fan openings 13) Model & Serial number label SFP/SFP+ cable QSFP+ to 4x SFP+ cable with splitter SMA cable HDMI cable Rev. 1.0.3 - February 26, 2019...
- Page 5 Optionally connect the probe output clock with SMA cables (8)) Use ON/OFF button to turn Probe ON (7)). EXOSTIV Probe can only be used and controlled with software provided by Exostiv Labs. Any other usage is strictly forbidden. Please check EXOSTIV Dashboard installation guide and user’s guide.
- Page 6 Interfaces voltages and specifications Connector reference I/O standard – voltage – specification Remark 4) ‘HDMI’ connector Check UG102 – Interfacing EP Series – User’s guide. 5) Control connector Not applicable Not used – do not connect 6) SFP connector Check UG102 – Interfacing EP Series – User’s guide. 7) Input power connector 12 V DC Power supply Respect voltage and polarity as follows:...
- Page 7 This device must accept any interference received, including interference that may cause undesired operation Caution Any changes or modifications of the device, not expressly approved by Exostiv Labs sprl, that could modify the FCC compliance of the device, could void the user’s authority to operate the equipment. Information to the user Class A digital device, pursuant to Part 15 of the FCC Rules.
- Page 8 DOCUMENT, EVEN IF EXOSTIV LABS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Exostiv Labs products are not designed or intended to be fail-safe or for use in any application requiring fail-safe performance; you assume sole risk and liability for use of Exostiv Labs products in such critical applications.
