Summary of Contents for Econoline 36-1 DP
- Page 1 36-1 DP PLEASE READ BEFORE USING THIS EQUIPMENT...
- Page 3 Below you will find instructions on how to assemble your unit upon receipt. If you have any questions on how to proceed with any steps, contact Econoline Technical Service by phone at 1-800-253-9968 or fax at 1-616-846-6341 NOTICE: The DP36 is delivered skid-mounted to assure safe arrival.
- Page 4 STEP 4 – Dust Collector set-up Unpack the dust collector and place within a few feet of the sandblast cabinet. (Note: vacuum hose is packed in bottom barrel of dust collector.) Attach one end of the plastic hose to the air inlet of the vacuum system and attach the other end to the air outlet on the rear of the blasting cabinet.
- Page 5 *Air to the plumbing of your unit should be supplied by hose or pipe with a minimum of 3/8” I.D. and we strongly suggest ½” I.D. *Do not attach your air supply to the unit with quick connects, as this greatly reduces the volume of air to the system and will adversely affect the units performance.
- Page 6 STEP 10 – Controlling the abrasive media flow The pressure-pot is fitted with an abrasive metering valve (no. 5) located on the bottom of the vessel. To adjust the valve, align the valve lever perpendicular to the valve body (closed position). Now turn the lever down approximately 30 degrees.
-
Page 7: Maintenance
MAINTENANCE To assure a long efficient life of the system, it is recommended to: A. Replace nozzle when compressor can’t keep up, or media usage is excessive. B. Rebuild media valve when it starts to leak or doesn’t shut off. C. -
Page 8: Helpful Hints
HELPFUL HINTS 1. Air compressor choice: Secure an air compressor that has the capacity to produce a high volume (cfm) and high-pressure (psi) of moisture –free air. You must maintain a constant air pressure, not high one minute and low the next, it must be constant. 2. - Page 9 PARTS LIST FOR LARGE LIGHT BOX COMPLETE ASSEMBLY #202835-LED DESCRIPTION PART NUMBER 1. Light Box cover only 410466 2. Power Cord 411242 3. Light Switch (on/off) 411249 4. LED tube 7W / T8 / 5000K (2 required) 411240 5. Socket 411245 6.
- Page 10 PARTS LIST FOR BLAST CABINET DESCRIPTION Part # 18. Window frame 309344-66 19. Window plexi-glass 12” x 24” 411405 20. Window underlayment 1 piece 24” x 120” 311535 10 pieces 12” x 24” 313286 21. Window gasket material 411403 (Specify number of feet required) 22.
- Page 12 PARTS LIST FOR AIR SYSTEM – PLUMBING DESCRIPTION PART NO. 1. Regulator 411127 2. Pipe Tee 411328 3. Inlet Ball Valve 411126 4. Air Hose ½” I.D. 413431 5. Choke Ball Valve 411126 6. Abrasive Metering Valve 411125 7. Pipe Cross 411330 8.
-
Page 15: Please Read
PLEASE READ For optimum performance, we have included two different media valve diaphragms. Installed in the media valve is our high-pressure diaphragm part #411157. If the media valve does not shut off immediately upon releasing the foot pedal, you may need to change the diaphragm. -
Page 19: Troubleshooting Tips
TROUBLESHOOTING TIPS PROBLEM POSSIBLE SOLUTION Surging of blast flow? Air pressure too low------------------- See “Lack of Air” Too much media----------------------- Adjust media valve Excessive media consumption? Media valve open too far------------- Close slightly Air pressure too low------------------- Check pressure gauge Clogging and plugging of blast flow? Debris in media------------------------ Purge &... -
Page 20: Warranty
ECONOLINE ABRASIVE PRODUCTS GUARANTEES ITS BLAST CABINETS AGAINST DEFECTS IN MATERIAL AND WORKMANSHIP FOR A PERIOD OF FIVE YEARS FROM THE ESTABLISHED PURCHASE DATE. ECONOLINE WILL REPAIR OR REPLACE, FREE OF CHARGE, ANY DEFECTIVE PARTS DETERMINED TO BE COVERED UNDER THIS WARRANTY BY OUR FACTORY SERVICE PERSONNEL.
