PF-313 CBN300# (Ø4mm~Ø5mm, for HSS end mill) Daimond wheel PF-313 CBN270# (Ø6mm~Ø13mm, for HSS end mill) Daimond wheel PF-313 CBN270# (Ø4mm~Ø13mm, for HSS end mill) 2 fultes Daimond wheel PF-313 SDC300# (Ø4mm~Ø13mm, for carbide end mill) 2 fultes Daimond wheel PF-1225-2 fultes CBN150# (Ø12mm~Ø25mm, for HSS end mill)
Page 4
PRECISON END MILL GRINDER Alignment Base Alignment Block Alignment Knob NO.2 FOR SCREW RADIAL ANGLE 20° Magnified Part NO.3 FOR CUTTING ANGLE 6° THIS OVAL SHAPE HOLE, Fixed Block (Harden treatment to protect WOULD ALLOW HOLDER the alignment base) UNIT MOVE ON AXIS TO GRIND ALL SURFACE OF END MILL 6°...
Page 5
OPERATIONS Set up the end mill to the ER collet holder ★ Please follow up steps 1.2.3.4. to set up the end mill to the collet holder.(without tightening) 1. Determine diameter and flute of your end mill, and then select the proper collet and collet holder.
Page 6
Relief settings 1. If the relief needs to be adjust, please use provided 4mm hex wrench to loosen the screws in the sharpening NO.1. 2. Rotate clockwise ( ) to increase, rotate counterclockwise ( ) to decrease. Tighten after relief setting. Secondary clearance angle sharpening-1 (for 4 flute) 1.
HSS end mill. 2. Determine the flute of the end mill and use the proper collet holder; PF-313 / 1225 is suitable for 2, 3, and 4 flute end mill. 3. Aligning end mill is the most important among the steps, make sure to complete this step before grinding.
FAST DRILL RE-SHARPENING MACHINE Patented Features 1. Double-bearing grinding unit (reduce wear). 2. Drill tightened design with bearing devise. 3. Adjustable trimming angle. Standard Accessories PF-213FG 1. ER Collets, ranged from 2.5mm-13mm (12pcs). 2. CBN Dimand wheel #200x1 PCS (for High Speed changing the grinding wheel drill).
Page 9
FAST DRILL RE-SHARPENING MACHINE Patented Features 1. Double-bearing grinding unit (reduce wear). 2. Drill tightened design with bearing devise. 3. Adjustable trimming angle. Standard Accessories PF-1226 1. ER Collets, ranged from 12mm-26mm (15pcs). 2. CBN Dimand wheel #150x1 PCS (for High Speed drill).
Page 10
OPERATIONS Procedures for changing the grinding wheel 1. Choose the collect accordingly to the drill diameter. 2. Slot the chosen collet Holder (B) at an appropriate angle. Φ 3. Insert the drill into the connected collet and collet holder set, leave a 35mm extension of the drill’s original body length, but do not tightened the drill too tight.
