Summary of Contents for FURBER Cool WLSF-4059R
- Page 1 Manual Anleitung Manuel d'utilisation Manuale FURBER AG Hintermättlistrasse 3, 5506 Mägenwil, Schweiz...
- Page 2 16” STAND FAN WITH REMOTE CONTROL OPERATING INSTRUCTIONS PLEASE READ COMPLETELY BEFORE OPERATING THE FAN READ AND SAVE THESE INSTRUCTIONS...
- Page 3 PARTS INDENTIFICATION (Fig.1) 1 Motor front cover 10 Inner stand pipe 20 Blade 2 Blade fixing shaft 11 Height adjustment 21 Guard lock knob 3 Motor shaft 12 Outer stand pipe 22 Rear guard 4 Remote control receive 13 Base 23 Power line window 5 Remote control panel...
-
Page 4: How To Assemble
4. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. - Page 5 2. The whole assembly (Fig.3) “Caution” Never remove the inner pipe stopper. If you remove the inner pipe stopper, service may be necessary. (1) Loosen the height adjustment knob(11). Then adjust the pipe to the desired height and then retighten the adjustment knob. (2) Loosen the body fixed knob (9) by turning into the left.
- Page 6 5. Mounting the front guard cover (Fig.6) (1) Put the front guard cover into the center of the front guard (17), (2) Fix and tighten the guard cover (16) by screws firmly. 6.Mounting the front and rear guard together (Fig.7) (1)After fixing the back guard base on the process point #1, then un-screw the locking screw mounted on the bottom of the guard.
- Page 7 HOW TO USE 1. Speed control Speed of a fan is controlled by pressing the key “ON/Speed” on the control box or Remote control. Press this key once, the fan is on and operates at low speed; Press a seccond time for middle fan speed and press a third time for the high fan speed.
- Page 8 Care, Cleaning & Storage • Keep the fan clean. • Ensure that the fan is switched off from the supply mains before any cleaning. Plastic parts should be cleaned with a moist cloth. Thoroughly remove water film with dry cloth. •...
