Summary of Contents for E-Service Nayax
- Page 1 01707 280 050 WWW.E-SERVICE.CO.UK SALES E-SERVICE.CO.UK Nayax installation Guide The complete guide to installing the Nayax wireless card reader...
- Page 2 Nayax Installation Guide Figure 1 - Installed Nayax Layout...
- Page 3 PL1 Main Board Cable Nayax AMIT 3 This cable is attached to the machine’s main board The Nayax AMIT 3 is the central unit of the Nayax and is usually connected directly to the coin mech. system and connects the Nayax components In the Nayax setup, the cable is plugged into the together.
- Page 4 PULSE1\FUJI RXD Blue EX PULSE INHIBIT Green AC / DC - Yellow PULSE2\FUJI TXD Not used Black Not used To correctly wire the Nayax Interface Board, please follow the diagram above to match the correct wires to the correct holes.
- Page 5 Nayax Installation Guide Number meter wiring guide Figure 3 Wire Colour Wire Name PL2 Hole Number Black (any wire) Black (any wire) To correctly wire the number meter, please follow the diagram above to match the correct wires to the correct holes.
- Page 6 Nayax Installation Guide Thomas software updating guide Figure 4 Access the Control Module Open the Machine and locate the Control Module, as seen in figure 4. Remove the bill validator to gain access to the control module and open it’s hinged door.
- Page 7 Test the newly activated software. Test the software by dropping a 10p coin, it should give change for the same value that the Nayax tap value should be, i.e £5, £10 or £20. Insert all other coins and notes and check the change given is correct.
- Page 8 Nayax Installation Guide Figure 9 Figure 10 Remove the plastic cover from the Thomas Machine door Unscrew the four 7mm nuts that are circled in red in figure 9. Once the nuts are unscrewed, remove the plastic cover, as seen in figure 10.
- Page 9 Nayax Installation Guide VPOS wireless card reader mounting guide Figure 12 Figure 13 Figure 11 Place the provided template over the Thomas 3000 Print out the template on page 15 or 16 of this guide, depending onwhether you are installing the VPOS or Onyx.
- Page 10 Nayax Installation Guide Figure 14 Insert the grommet for the connector cable Once drilled, fit the grommet into the 22mm hole, as seen in figure 14. Figure 15 Figure 16 Screw the VPOS/Onyx into the front of the machine Position the VPOS/Onyx wireless card reader over the newly drilled holes and screw it in from the back of the machine’s door, as seen in figure 16.
- Page 11 Figure 19 Figure 20 Connect the Nayax Interface Board to the AMIT 3 Plug the the I/O cable into the AMIT’s port marked ‘I/O’, as seen in figure 20. If the Interface Board is not already connected to the I/O cable, please refer to page 4 for detailed...
- Page 12 Nayax Installation Guide NAYAX Interface Board mounting guide Figure 22 Figure 23 Figure 21 Plug the Interface Board into the coin mech and the main board Find the cable connecting the machine’s main control board to the coin mech and unplug it. Plug the inter- face board into the same socket as in figure 22.
- Page 13 Nayax Installation Guide Mounting the aerial guide Figure 24 Figure 25 Position the aerial on the machine. Position aerial on the machine. Positioning the aerial on the inside of the machine will protect against vandalism, but positioning the aerial externally will maximise signal strength. To position the aerial on the outside, pass its wire into the hole on the back of the machine, as in figure 24.
- Page 14 Find the contactless payment instructions label that was included in the kit and attach it to the front of the machine in a visible location. Turn on the Machine and contact E-Service Turn the power on to the machine and call E-Service on 01707 280 050. We will complete the installation with you and test it remotely.
- Page 15 125mm 87mm 52mm...
- Page 16 90mm 87mm 39mm 90mm...
- Page 17 E-Service by phone or email. The E-Service Support Team and our expert engineers are ready to help you get your Nayax payment system up and running and to help you through any issues that might occur.
