Summary of Contents for HUDDY DIAMONDS DiaKat BS-300R
- Page 1 Ledařská 8 / 147 00 Praha 4 - Braník / Česká republika http://www.huddy.cz / info@huddy.cz tel: +420 244 461 926 / fax: +420 244 461 927 / Operator’s Manual BS-300R Universal Grinder...
-
Page 2: Table Of Contents
BS- - - - 300R 300R 300R 300R Universal surface grinder Read the operator’s manual carefully and understand the contents before you use this equipment. Always use the machine in accordance with all the instructions contained in this manual, in order to ensure safe and efficient operation as well as longevity of the machine. -
Page 3: Safety Instruction
BS- - - - 300R 300R 300R 300R Universal surface grinder SAFETY INSTRUCTION 1.1. General safety instructions 1.1.1. Qualification requirements Persons operating this machine must fulfil the following requirements: 1. The machine may be operated independently only by workers who are: •... -
Page 4: Using The Machine
BS- - - - 300R 300R 300R 300R Universal surface grinder 1.1.4. Using the machine When using the machine the operator must comply with the following instructions: 1. Check the machine before use. 2. Before commencing work check if it is safe to start the machine with out endangering the operator or other persons. -
Page 5: Prohibited Activities
BS- - - - 300R 300R 300R 300R Universal surface grinder 1.3. Prohibited activities When using the machine it is forbidden: 1. Using the machine for work other then for which is designed. 2. Operating the machine in other manners then those described in this manual. 3. -
Page 6: Hygienic Information
BS- - - - 300R 300R 300R 300R Universal surface grinder When working with the machine the following instructions must be complied with: 1. It is prohibited to work with the machine with out the tool cover (including the rubber collar). 2. -
Page 7: Technical Data And Description Of The Machine
BS- - - - 300R 300R 300R 300R Universal surface grinder TECHNICAL DATA AND DESCRIPTION OF THE MACHINE 2.1. Description of the machine The universal BS – 300R DiaKat grinder is designed for levelling of bumpy or uneven concrete and asphalt horizontal surfaces, removing of paint, concrete blooming, dirt deposits, glue, horizontal road markings and surface preparation prior to further treatment. -
Page 8: Primary Operative Parts Of The Machine
BS- - - - 300R 300R 300R 300R Universal surface grinder 2.3. Primary operative parts of the machine Pic. 3 Description of operative parts 7 – Front setting wheel 1 – Quick-lift leaver 8 – Engine 2 – Handlebar setting leaver 9 –... -
Page 9: Mounting And Dismounting Of Tool
BS- - - - 300R 300R 300R 300R Universal surface grinder Name Tc grinding wheel Ø 300 mm * grinding of surfaces to desired finish * removing of minor unevenness * removing of paint, glue Depth of cut 0,2 - 0,5 mm Material * asphalt * concrete... -
Page 10: Mounting Of Tool
BS- - - - 300R 300R 300R 300R Universal surface grinder !ATTENTION! Always follow the instructions below when mounting or dismounting tool! (Only then you can set up the machine with tool correctly and safely.) The machine must be always secured against movement and the engine switched off when changing tool! 2.5.1. -
Page 11: Working With The Machine
BS- - - - 300R 300R 300R 300R Universal surface grinder WORKING WITH THE MACHINE 4.1. Setting of the machine , start !ATTENTION! never start the engine if the tool is touching the floor. 1. With the aid of front and rear setting wheels set the machine that the tool (machine frame) is parallel to the working surface and the tool is lightly touching the floor. -
Page 12: Maintenance
BS- - - - 300R 300R 300R 300R Universal surface grinder MAINTENANCE The basic steps of preventive maintenance described in this manual can be carried out by the operator appointed by the entrepreneur. We recommend that all repairs and adjustments beyond the scope of this manual are carried out by authorised service centre. -
Page 13: Conditions Of Guarantee
BS- - - - 300R 300R 300R 300R Universal surface grinder CONDITIONS OF GUARANTEE Diakat machines are designed and manufactured to withstand the toughest working conditions and still remain safe, defect free and long-lasting. The following conditions are the same for the whole Diakat range of products.
