LED WEATHER PROOF SERIES
PL-TP01 - 30/55/70/80W
INSTALLATION GUIDE
Important Safety Instructions
1. Turn off the main power supply prior to installation.
2. The Ceiling Light must be installed by a licensed electrial contractor or electrician.
3. Do not install the Ceiling Light in damp, wet and hot locations. Please ensure adequate ventilation.
4. For indoor use only.
Cleaning and Maintenance
Turn off the power supply. Clean the Ceiling Light with soft cloth using a mild liquid cleaner. Dry with a cloth.
// INSTALLATION DIAGRAM
1
RECESSED
1. Drill 4 holes of 8mm diameter.
3
3.Unscrew until a gap of 4mm is present.
The hook of the bracket will clip in here.
PrimeLED Australia
Warehouse / Showroom
580mm
SCREW
Unit 2, 99-101 Western Ave Westmeadows VIC 3049
1300 533 000 (1300 LED 000) info@primeled.com.au
www.primeled.com.au
2
2. Install the bracket onto the ceiling.
4
4. Install the light and tighten the screw.
RoHS
Advertisement
Table of Contents
Summary of Contents for PRIMELED WEATHER PROOF Series
- Page 1 3.Unscrew until a gap of 4mm is present. 4. Install the light and tighten the screw. The hook of the bracket will clip in here. PrimeLED Australia Unit 2, 99-101 Western Ave Westmeadows VIC 3049 1300 533 000 (1300 LED 000) info@primeled.com.au Warehouse / Showroom www.primeled.com.au...
- Page 2 3. Screw the suspension kit to both sides of the 4. Install the light and adjust the suspension kit lamp. wires. PrimeLED Australia Unit 2, 99-101 Western Ave Westmeadows VIC 3049 1300 533 000 (1300 LED 000) info@primeled.com.au Warehouse / Showroom www.primeled.com.au...
