DETECTOR DEVICE INFORMATION AND USE DIRECTIONS

The Detector device was designed to locate and identify stations
for the Sentricon System with Always Active
®
caps or ESP technology Transensors When using Sentricon with
®
ESP technology, the Detector will also determine the station status.

Detector Features

– LCD display — identifies station, and indicates station status (with ESP technology
only)
– Proximity sensor — easier to locate stations
– Replaceable, rechargeable Nickel Metal Hydride batteries—commercially available
and easy to replace
– Auto shut off — saves battery life
– Adjustable pole length with ergonomic design — enhanced technician comfort
– No exposed wires — easier to use around landscaping and reduced risk for damage
and repairs
– Light weight — enhanced technician comfort

When You Get the Detector

1. Remove top panel electronics box and insert 8 nickle metal hydride batteries.
2. Use the included charger found in the box to fully charge the batteries.
3. Review instructions for each feature of the auxilary options.
4. Watch the "How-to-Use" video on the "product resources" section of the CSS Resource Center (www.cssresourcecenter.com).
5. Test the device in the office to make sure it works properly before going to a job site.
On & Off
To turn the device on, lightly tap the green power button (see photo). To turn the device off, tap the green power button a second time. The
device will automatically turn off after 2 ½ minutes of inactivity. (This time can be adjusted.)

Audible Notifications

– Device power on and device power off — brief audible tone
– Station proximity — audible tone increases in frequency as the device gets closer to the station
– Maintenance alert — pulsating audible tone (with ESP technology only)
Light Colors
– Green light — power is on
– Red light — station proximity
– Orange light — batteries are charging
– Yellow light — batteries are no longer capable of accepting a charge; replace the batteries
Pole Adjustments
The length of the pole can be adjusted by loosening the adjustment knob and shortening or lengthening the telescopic pole.
Protective Case
Will be included with the unit to help absorb impact from normal use and prevent scuffing.
