Chore-Time Generation 2 QUADRATHERM QUADRADIANT Manual

Hide thumbs Also See for Generation 2 QUADRATHERM QUADRADIANT:

Advertisement

Quick Links

Download this manual
FOR YOUR SAFETY
If you smell gas:
1. Open Windows
2. Don't touch electrical switches
3. Extinguish any open flame
4. Immediately call your gas supplier
FOR YOUR SAFETY
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
Note:
The original, authoritative version of this manual is the English version produced by CTB, Inc. or any of its subsidiaries or divisions, (hereafter
collectively referred to as "CTB"). Subsequent changes to any manual made by any third party have not been reviewed nor authenticated by CTB.
Such changes may include, but are not limited to, translation into languages other than English, and additions to or deletions from the original content.
CTB disclaims responsibility for any and all damages, injuries, warranty claims and/or any other claims associated with such changes, inasmuch as
such changes result in content that is different from the authoritative CTB-published English version of the manual. For current product installation and
operation information, please contact the customer service and/or technical service departments of the appropriate CTB subsidiary or division. Should
you observe any questionable content in any manual, please notify CTB immediately in writing to: CTB Legal Department, P.O. Box 2000, Milford, IN
46542-2000 USA.
0409
For additional manuals or more information, see our website at www. ctbinc.com
POUR VOTRE SURETE
Si vous sentez une odeur de gaz:
1. Ouverz les fenêtres
2. Ne touchez pas aux de commutateurs électriques
3. Eteindre n'importe quelle ouverture flambe
4. Immédiatement appeler votre fournisseur de gaz
POUR VOTRE SURETE
Pas l'essence de magasin ou usage ou les autres
vapeurs et les liquides inflammables à proximité de cet
ou l'autre appareil.
0209 Quadradiant
CH2141A

Advertisement

loading
Need help?

Need help?

Do you have a question about the Generation 2 QUADRATHERM QUADRADIANT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Chore-Time Generation 2 QUADRATHERM QUADRADIANT

Summary of Contents for Chore-Time Generation 2 QUADRATHERM QUADRADIANT

  • Page 1 FOR YOUR SAFETY POUR VOTRE SURETE If you smell gas: Si vous sentez une odeur de gaz: 1. Open Windows 1. Ouverz les fenêtres 2. Don't touch electrical switches 2. Ne touchez pas aux de commutateurs électriques 3. Extinguish any open flame 3.

  • Page 2: Warranty

    Manufacturer must authorize any exceptions to this Warranty in writing. Manufacturer reserves the right to change models and specifications at any time without notice or obligation to improve previous models. Effective 08/08 Chore-Time Equipment A Division of CTB, Inc. P.O. Box 2000 Milford, Indiana 46542-2000 USA Ph.: 574-658-4101 Fax: 877-730-8825...
  • Page 3 WARNING ! SERIOUS PERSONAL INJURY AND/OR DEATH MAY RESULT FROM USE OF THIS HEATER IN AN UNVENTILATED BUILDING OR IN HUMAN LIVING AREAS. LE RESULTAT DE MAI DE MORT DE ET/OU DE BLESSURE PERSONNEL SERIEUX DE L'USAGE DE CET APPAREIL DE CHAUFFAGE DANS UN CONSTRUISANT UNVENTILATED OU DANS L'HUMAIN SECTEURS VIVANTS EL USO DE ESTA CALENTADORA EN UN EDIFICIO SIN VENTILACIÓN O EN UNA AREA HUMANA PUEDE RESULTAR EN ENFERMEDAD Y/O MUERTE...
  • Page 4 Before lighting, sniff all around the appliance area for a gas odor. Be sure to sniff next to the floor because propane gas is heavier than air and may temporarily exist at floor level. Avant d'allumer, renifle tout autour le secteur d'appareil pour une odeur de gaz. Etre sûr de renifler à côté du plancher parce que le gaz de propane est plus lourd que l'air et peut exister temporairement au niveau de plancher.
  • Page 5 QUADRADIANT QUADRADIANT 80,000 BTU High Pressure Heater 120 v Maximum 5 PSI GAS WARNING: During normal operation, the surfaces of the unit become very hot. It is VERY IMPORTANT that the power cords and gas supply hoses DO NOT TOUCH or REST ON ANY surface of the unit or to come within 12”...
  • Page 6 WARNING 5 PSI MAXIMUM OUTLET PRESSURE. GAS PRESSURE EXCEEDING 5 PSI MAY VOID WARRANTY. USE THREADED GAS CONNECTIONS ONLY. HEATER MUST BE CONNECTED TO GAS SUPPLY USING THE DRIP LEG, HOSE AND CONNECTORS PROVIDED WITH THE UNIT BY THE MANUFACTURER. ALLOW HEATING UNIT TO TO AVOID INJURY, ALWAYS BEFORE USING HEATER...
  • Page 7 QuadRadiant® Heater Installation Checklist Installation Topics Checkmark below when complete 1. Gas Pressure at Heater Q. Have you verified that your gas pressure at the heater is 5 psi maximum? A. See page 10 in the installation and operation manual. 2.
  • Page 8 Lista de verificación de instalación de criadoras QuadRadiant® Temas de instalación Ponga una marca debajo una vez completado 1. Presión de gas en el calentador Q. ¿Ha verificado usted que su presión de gas al calentador es de 5 psi al máximo? A.
  • Page 9 Install drip leg on gas line. The manufacturer requires the installation of the drip leg in order to help keep the gas orifice free from debris commonly found in gas lines. Use approved and certified sealant on all connections. WARNING! Failure to follow the instructions in this manual could result in serious personal injury or property damage.
  • Page 10 Remove adapter from drip leg parts bag. Apply certified and approved gas sealant to threads and insert into gas valve as shown. Take care to not get sealant inside of adapter. Piping joint compound must be resistant to the action of liquefied petroleum gases. In order to avoid loosening other connections when installing the adapter, tighten using a wrench on the adapter and one on the valve.
  • Page 11 SUSPENDING THE HEATER NOTE: We recommend that the heater be installed level. Keep gas hose away from hot surfaces. The heater is attached to a winch cable used for raising and lowering. In addition, a safety cable or chain (not supplied) is required to be attached to the suspension hooks to prevent the heater from falling to the litter if the cable should happen to break.
  • Page 12 WITH DEFLECTORS MISSING DEFLECTORS This is only a temporary adjustment. Heaters REQUIRE the installation of HEAT DEFLECTORS. CONNECTING HEATER TO THERMOSTATICALLY CONTROLLED POWER SUPPLY Insert grounded plug into 120 volt controlled electrical outlet. WARNING! Do not allow power cords and/or gas supply hoses to rest on the canopy, hanging brackets or any other hot surfaces of the unit or within 12”...
  • Page 13 Sensor Location Sensor should be placed over the feeder or drinker line. Suspend sensor 12" to 16" off the floor. Sensor should be no more than10-12 feet to the side from the center or 10 feet lengthwise from the center of the heater. Page 13 For additional manuals or more information, see our website at www.
  • Page 14 Pulleys should be mounted in the ceiling and positioned 6” wider than the suspension points on the heater. Chain AND Carabiner Suspension Cable Suspension Cable Suspension Chain AND Carabiner Suspension NOTE: Do not mount this heater directly below electrical wiring that is exposed or in conduit. NOTE: During and after winching, make certain that ALL hoses and power supply cords are NOT resting on the heater nor are within 12”...
  • Page 15 AIR MOVEMENT Position heaters so there is no direct air movement on the heater. Stir fans, inlets and tunnel doors should not blow directly on the units (During minimum ventilation, lock off inlets that affect heater operation.) Check all heaters to be sure flame is not blowing outside the emitter. Do not run heaters during tunnel ventilation.
  • Page 16 THIS HOSE INSTALLATION IS WRONG! The gas supply hose is touching the heater. More of the hose will rest on the heater during winching. THIS HOSE INSTALLATION IS WRONG! The gas supply hose is touching the heater. More of the hose will rest on the heater during winching.
  • Page 17 Each unit requires two Left Deflectors and two Right Deflectors NOTE: Full side of deflec- tors face to the center of the heater. NOTE: Narrow, holed side of the deflectors face toward the outer side of the heater. Page 17 For additional manuals or more information, see our website at www.
  • Page 18 Align tabs of deflectors with slots on heater and insert tab into slots completely so that deflectors are flush against the unit. Using pliers, bend the tabs to secure deflectors to the heater. Bend these tabs toward the outer edge. Bend these tabs toward the inside.

  • Page 19: Maintenance Program

    MAINTENANCE Proper care and maintenance of your heater cannot be over emphasized!! A POORLY MAINTAINED HEATER WILL: - Raise Operating Costs- due to poor combustion. - Lower Air Quality - Cause Inconsistent Temperatures - Decrease the Life of the Heater BEFORE PERFORMING ANY MAINTENANCE ON THE HEATER, MAKE CERTAIN THAT ALL POWER AND FUEL HAS BEEN SHUT OFF TO THE UNIT.
  • Page 20 16550123 CONTROL ASM QDR 16550135 IGNITOR w/BURNER MOUNT & WIRE 120V 5P NAT 1 each 16550105 CONTROL ASM QDR 120V 5P LP (See pages 22, 23 for components) –– 1 each 16550086 16550038 HEAT DEFLECTOR LEFT 16550037 HEAT DEFLECTOR RIGHT SPACER, BURNER/INNER CONE-SHORT 2 each 2 each...
  • Page 21 16550089 16550085 PAN/CHANNEL REFLECTOR 16550082 BOTTOM FLAME SHIELD INNER CONE, CORRUGATED QDR 2 each 1 each 1 each 16550084 EMITTER,PANEL QDRII 16050048 INSULATION, 12 each 2 each END PANEL 16050046 INSULATION, BOTTOM PANEL 1 each 16050047 INSULATION, SIDE PANEL 2 each 16550093 BURNER ASM 1 each...
  • Page 22 16550136 POWER CORD W/TERMINALS –– 1 each 16050055 HOSE GAS 1/4ID 3/8 X 3/8 –– 1 each 16550083 BOX, IGNITION 16550055 CONTROL BOX LID QDR CONTROL QDR II –– 1 each 1 each 10106615 HEYCO STRAIN RELIEF 16550091 HEAT SHIELD, 16550090 BRACKET, CONTROL BOX SHORT SR 7K-2 ––...

  • Page 23: Air Intake

    16-11194 BUSHING: 16550087 AIR INTAKE 13005282 SWITCH TOGGLE GALV STDHEX 3/8 x 1/8 NAT QDR SINGLE POLE –– 1 each 1 each 16550088 AIR INTAKE LP QDR 16550137 VALVE ASCO 120V W/TERMINALS IGNITION MODULE AND 5PSI –– 1 each IGNITION WIRE HARNESS KIT 16550124 16550057 ORIFICE #54...
