Tissue Flotation Bath
TFB 35
Instruction Manual
IMPORTANT: Read this manual before starting the instrument
Rev. 04 (05/2007)
© Copyright: Duplication of this manual by any means for any purpose without
written consent of medite GmbH is prohibited.
Wollenweberstr. 12 - D-31303 Burgdorf -Tel: +49 5136 888 4 0 Fax: + 49 5136 888 4 55 sales@medite.de
www.medite.de
Rev. 04 (06/2006) - DS - TFB35e_Druck03
Advertisement
Table of Contents
Related Manuals for Medite TFB 35
Summary of Contents for Medite TFB 35
- Page 1 © Copyright: Duplication of this manual by any means for any purpose without written consent of medite GmbH is prohibited. Wollenweberstr. 12 - D-31303 Burgdorf -Tel: +49 5136 888 4 0 Fax: + 49 5136 888 4 55 sales@medite.de www.medite.de...
- Page 2 DIN EN ISO 9001 : 2000 VDE 701 M. Ott – Managing Director Burgdorf, 20.05.2007 Wollenweberstr. 12 - D-31303 Burgdorf -Tel: +49 5136 888 4 0 Fax: + 49 5136 888 4 55 sales@medite.de www.medite.de Rev. 04 (06/2006) - DS - TFB35e_Druck03...
-
Page 3: Table Of Contents
Contents Safety 1.1 Introduction 1.2 Intended use 1.3 Authorised operator 1.4 Safety measures on site Transport/Installation 2.1 Technical data 2.2 Transport / Stockage 2.3 Unpacking 2.4 Set up and Connection Operation 3.1. Switching on 3.2. Set temperature controller Errors 4.1. Change fuses 4.2. -
Page 4: Safety
1 Safety 1.1 Introduction With the purchase of the Tissue Flotation Bath TFB 35 you decided for a high quality product of medite Medizintechnik GmbH. These instructions shall help you to use the instrument. Please read it thoroughly and follow the advices. -
Page 5: Technical Data
Power supply: 230 V / 50 Hz / 400 VA or 115 V / 60 Hz / 400 VA 2.2 Transport/ Storage The Tissue Flotation Bath TFB 35 is delivered in a protecting box. Please move it only upright and avoid shock. 2.3 Unpacking Put the instrument on an even, solid surface and remove the protecting box and plastic wrap. -
Page 6: Set Up And Connection
2.4. Installation and Connection Before starting the instrument, please make sure that your mains voltage corresponds to the value indicated on the instrument (example: for an instrument requiring 240 Volts, 200 - 240 Volts should be available; for a 115 Volts instrument, there should be 100 - 125 Volts.) The instrument is supplied ready to use. -
Page 7: Operation
3 Operation Removable glass tray Illumination by fluorescent lamp Electronic temperature control 3.1 Switching on Press the mains switch at the rear of the instrument. The unit is now in standby mode, which is indicated by the message OFF on the display of the controller. -
Page 8: Set Temperature Controller
3.2 Adjust the temperature controller The instrument can be switched on by pressing the power switch to position “I” at the back of the instrument. The illuminated switch lightens up, indicating that the instrument is ready to use. The temperature of the working plate is infinitely variable in 1°C steps between +30C and 90... -
Page 9: Errors
4 Errors 4.1 Change of fuses CAUTION! FIRST PULL OUT THE MAINS PLUG ! In case of a failure first check the fuses in the mains socket at the back of the instrument and change them if necessary. Fuse Holder In case of any other defect please contact the service department. -
Page 10: Exchanging The Neon Tube
8 Putting out of operation After end of the total period of use please deliver the equipment to a regular disposal facility. The company medite as manufacturer is also prepared to take back the equipment for disposal against payment for the disposal fee. -
Page 11: Wiring Diagram
9 Wiring diagram Rev. 04 (06/2006) - DS - TFB35e_Druck03... - Page 12 295 x 235 mm Weight : 15 kg Voltage : 230V / 50Hz / 750VA Wollenweberstr. 12 - D-31303 Burgdorf -Tel: +49 5136 888 4 0 Fax: + 49 5136 888 4 55 sales@medite.de www.medite.de Rev. 04 (06/2006) - DS - TFB35e_Druck03...
