Summary of Contents for ABitTop PS2Netbox

  • Page 1 PS2NETBOX Game loader Email:sales@abittop.com...
  • Page 2 PS2Netbox User Manual V1.2...
  • Page 3: Table Of Contents

    Table of contents I. Introduction to product ............................... 1 II. The main functions ................................1 Game data is provided through the network cable ....................1 Extreme convenient installing for games ....................... 1 Virtual USB flash disk ............................. 1 Support PS1 games ..............................1 Friendly game selection interface ...........................
  • Page 4 Does it have the function of booting from Mass in all modded PS2 consoles? ........... 10 What are the advantages compared to the hard disk drive PHAT PS2 console? ........10 What are the advantages compared to USB flash disk for playing games? ..........10 What are the advantages compared to Samba method?...
  • Page 5: Introduction To Product

    I. Introduction to product PS2Netbox is a kind of storage device which supports the connection with PS2 console through network cable and USB cable to facilitate the collection and management of game-related resources. The device is suitable for the use with the full range of PS2 console for game image storage, self-defined game list theme, game cover display, etc.
  • Page 6: The Theme Of Game List Interface Can Be Customized

    6. The theme of game list interface can be customized After the theme resource is copied to the directory of OPL\THM, the designated theme selected in OPL software can be used to present game selection interface. 7. Game cover can be customized After the game cover image file is copied to the directory of OPL\ART, the game cover can be displayed on the game selection interface.
  • Page 7: Equipped With 9W Ps2 Console With Bios Version 230

     No external power simplified connection, powered off with the PS2 console synchronously, safe to use PS2Netbox Disks Compatibi Good Good...
  • Page 8: Product Specifications

    used Update USB cable connected Remove hard disk Purchase game disk According to SMB game to the PC, drag and drive, install hard or burn new game device drop operation disk drive cartridge disk and connect it to PC, dedicated software is used for recording Ease Automatic...
  • Page 9: Usage Instructions

    VI. Usage instructions 1. Hard disk drive preparation The device supports the use of 2.5-inch hard disk drive (laptop hard disk drive), including IDE interface and SATA interface hard disk drives. The hard disk drive needs to be fixed on the device’s bracket and covered with casing. Then the device is connected to PC through USB cable and PC will recognize it as the mobile hard disk drive.
  • Page 10: Selection Of Booting Methods

    4. Selection of booting methods 1) USB flash disk booting The PS2 console has been modded and supports USB flash disk booting, so it can set to USB flash disk booting method. The USB cable data port of the device needs to be plugged in the PS2 console. The game list is displayed immediately after startup. 2) FMCB memory card booting The USB cable data port of the device needs to be plugged in the PS2 console.
  • Page 11: Express Installation

    VII. Express installation (only two collocations are shown) 1. FMCB memory card booting, with PS2 special format hard disk drive Unscrew the casing to disassemble the device. Install the hard disk drive on the bracket of the device, and tighten the hard disk drive fixing screws. Install the device casing, and tighten the case screws.
  • Page 12: Is Game Downloading Service Provided

    2. Is game downloading service provided? Users can download the games from the Internet, what’s more, the full sorted collection can be purchased from some online stores. The product has no bundling sales of games for the consideration of copyright. 3.
  • Page 13: Does It Support Igr Shortcut Key Operation

    9. Does it support IGR shortcut key operation? The device supports the press R1+R2+L1+L2+Select+Start to return to the game list interface during the game. Press R1+R2+L1+L2+R3+L3 during the game to shut down, power off the PS2 console and the power indicator turns to red. 10.
  • Page 14: Does It Have The Function Of Booting From Mass In All Modded Ps2 Consoles

    15. Does it have the function of booting from Mass in all modded PS2 consoles? Not all the modded PS2 consoles support this function. For example, Modbo5.0 PS2 consoles have such function, partial versions of Modbo4.0 have such function, while other Modbo ones do not have such function. It is recommended to use the memory card to automatically boot the software, which is adapted to most PS2 consoles, and the booting speed is much faster.
  • Page 15: Does It Support Any Type Of Ps2 Consoles In 7W, 9W

    reading or reading error. Each game needs one disks to save, which is inconvenient to save and select game. The device is equipped with one 2T hard disk drive which can store 600-700 games and provides convenience for users to preview games and select the interesting programs for entertainment.
  • Page 16: Game Peripherals (Light Gun, Steering Wheel) Of Usb Interface Cannot Work

    27. Game peripherals (light gun, steering wheel) of USB interface cannot work Just connect the USB auxiliary power port of the device to PS2 console, or power on the device with external power. Make sure that the PS2 console USB peripherals do not work is not because of virtual USB flash disk function of the device. Users can also disable the device’s USB function in the tool settings of device’s customized OPL software.
  • Page 17: Drawing

    X. Drawing 1. Appearance of the device 13 / 19...
  • Page 18: Internal Diagram Of The Device

    2. Internal diagram of the device 3. Accessories and interfaces 14 / 19...
  • Page 19: Installation Diagram

    4. Installation diagram SATA 接 IDE 接 口硬盘 口硬盘 SATA 接口 接口 15 / 19...
  • Page 20: Splash Screen

    网线 辅助供电 数据 及扩展 接口 USB 接口 5. Splash screen 16 / 19...
  • Page 21: Game List Interface Of Some Theme

    6. Game list interface of some theme 7. Software settings interface 17 / 19...
  • Page 22 18 / 19...
  • Page 23 19 / 19...
