- Page 1 MKE-5 Digital Indicator All Platform Models Parts Counting Manual 59 Second Street East Rockaway, NY 11518 (800) 645-4301 www.arlynscales.com v3.0.72317...
-
Page 2: Table Of Contents
CONTENTS INTRODUCTION ....................................3 PARTS COUNTING: OVERVIEW ................................3 CONTROLS AND INDICATORS ................................4 ....................................4 OUNTING CREENS ....................................4 RONT ANEL EYBOARD QUICK SAMPLE COUNTING .................................. 5 WORKING WITH SAMPLES IN MEMORY ............................... 5 .................................. 5 REATING A EFAULT AMPLE ) .................................. -
Page 3: Introduction
INTRODUCTION Thank you for choosing an Arlyn Scale for your parts counting needs. This manual is meant as a supplement to the regular instruction manual. If this is your first time using parts counting with this scale, we suggest that you proceed with the section titled "Quick Start: Counting Parts by Quick Sample"... -
Page 4: Controls And Indicators
CONTROLS AND INDICATORS The Counting Screens This is the counting screen. You will be taken here automatically whenever you activate a sample. If not, you can get there by: 1) Press the MENU key to bring up the main menu. 2) The first option, NEXT SCREEN, is already highlighted. -
Page 5: Quick Sample Counting
QUICK SAMPLE COUNTING This is a slightly more detailed description of Quick Sample Counting than that given in the Quick Start section below. This function is a quick method of acquiring a sample and activating counting mode at the same time. The sample size is limited to 10, 25, 50 or 100 pieces. -
Page 6: Editing Its Value (Piece Weight)
The NEW function will only create the new sample. It will not assign it any values. Editing its Value (piece weight) There are two ways to do this. You can enter the piece weight directly or you can have the scale automatically calculate it for you. Enter its Piece Weight Directly* If you know the exact weight of the piece you may enter it directly. -
Page 7: Text Editor Screen
Text Editor Screen The current description is shown at the top of the screen with an arrow pointing at the first character. This arrow is your cursor position. The lower part of the screen contains the entire character set with the current selection highlighted. Editing the description is similar to techniques commonly seen in video games, cell phones and the like. -
Page 8: Tips And Rules For Acquiring Samples
TIPS AND RULES FOR ACQUIRING SAMPLES Before a part can be counted, the scale needs to know how much each piece weighs. This process is known as Sample Acquisition. Samples can be taken quickly through a few key presses (Quick Sample) or they may be defined, named and stored in memory. Acquiring an accurate sample is essential for parts counting and there are a few basic rules that should be followed. -
Page 9: Multiple Platform Counting
MULTIPLE PLATFORM COUNTING Some scales are equipped with two or more platforms. In most cases there is a small capacity platform and a large capacity platform. Samples can be taken, or parts counted, on either platform. It is always recommended to acquire samples on the small capacity platform, if possible, to get the maximum accuracy. But you may use either one. -
Page 10: Minimum Piece Weights
There are no entries for parts counting in any menu Your counting mode may not be enabled. In addition to the additional circuitry required for counting scales there is a software switch that must be enabled. It may have been shut down by accident while working with a technician over the phone or was accidentally switched off during recent service at our factory. -
Page 11: Quick Start: Defining And Using Samples With A 10-Piece Sample
4) Make sure that the platform is empty, then press the ENTER key. 5) Place the ten pieces on the platform. Give it a second to stabilize and then press the ENTER key. The scale will calculate the piece weight and then switch to the counting screen. 6) Remove the parts from the platform and then press the ZERO key.
