Stanley Electric LLF0017A/LEN1/104/E/IN/A Instruction Manual

Stanley Electric Co., Ltd.
●Installation of this product/ luminaire must be carried out by a qualified electrician in accordance with the national, local
electric and construction codes and regulations. Installation by unqualified person is prohibited by law.
Product name
LLF0017A/LEN1/104/E/IN/A
LLF0017A/LEN1/80/E/IN/A
LLF0017A/LEN1/72/E/IN/A
Overall dimensions
Maximum projected area
IP classification
IK classification(Glass cover)
Operating ambient temperature
Mounting height
Mounting device(Side-entry for diameter)
Installation instructions
Attention at installation
WARNING
●Please ensure installation is in accordance with mounting instruction. –Risk of product fall or fire.
●Do not use the product under the following environment and situation. It will cause electric shock and fire.
The unit will fall or not operate if not installed properly:
・Place exposed directly to organic solvent (Acetone, Ethyl ether, Hexane, etc.).
・Place where corrosive gas (Hydrogen sulfide, Chlorine, Ammonia, etc.)
and flammable gas (Hydrogen, Methane, etc.) is present.
・Places where flammable liquid (Gasoline, Kerosene, Fuel oil, etc.) is used.
・Places where humidity exceeds 90% or the product is affected by flood.
・Places covered by heat insulator and combustible material.
・Places where the product is buried under snow.
●Don't set it up in the place where the hazard is caused when the icicle drops. It causes the injury by the icicle fall.
●The insulation of the AC cable connected to the luminaire must be free from damage or cracks. -Risk of electric shock and fire.
●Do not disassemble this product, repair or replace any of its components. -Risk of electric shock, fire or the product fall.
●Do not use the product when broken or appears damaged in any way. -Risk of product fall, electric shock and fire.
●Please use the cable indicated on operation method with the performance beyond equality for a used cable.
It causes the electric shock, a fire, not lighting when other cables are used.
●When abnormality occurs, turn off the power immediately and contact your distributor for assistance. Continued use of
the product risks electric shock and fire.
●Do not connect to power source other than specified for the product. –Risk of electric shock, fire and product will not illuminate.
●Front glass may be broken if a strong shock is applied.
Please be careful handling so as not to scratch it when carrying or installing the instrument.
CAUTION
●IP classification is IP66. It can not be used as more than IP66 and underwater lighting equipment.
●Wind pressure resistance is 60m/s. Risk of product fall.
●Be sure to turn off the power supply during product installation or removal. There is a possibility that the product is
damaged when the installation or removal of the lighting is done with the power supply turned on. It causes the electric
shock, and a fire.
●The luminaire should be positioned so that prolonged staring into the luminaire at a distance closer than ○ m is not expected.
●The surface of the product becomes a high temperature immediately after lighting and turning off. Please note it enough.
●Please don't use for a hot spring including sulfur constituent. The brightness becomes dark and causes a life expectancy
decline.
●Please don't install apparatus for the sun. Sunlight concentrates, and an LED is damaged and causes the not lighting and fire.
Instruction manual
Power
90W
70W
42W
Installer, please save a copy this instructions manual for retention and reference by the end user.
Incorrect handling of this product may cause serious personal injury, death and/ or damage
to the product and property.
There is a possibility that it is assumed to owe injury.
Road Light
Rated voltage Rated current
220V～ 0.42A
220V～ 0.32A
220V～ 0.19A
For retention and reference
frequency
50/60Hz
50/60Hz
50/60Hz
486mm × 277mm × 86mm
0.033m
2
IP66
IK08
－40～55℃
6～12m
Φ60.5mm × 100mm
No. D00189637B
Weight
5.0kg
4.9kg
4.7kg
1/5
