DOPPLER

DOPPLER SYSTEMS

DOPPLER

DDF7000 (MPT)

DDF7000

USER'S 'S 'S 'S MANUAL

USER

Doppler Systems LLC / PO Box 2780 / Carefree, AZ 85377

Revision A: July 19, 2013

Revision B: October 17, 2013

Revision C: June 26, 2015

Revision D: July 30, 2017

Revision E: January 17, 2020

SYSTEMS

(MPT)

MANUAL

Table of Contents

Need help?

Do you have a question about the DDF7000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Doppler Systems DDF7000

Page 1 USER USER MANUAL MANUAL © December 3, 2011 Doppler Systems LLC / PO Box 2780 / Carefree, AZ 85377 Revision A: July 19, 2013 Revision B: October 17, 2013 Revision C: June 26, 2015 Revision D: July 30, 2017 Revision E: January 17, 2020...
Page 2: Table Of Contents
Doppler MPT Users Manual Revision D CONTENTS CONTENTS CONTENTS CONTENTS W W W W ARRANTY INFORMATION ARRANTY INFORMATION ARRANTY INFORMATION ........ ARRANTY INFORMATION ................................................................................1 1 1 1 ....INTRODUCTION INTRODUCTION INTRODUCTION INTRODUCTION ........
Page 3 Doppler MPT Users Manual Revision D Connecting the Slave to the Master ....................45 Operation Behind a Firewall ......................45 CONFIGURING TH CONFIGURING TH CONFIGURING TH CONFIGURING THE DIRECTION FINDER E DIRECTION FINDER E DIRECTION FINDER ........ E DIRECTION FINDER ........
Page 4 Doppler MPT Users Manual Revision D Figures Figure 1: Arrangement of Mobile Antennas ................6 Figure 2: VHF Mobile Antenna Installation................7 Figure 3: THF Mobile Antenna Installation ................7 Figure 4: Remove the longer cap screws to install the lower mast ........10 Figure 5: Secure the lower mast to the frame using the cap screws ........
Page 5: Arranty Information
WARRANTY INFORMATION WARRANTY INFORMATION Doppler Systems will repair or replace, at their option, any parts found to be defective in either materials or workmanship for a period of one year from the date of shipping. Defective parts must be returned for replacement. In the US, contact the factory, or overseas your local distributor, for advice about returning any defective parts or equipment.
Page 6 Doppler MPT Users Manual Revision D Chapter 1 1 1 1 Chapter Chapter Chapter INTRODUCTION INTRODUCTION INTRODUCTION INTRODUCTION The Series 7000 is a high performance radio direction finding system that operates using the synthetic Doppler principle in which a circular array of antennas are combined in a way that simulates a single element rotating in a circular path.
Page 7 Introduction Designed to work with standard commercial narrow band FM receivers • Highly configurable allowing for autonomous operation and multiple networking options • Master-Slave configuration allows up to 32 frequencies to be monitored simultaneously using • one antenna.
Page 8 Doppler MPT Users Manual Revision D Chapter Chapter 2 2 2 2 Chapter Chapter SPECIFICATIONS SPECIFICATIONS SPECIFICATIONS SPECIFICATIONS DF Method Synthetic-Doppler with patented "Smooth Summing" Frequency Range 125 - 1000 MHz 1 deg rms (8 element antenna) Accuracy 2.5 deg rms (4 element antenna) Resolution 0.1 deg Sampling Rate...
Page 9: Mobile Antenna Installation
It is especially important that the coaxes used have the same length. Doppler Systems antennas DDF7061 and 7062 use the same magnetic mount base and cover the frequency ranges 88-136 and 136-500 MHz respectively. Cut the whips to resonance using the chart provided with the antennas and space them approximately 1/8 to 1/4 wavelength apart on the car’s roof.
Page 10: Figure 1: Arrangement Of Mobile Antennas
Doppler MPT Users Manual Revision D not free to move around and touch the antenna elements. Route the control and RF cables through a rear window. For mobile operation in the 700-1000 MHz band, antenna DDF7064 should be mounted directly on top of the RF summer. This antenna provides an extended ground plane, a wind shroud, and four stub type antennas built into TNC connectors.
Page 11: Figure 2: Vhf Mobile Antenna Installation
Chapter 3 Mobile Antenna Installation The photos below show typical installations. Figure 2: VHF Mobile Antenna Installation Figure 3: THF Mobile Antenna Installation...
Page 13: Fixed Site Antenna Assembly Fixed Site Antenna Assembly
Chapter Chapter 4 4 4 4 Chapter Chapter FIXED SITE ANTENNA ASSEMBLY FIXED SITE ANTENNA ASSEMBLY FIXED SITE ANTENNA ASSEMBLY FIXED SITE ANTENNA ASSEMBLY Fixed site antennas are shipped unassembled. This section provides assembly instructions. IN THIS CHAPTER IN THIS CHAPTER IN THIS CHAPTER IN THIS CHAPTER Antenna Mounting Location .................
Page 14: Figure 4: Remove The Longer Cap Screws To Install The Lower Mast
Doppler MPT Users Manual Revision D Figure 4: Remove the longer cap screws to install the lower mast...
Page 15: Figure 5: Secure The Lower Mast To The Frame Using The Cap Screws
Fixed Site Antenna Assembly Next position the bottom mast to fit over the connectors and drain plug and fasten the mast to  the antenna frame using the screws and lockwashers from step 1. The figure below shows the mast connected to the frame. Figure 5: Secure the lower mast to the frame using the cap screws...
Page 16: Attaching The Bottom Mast To Your Mast
Doppler MPT Users Manual Revision D ATTACHING THE BOTTOM MAST ATTACHING THE BOTTOM MAST ATTACHING THE BOTTOM MAST ATTACHING THE BOTTOM MAST TO YOUR MAST TO YOUR MAST TO YOUR MAST TO YOUR MAST The fixed site antennas are furnished with a mast clamp for installation on a pipe or pole. The diameter of the pipe or pole can be between 1.25 in.
Page 17: Attaching The Cables
Fixed Site Antenna Assembly ATTACHING THE CABLES ATTACHING THE CABLES ATTACHING THE CABLES ATTACHING THE CABLES Unroll the control and coax cables being careful not to damage the ferrites or to crimp the coax. Be careful to keep the connectors clean from dirt. Fasten the control cable by aligning the key and turning the outer locking ring until it just meets the red line on the mating connector.
Page 18: Figure 8: Arrangement Of The Antenna Element Mounting Hardware
Doppler MPT Users Manual Revision D Figure 8: Arrangement of the antenna element mounting hardware...
Page 19: Figure 9: Three Wire Element Mounting Arrangement
Fixed Site Antenna Assembly Three Wire Biconical Elements The antenna elements are mounted to baluns at the end of the frame arms using a 5/16-24 cap screw, a flat washer and a rubber washer. The arrangement of the hardware is shown in the photo below.
Page 20: Figure 10: Antenna Element Mounted On The Balun
Doppler MPT Users Manual Revision D Thread the cap screw into the balun being careful not to cross thread the screw. Tighten the cap screw until the lock washer is fully compressed. Do not over tighten the cap screw or the brass threads in the balun may be stripped.
Page 21: Figure 11: Fully Assembled Vhf Antenna
Fixed Site Antenna Assembly After all the elements are attached the antenna is ready to be erected. The assembled antenna will look similar to the photo below. Figure 11: Fully Assembled VHF Antenna...
Page 22: Two Band Antenna Installation
Doppler MPT Users Manual Revision D TWO BAND ANTENNA INSTALLATION TWO BAND ANTENNA INSTALLATION TWO BAND ANTENNA INSTALLATION TWO BAND ANTENNA INSTALLATION To assemble the two band antenna perform the steps detailed above; however, before attaching the antenna elements install the connecting mast and cables. The connecting mast is installed similarly to the base mast using the 5 longer screws and lock washers at each end.
Page 23: Figure 13: Assembled Uhf-Vhf Antenna
Fixed Site Antenna Assembly Next connect the UHF antenna frame to the coupling mast, connect the cables, fasten them with cable ties, and then install the antenna elements on both VHF and UHF frames. The completed antenna stack is shown below. Figure 13: Assembled UHF-VHF Antenna...
Page 24: Three Band Antenna Installation
THREE BAND ANTENNA INSTALLATION THREE BAND ANTENNA INSTALLATION THREE BAND ANTENNA INSTALLATION THREE BAND ANTENNA INSTALLATION Follow the steps above to install the three element antenna and simply install the third antenna using the short connecting mast supplied. Figure 14: UHF Antenna Frame Installed on Mast...
Page 25: Figure 15: Uhf To Thf Mast With Cables
Fixed Site Antenna Assembly Figure 15: UHF to THF mast with cables...
Page 26: Figure 16: Thf Antenna Frame Installed
Doppler MPT Users Manual User's Guide Figure 16: THF Antenna Frame Installed...
Page 27: Figure 17: Thf Element Mounting Hardware
Fixed Site Antenna Assembly There are two styles of THF elements. One style of elements mount similar to the other elements except that they have longer cap screws. The other style shown in Figure 16 below have a rubber washer installed to preload the elements and to keep moisture out of the threads. Do not over tighten the elements or you may strip the brass inserts in the balun.
Page 28: Marine Band Antenna Assembly Marine Band Antenna Assembly Band Antenna Assembly
Doppler MPT Users Manual Revision D Chapter 5 5 5 5 Chapter Chapter Chapter MARINE BAND ANTENNA ASSEMBLY MARINE BAND ANTENNA ASSEMBLY MARINE BAND ANTENNA ASSEMBLY MARINE BAND ANTENNA ASSEMBLY This chapter describes the assembly and installation of the four element marine band antenna. IN THIS CHAPTER IN THIS CHAPTER IN THIS CHAPTER...
Page 29: Mounting The Mast To The Antenna
Marine Band Antenna Assembly MOUNTING THE MAST TO THE ANTENNA MOUNTING THE MAST TO THE ANTENNA MOUNTING THE MAST TO THE ANTENNA MOUNTING THE MAST TO THE ANTENNA At the base of the antenna frame there are five longer screws protruding from the bottom connector plate as shown in the photo below.
Page 30: Figure 19: Install The Base Mast On To The Antenna Using The Long Screws
Doppler MPT Users Manual Revision D Place the mast on the bottom of the antenna and use the long screws to secure the mast to the base as shown below. Figure 19: Install the base mast on to the antenna using the long screws...
Page 31: Attaching The Antenna Mast To Your Mast
Marine Band Antenna Assembly ATTACHING THE ANTENNA MAST TO YOUR MAST ATTACHING THE ANTENNA MAST TO YOUR MAST ATTACHING THE ANTENNA MAST TO YOUR MAST ATTACHING THE ANTENNA MAST TO YOUR MAST The antenna is furnished with a mast clamp for installation on a pipe or pole. The diameter of the pipe or pole can be between 1.25 in.
Page 32: Mounting The Elements And Connecting The Cables
Doppler MPT Users Manual Revision D MOUNTING THE ELEMENTS AND CONNECTING THE CABLES MOUNTING THE ELEMENTS AND CONNECTING THE CABLES MOUNTING THE ELEMENTS AND CONNECTING THE CABLES MOUNTING THE ELEMENTS AND CONNECTING THE CABLES There are eight vertical antenna elements. Each element has a threaded insert. Screw the threaded inserts into the baluns (black boxes) at the end of the antenna arms.
Page 33: Ddf7001 Processor Connections Ddf7001 Processor Connections
DDF7001 Processor Connections Chapter 6 6 6 6 Chapter Chapter Chapter DDF7001 DDF7001 PROCESSOR CONN PROCESSOR CONNECTIONS ECTIONS DDF7001 DDF7001 PROCESSOR CONN PROCESSOR CONN ECTIONS ECTIONS The DDF7001 processor requires a 12 V power supply, a loud speaker or headphones, a receiver, and a Windows based computer.
Page 34: Figure 24: Direction Finder With Rs232 Receiver
Doppler MPT Users Manual Revision D Figure 24: Direction Finder with RS232 receiver...
Page 35: Figure 25: Single Antenna Fixed Site System With Lan Connection
DDF7001 Processor Connections Figure 25: Single Antenna Fixed Site System with LAN Connection...
Page 36: Figure 26: Three Antenna Fixed Site Installation
Doppler MPT Users Manual Revision D DDF7095 Antenna Control Coax Antenna Control Coax Antenna Coax Receiver Control Audio Processor 12VDC DDF7001 Crossover Cable Figure 26: Three Antenna Fixed Site Installation...
Page 37: Figure 27: Basic Mobile Installation For Homing
DDF7001 Processor Connections Mag Mounted Antennas Mag Mounted Summer DDF7080 Coax Control Receiver Audio Processor 12VDC DDF7001 Laptop Crossover Cable Figure 27: Basic Mobile Installation for Homing Mag Mounted Antennas Mag Mounted Summer Coax Receiver Control RS232 Audio USB-to- Serial Processor 12VDC Crossover...
Page 38: Power And Speaker Connection
Doppler MPT Users Manual Revision D IN THIS CHAPTER IN THIS CHAPTER IN THIS CHAPTER IN THIS CHAPTER Power and Speaker Connection ............... 34 Receiver Connection ................... 34 Computer Connection..................35 NMEA Devices ...................... 37 POWER AND SPEAKER CONNECTION POWER AND SPEAKER CONNECTION POWER AND SPEAKER CONNECTION POWER AND SPEAKER CONNECTION A power and speaker cable is furnished with the DDF7001.
Page 39: Computer Connection
DDF7001 Processor Connections RSSIinput CAB170 (AWG22 BLU) TWISTED Ground CAB354 (AWG22 WHT) PAIR View from Wiring End. 5 ft end to end CON270/264 Audhigh CAB355 (AWG22ORG) TWISTED Audlow CAB302 (AWG22VIO) PAIR CON281 (3.5mm) CON270 is Molex 39012065 receptacle. CON264 are Molex 39000182 female terminals. CON281 is Kobicon 171-3235-EX 3.5mm mono plug.
Page 40: Figure 32: Doppler Df Discover Will Display All Direction Finders Connected On A Lan
Doppler MPT Users Manual The Ethernet software in the DDF7001 ships with a DHCP client enabled, so if connected to a network that supports DHCP, the DDF7001 will obtain an IP address from the DHCP server. Once it has done this it begins broadcasting its IP address on the network as a UDP broadcast message on port 9007.
Page 41: Figure 34: Network Interface Setup In Windows
DDF7001 Processor Connections The DDF7001 is shipped with a default IP address of 10.0.0.100. If you are going to connect it directly to your computer you must set your computer TCP/IP properties as shown in Figure 34 below. Once it is connected you can use the web server or the MPT User Interface software to change the IP address and the IP port number.
Page 42: Connecting Usb Devices To The Ddf7001
AOR DV1 Receiver EasySync USB2-H-1004 4 port USB-to-Serial Adaptor EasySync ES-U-1001-B10 1 port USB-to-Serial Adaptor Doppler Systems DDF6074 GPS Receiver (with serial adaptor) Doppler Systems DDF6075 Compass (with serial adaptor) Doppler Systems DDF7057 Self-Test Generator Doppler Systems DDF7056 Yaw Rate Sensor...
Page 43: Usb-To-Serial Converters
USB- - - - TO TO- - - - SERIAL CONVERTERS SERIAL CONVERTERS SERIAL CONVERTERS SERIAL CONVERTERS USB-to-Serial converters are used for interfacing serial receivers like the ICOM R8500 or AOR AR5000  connecting NMEA based devices such as a GPS receiver or a compass ...
Page 44: Usb Receivers
Doppler MPT Users Manual The DDF7056 Yaw Rate Sensor is used to provide a faster update of the heading in mobile applications where the vehicle is performing frequent turns. This device outputs an NMEA message; however, its baud rate is 38.4 k. Therefore, the MPT User Interface software must be used to set the baud rate to 38.4 k prior to using the yaw rate sensor.
Page 45: Serial Receivers
Chapter 6 Connecting USB Devices to the DDF7001 Remove this jumper SERIAL SERIAL SERIAL SERIAL RECEIVERS RECEIVERS RECEIVERS RECEIVERS The DDF7001 currently supports the ICOM R8500, ICOM R9500, AOR AR8600, and the AOR AR500 RS232 commanded receivers. The DDF7001 configures the receiver to receive narrow band FM transmissions required for the direction finder to work properly.
Page 46: Using The Mpt As A Slave Processor Using The Mpt As A Slave Processor
Doppler MPT Users Manual Chapter Chapter 7 7 7 7 Chapter Chapter USING THE MPT AS A SLAVE PROCESSOR USING THE MPT AS A SLAVE PROCESSOR USING THE MPT AS A SLAVE PROCESSOR USING THE MPT AS A SLAVE PROCESSOR...
Page 47: Changing The Processor To The Slave Configuration
Multiple DDF7000 direction finding processors can share a common antenna. A block diagram of two DDF7000 processors sharing one antenna is shown below. To share a common antenna One DDF7000 processor must be configured as a master (DDF7001) and all other...
Page 48 Doppler MPT Users Manual Revision D J5 in master position J5 in slave position...
Page 49: Connecting The Slave To The Master
4. Replace the cover, insert and tighten the four cover screws. CONNECTING THE SLAVE TO THE MASTER CONNECTING THE SLAVE TO THE MASTER CONNECTING THE SLAVE TO THE MASTER CONNECTING THE SLAVE TO THE MASTER The slave processor is shipped with a slave cable. If you are attempting to convert a master processor to a slave processor in the field, contact the factory to purchase one of these cables.
Page 50: E Direction Finder
Doppler MPT Users Manual Chapter 8 8 8 8 Chapter Chapter Chapter CONFIGURING THE DIRECTION FINDER CONFIGURING THE DIRECTION FINDER CONFIGURING THE DIRECTION FINDER CONFIGURING THE DIRECTION FINDER The software configuration of the DDF7001 is described in the MPT Software User's Manual and the help file that is installed with the MPT User Interface software.
Page 51: Interfacing To The Ddf7001 Direction Finder
Chapter 9 Interfacing to the DDF7001 Direction Finder Chapter Chapter 9 9 9 9 Chapter Chapter INTERFACING TO THE INTERFACING TO THE DDF7001 DDF7001 DIRECTION FINDER DIRECTION FINDER INTERFACING TO THE INTERFACING TO THE DDF7001 DDF7001 DIRECTION FINDER DIRECTION FINDER This chapter is provided for the user that wants to develop their own software to interface with the DDF7001 direction finder.
Page 52: Command And Data Structure
Doppler MPT Users Manual Revision C COMMAND AND DATA STRUCTURE COMMAND AND DATA STRUCTURE COMMAND AND DATA STRUCTURE COMMAND AND DATA STRUCTURE Every DDF7001 command and the data coming from the DDF7001 conform to the data structure as shown in the following table. Byte # Definition Comments...
Page 53 Interfacing to the DDF7001 Direction Finder 0xEC81, 0x2C40, 0xE401, 0x24C0, 0x2580, 0xE541, 0x2700, 0xE7C1, 0xE681, 0x2640, 0x2200, 0xE2C1, 0xE381, 0x2340, 0xE101, 0x21C0, 0x2080, 0xE041, 0xA001, 0x60C0, 0x6180, 0xA141, 0x6300, 0xA3C1, 0xA281, 0x6240, 0x6600, 0xA6C1, 0xA781, 0x6740, 0xA501, 0x65C0, 0x6480, 0xA441, 0x6C00, 0xACC1, 0xAD81, 0x6D40, 0xAF01, 0x6FC0, 0x6E80, 0xAE41, 0xAA01, 0x6AC0, 0x6B80, 0xAB41, 0x6900, 0xA9C1, 0xA881, 0x6840, 0x7800, 0xB8C1, 0xB981, 0x7940, 0xBB01,...
Page 54: Commands
Doppler MPT Users Manual Revision C COMMANDS COMMANDS COMMANDS COMMANDS The following table defines the commands that can be sent to the DDF7001. The DDF7001 responds by echoing back the command with the value that was accepted by the DDF7001. If the DDF7001 did not accept the command then nothing will be echoed back.
Page 55 Command Command Data Range Comments Name Number Length 0=250,1=500. 2=1000 ,3=2000 Sweep Rate 0x0001 byte Default is 2 Averages 0x0002 byte 1-20 Attenuator 0x0003 byte 0 – 1 0 = off , 1 = on Audio Volume 0x0004 byte 0 – 96 0 = max volume, 96 = muted, default 20 Reserved for future use 0x0005...
Page 56 Doppler MPT Users Manual Revision C Reserved for future use 0x000B Direction Cosines 0x000C 4 INT16 -10000 - 10000 Range is -1 to 1 (divide by 10000) Each receiver has calibrated direction cosines. Typically the user does not need to change these Calibrate 0x000D INT16...
Page 57 Interfacing to the DDF7001 Direction Finder Configure Serial Port 0x0011 6 bytes Byte 0 : port number (0 - 3) The DDF7001 supports up to a 4 port USB-to-serial converter. Byte 1 : Baud Rate 0 = 1200 1 = 2400 2 = 4800 3 = 9600 4 = 19200...
Page 58 Doppler MPT Users Manual Revision C Receiver Pass Through 0x0017 Various Sends command directly to receiver Sweep 0x0018 byte Nibble 0 : Direction Manual command to start the sweep 0 = CW Used in factory testing. Not recommended for use by user. 1 = CCW Nibble 1: Sweep State 0 = Sweep Off...
Page 59 Interfacing to the DDF7001 Direction Finder Serial Pass Through 0x0026 Various byte 0: port Number remaining bytes serial port data Send Serial Number 0x0027 Sends the serial number of the unit Stream Audio 0x0028 UINT16 Port number to stream audio to 0 = disable streaming Default 50 Streaming Audio Squelch...
Page 60: Responses
RESPONSES RESPONSES RESPONSES RESPONSES With the exception of commands that specifically ask for data to be sent the response to a command is that it will echo the data back in the exact format it was sent with the actual settings of the DDF7001.
Page 61 Response Name Response Number Format Comments Bearing Message 0x0000 ASCII Comma delimited string Bearing (0-359.9), S meter (0-255), Number of Averages (1-20), Audio Level (0-2047) UTC Timestamp (if GPS receiver is connected) Latitude (if GPS receiver is connected) (100 if latitude not detected) Longitude (if GPS receiver is connected) (190 if longitude not detected) Heading (if GPS receiver is connected) (-1 if no heading is available) Direction of Rotation (if averages are set to 1)
Page 62 Doppler MPT Users Manual Revision C Cmd number,setting<CR> S Meter Cal Constants 0x0019 ASCII Two comma separated strings representing the slope and intercept constants in exponent format (e.g. 1.23e- 1,1.045e3) Receiver Data 0x0017 Bytes Data received from the receiver that is passed through the DDF7001 RX Settings 0x0022 ASCII...
Page 63: Audio Interface
AUDIO INTERFACE AUDIO INTERFACE AUDIO INTERFACE AUDIO INTERFACE The DDF7001 digitizes the receiver audio and can stream it via UDP. Once a TCP/IP connection is made the controller sends a Stream Audio (0x0028) command to the DDF7001 signaling the DDF7001 as to which port to use to stream the audio. Once this command is received the DDF7001 will stream the audio when the audio level exceeds the audio squelch threshold.
Page 64: Index Index
INDEX INDEX INDEX INDEX SINGLE BAND ANTENNA INSTALLATION • 9 ANTENNA MOUNTING LOCATION • 9 ATTACHING THE ANTENNA MAST TO YOUR MAST • 27 THREE BAND ANTENNA INSTALLATION • ATTACHING THE BOTTOM MAST TO A YOUR MAST • 12 TWO BAND ANTENNA INSTALLATION • ATTACHING THE ELEMENTS •...
