Luxlink IRGP-1501 Operating Instructions

WARRANTY

All fiber optic transmission systems, products and accessories
manufactured by Liteway, Inc. and it's subsidiaries are fully tested prior
to shipment and are warranted against defective materials and
workmanship for a period of five full years from the date of the original
shipment. Should a problem occur, a Return Material Authorization
Number (RMA) must be obtained from Liteway Inc. at (516) 931-2800
and the item returned to Liteway, Inc. 166 Haverford Road, Hicksville,
NY 11801, USA, prepaid. Liteway Inc. will then, at its option repair or
replace the defective item.
Liteway, Inc. maximum liability under this warranty is limited to the cost
of the defective item only. No contingent liabilities of any kind are either
assumed or implied.
Any items returned to Liteway, Inc. that have been misused, abused,
damaged, modified, connected or adjusted in any way contrary to the
instructions furnished by Liteway, Inc. or repaired by unauthorized
personnel will not be covered by this warranty. Any non-warranty
repairs required will be quoted at the current rate for such services.
!

Important Notices

CAUTION ! AVOID DIRECT EXPOSURE TO BEAM.
All -7,-8, and -9 Models use laser diodes. These solid-state laser diodes
are located in the optical ports of these units. Laser diodes produce
invisible radiation that may be harmful to human eyes. Never look
directly into the optical port of any fiber optic unit designed to operate
with single-mode optical fiber.
NOT FOR LIFE SUPPORT SYSTEMS
Liteway, Inc. does not authorize or warrant any of its products or
accessories for use in critical life support systems or applications of any
kind.
© Copyright 2018 Liteway, Inc. 124968 Rev E
OPERATING INSTRUCTIONS
Fiber Optic IRIG
Signal Distribution
Model IRGP-1501
The IRGP-1501 is an optical repeater that is used to implement a
drop-and-repeat network for IRIG A through E signals.

Technical Specifications

Signal Bandwidth 100 Hz to 500 KHz
Out Impedance 50 ohms
Out Signal Level 3 volt peak to peak, (5 mA)
Signal/Noise Ratio 60 dB/min (ref 1Vpp)
Linearity & THD 3% max
Operating Wavelength 850 (-1), 1310 (-3,-7), 1550 (-9)
Optical Output -15 dBm typical
Optical Loss Budget 0 – 12 dB
Fibers Accommodated 1 multimode (-1,-3), 1 single-mode (-7,-9)
MTBF 100,000 Hours (MIL-HDBK-217)
Temperature Range -35º to +75ºC
Humidity <95% non condensing
Power Requirements 11-24 VAC/DC @ 190 mA
Physical Size (mm) 5.0"(127)L x 3.0"(76)D x 1.0" (25.4)W
All specifications measured with 1Km of 62.5u multimode fiber.
All specifications are subject to change without prior notice.
